- Page 1 Inspiron 5584 Setup and Specifications Regulatory Model: P85F Regulatory Type: P85F001...
- Page 2 WARNING: A WARNING indicates a potential for property damage, personal injury, or death. © 2019 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 3: Table Of Contents
Contents Set up your Inspiron 5584..........5 Create a USB recovery drive for Windows.....8 Views of Inspiron 5584..........9 ......................9 Front ....................... 10 Right ......................10 Left ......................11 Base .....................12 Display ....................13 Bottom Specifications of Inspiron 5584........14 ................14 Dimensions and weight .................... - Page 4 Camera ....................21 Touchpad ................21 Touchpad gestures ..................22 Power adapter ....................22 Battery ....................23 Display ..............24 Fingerprint reader (optional) ......................25 Video ................25 Computer environment Keyboard shortcuts............. 27 Getting help and contacting Dell......... 30 .................30 Self-help resources ..................31 Contacting Dell...
-
Page 5: Set Up Your Inspiron 5584
Set up your Inspiron 5584 NOTE: The images in this document may differ from your computer depending on the configuration you ordered. Connect the power adapter and press the power button. NOTE: To conserve battery power, the battery might enter power saving mode. - Page 6 SLN151664 SLN151748 at www.dell.com/support. For Windows: Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you: – Connect to a network for Windows updates. NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when prompted.
- Page 7 Locate and use Dell apps from the Windows Start menu—Recommended Table 1. Locate Dell apps Resources Description My Dell Centralized location for key Dell applications, help articles, and other important information about your computer. It also notifies you about the warranty status, recommended accessories, and software updates if available.
-
Page 8: Create A Usb Recovery Drive For Windows
A message appears, indicating that all data in the USB flash drive will be deleted. Click Create. Click Finish. For more information about reinstalling Windows using the USB recovery drive, see the Troubleshooting section of your product's Service Manual at www.dell.com/support/manuals. -
Page 9: Views Of Inspiron 5584
Views of Inspiron 5584 Front Left microphone Provides digital sound input for audio recording and voice calls. Camera Enables you to video chat, capture photos, and record videos. Camera-status light Turns on when the camera is in use. Right microphone... -
Page 10: Right
Right SD-card slot Reads from and writes to the SD card. USB 2.0 port Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 480 Mbps. Security-cable slot (wedge-shaped) Connect a security cable to prevent unauthorized movement of your computer. Left Power-adapter port Connect a power adapter to provide power to your computer. -
Page 11: Base
Connect to a TV or another HDMI-in enabled device. Provides video and audio output. Network port Connect an Ethernet (RJ45) cable from a router or a broadband modem for network or Internet access. USB 3.1 Gen 1 ports (2) Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps. -
Page 12: Display
If the power button has a fingerprint reader, place your finger on the power button to log in. NOTE: You can customize power-button behavior in Windows. For Me and My Dell at more information, see www.dell.com/support/ manuals. -
Page 13: Bottom
Provides digital sound input for audio recording and voice calls. Bottom Left speaker Provides audio output. Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. Right speaker Provides audio output. -
Page 14: Specifications Of Inspiron 5584
Specifications of Inspiron 5584 Dimensions and weight Table 2. Dimensions and weight Description Values Height: 18 mm (0.71 in.) Front 22.45 mm (0.88 in.) Rear 364.46 mm (14.35 in.) Width 248.66 mm (9.79 in.) Depth 2.05 kg (4.52 lb) Weight... -
Page 15: Chipset
Chipset Table 4. Chipset Description Values Intel PCH-LP Chipset Generation Intel Core i3/i5/i7 Processor 64-bit DRAM bus width 16 MB Flash EPROM Up to Gen3 PCIe bus Operating system • Windows 10 Home (64-bit) • Windows 10 Professional (64-bit) • Ubuntu Memory Table 5. -
Page 16: Ports And Connectors
Description Values • 12 GB DDR4 at 2400 MHz (1 x 8 GB + 1 x 4 • 16 GB DDR4 at 2400 MHz (2 x 8 GB) • 16 GB DDR4 at 2400 MHz (1 x 16 GB) Ports and connectors Table 6. -
Page 17: Communications
Internal: • One M.2 slot for 2230/2280 solid- state drive or 2280 Intel Optane NOTE: To learn more about the features of different types of M.2 cards, see the knowledge base article SLN301626. Communications Ethernet Table 8. Ethernet specifications Description Values Realtek RTL8107E Ethernet controller Model number... -
Page 18: Audio
Description Values Encryption • 64-bit/ • 64-bit/ • 64-bit/ • 64-bit/ • 64-bit/ 128-bit 128-bit 128-bit 128-bit 128-bit • AES- • AES- • AES- • AES- • AES- CCMP CCMP CCMP CCMP CCMP • TKIP • TKIP • TKIP • TKIP •... -
Page 19: Storage
Storage Table 11. Storage specifications Storage type Interface type Capacity One 2.5-inch hard drive SATA AHCI, up to 6 Up to 2 TB Gbps One M.2 2230/2280 solid-state PCIe Gen3.0x4 NVMe, Up to 512 GB drive up to 32 Gbps Intel Optane memory (optional) Intel Optane memory functions only as a storage accelerator. -
Page 20: Media-Card Reader
Media-card reader Table 13. Media-card reader specifications Description Values One SD-card slot Type Cards supported • Secure Digital (SD) • Secure Digital High Capacity(SDHC) • Secure Digital Extended Capacity(SDXC) Keyboard Table 14. Keyboard specifications Description Values Backlit keyboard Type QWERTY Layout Number of keys •... -
Page 21: Camera
Description Values Keyboard shortcuts Camera Table 15. Camera specifications Description Values Number of cameras HD RGB camera Type Front (above the LCD screen) Location CMOS sensor technology Sensor type Resolution: 0.92 megapixel Still image 1280 x 720 (HD) at 30 fps Video 78.6 degrees Diagonal viewing angle... -
Page 22: Power Adapter
Power adapter Table 17. Power adapter specifications Description Values E4 45 W E4 65 W Type 4.5 mm x 2.9 mm 4.5 mm x 2.9 mm Diameter (connector) 100 VAC–240 VAC 100 VAC–240 VAC Input voltage 50 Hz–60 Hz 50 Hz–60 Hz Input frequency 1.30 A 1.6 A/1.70 A... -
Page 23: Display
4 hours (when the computer is off) Charging time (approximate) NOTE: Control the charging time, duration, start and end time, and so on using the Dell Power Manager application. For more information on the Dell Power Me and My Dell on Manager see, https://www.dell.com/... -
Page 24: Fingerprint Reader (Optional)
Description Values Megapixels Pixels per inch (PPI) 500:1 500:1 Contrast ratio (min) 25 ms 25 ms Response time (max) 60 Hz 60 Hz Refresh rate Horizontal view angle • Left: 40 degrees • Left: 40 degrees • Right: 40 degrees •... -
Page 25: Video
Video Table 21. Video specifications Discrete graphics Controller External display support Memory Memory size type NVIDIA GeForce One HDMI 1.4b port 2 GB/4 GB GDDR5 MX130 Table 22. Video specifications Integrated graphics Controller External display support Memory size Processor Intel UHD One HDMI 1.4b port Shared system Graphics 620... - Page 26 ‡ Measured using a 2 ms half-sine pulse when the hard-drive head is in parked position.
-
Page 27: Keyboard Shortcuts
Keyboard shortcuts NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts remain the same across all language configurations. Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. - Page 28 Function key Re-defined key (for Behavior multi-media control) Play/Pause Play next track/chapter Switch to external display Search Toggle keyboard backlight (optional) Decrease brightness Increase brightness The Fn key is also used with selected keys on the keyboard to invoke other secondary functions.
- Page 29 Function key Behavior Open application menu Toggle Fn-key lock Page up Page down Home...
-
Page 30: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 26. Self-help resources Self-help resources Resource location Information about Dell products and www.dell.com services My Dell Tips... -
Page 31: Contacting Dell
BIOS information Product ID in the search bar. Contacting Dell To contact Dell for sales, technical support, or customer service issues, see www.dell.com/contactdell. NOTE: Availability varies by country/region and product, and some services may not be available in your country/region.
