- Page 1 Radius 2 Operation Manual...
-
Page 2: Table Of Contents
Index 1: Safety instructions 2: Overview 3: Front panel controls 4: Rear panel controls 5: Warranty 6: Technical specification Radius 2 Operation Manual Index... - Page 3 1: Important safety instructions - Read first READ THE INSTRUCTIONS – Read and retain these instructions for future reference. Read the instructions on the Safety Sheet provided separately. Adhere to all warnings printed here and on the console and its power unit. COVERS –...
-
Page 4: 2: Overview
EQ/Isolator, a smooth natural sounding hi-pass filter on each channel, and an AUX send/Return system with insert button for easy integration of external effects, including MasterSounds own FX unit. Radius 4 also includes 2 mic inputs, selectable via the rear panel. -
Page 5: 3: Front Panel Controls
3: Front panel controls AUX – The AUX send level pot adjusts the a mount of channel signal level sent to the Aux Mix Buss, (and on to an external FX unit). Fully clockwise the signal level is boosted by +10dBu, allowing for precise adjustment of FX signals. - Page 6 CH1/CH2 ROTARY FADER – Each channel has a large rotary fader for precision control of its level when mixing. The rotary ranges from fully off when anti- clockwise to unity gain (0dB) when clockwise. For best performance operate these controls near to their fully clockwise position for normal music level.
-
Page 7: 4: Rear Panel Controls
4: Rear panel controls MASTER OUT – Output level is +14dBu when the MASTER level control is fully clockwise and the VU meters read -4VU. The XLR output is designed to operate with balanced equipment such as powered monitor speakers and amplifiers. - Page 8 Using the external Send & Return System Connect the Mixer Aux Send outputs to the FX unit Inputs, and connect the FX units Outputs to the mixer Aux Returns. Set the FX unit to unity gain. Turning up the mixer Channel Send control feeds the channel signal to the FX unit.
-
Page 9: 5: Warranty
5: Warranty MasterSounds warrants that the Mixer shall be free of defects in workmanship and materials for a period of twenty four months (2 years) from the date of delivery. In the event that the product fails to operate as intended, MasterSounds will repair or replace the product subject to the following conditions. -
Page 10: 6: Technical Specification
Weight W = 14 L = 10 H = 7 (inch) Packed Dimensions Packed weight ** MasterSounds reserves the right to change the specification without notice. ** Radius 2 Operation Manual Copyright © 2020 MasterSounds Audio. All rights reserved www.mastersounds.co.uk... - Page 12 Radius 2 Operation Manual Copyright © 2020 MasterSounds Audio. All rights reserved www.mastersounds.co.uk...
