Maintenance Manual
MAINTENANCE UNIT
MU-1
ISSUE6
2016/04
149P-0015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MU-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Olympus MU-1

Summary of Contents for Olympus MU-1

  • Page 1 Maintenance Manual MAINTENANCE UNIT MU-1 ISSUE6 2016/04 149P-0015...
  • Page 3 If repairs or modifications are made by personnel not authorized by Olympus, the warranty is void, and Olympus shall not be liable for damage that occurs to or as a result of use of the modified product. The information contained in this manual is subject to change at any time without notice. Later editions of this manual will contain revised and updated material.

  • Page 5: Table Of Contents

    MU-1 CONTENTS Chapter 1: Product Outline ............1-1 1 Product Overview ....................1-1 2 Features ........................1-1 3 Restrictions ......................1-2 4 Specifications ......................1-3 5 Names and Functions of Various Components ........... 1-5 6 System Chart ......................1-7 Chapter 2: Specifications ............2-1 Chapter 3: Installation and Connection ........

  • Page 7: Chapter 1: Product Outline

    MU-1 Chapter 1: Product Outline 1. Product Overview This product is used in combination with the AW channel cleaning adapter, leak tester and chemical tank to provide the following functions. This product can be combined with the AW channel cleaning adapter to drain water from the OES scope and EVIS scope air and water channel.

  • Page 8: Restrictions

    MU-1 3. Restrictions OES scopes and EVIS scopes can be used. Unless the AW channel cleaning adapter, leak tester and chemical tank are used, draining water from the air and water channel, leak inspections and feeding rubbing alcohol for drying the OES scope and EVIS scope are not possible.

  • Page 9: Specifications

    MU-1 4. Specifications Main Unit Specifications 4-1-1 Applicable Endoscopes OES Scope EVIS Scope 4-1-2 Pump Used Electromagnetic vibrator pump 4-1-3 Air Feeding Performance At the scope socket: 2.84 x 10 Pa or greater at 0 ml/min; 1.76 x 10 Pa or greater at 2000 ml/min;...
  • Page 10 MU-1 4-2-3 Atmospheric Pressure 700 to 1060 Pa 4-2-4 Inflammable Atmosphere Use in an inflammable atmosphere is prohibited. Product Outline ISSUE6...

  • Page 11: Names And Functions Of Various Components

    MU-1 5. Names and Functions of Various Compo- nents Front and Sides Hook Used when the maintenance unit is hung on a wall. The included screw is used to install Screw x 2 this hook near a sink if necessary.
  • Page 12 MU-1 Back Power supply inlet Breaker Product Outline ISSUE6...

  • Page 13: System Chart

    MU-1 6. System Chart Water-resistant Cap EVIS Videoscope Alcohol Container AW Channel MaintenanceUnit (MB-264) Cleaning Adapter (MU-1) only EVIS Videoscope 100/200 series OES Fiberscope 10/20/30 series Leakage Tester (MB-155) OES Fiberscope ISSUE6 Product Outline...

  • Page 15: Chapter 2: Specifications

    MU-1 Chapter 2: Specifications Refer to the “Specifications” of Instruction Manual. ISSUE6 Specifications...

  • Page 17: Chapter 3: Installation And Connection

    MU-1 Chapter 3: Installation and Connection Refer to the “Installation and Connection” of Instruction Manual. ISSUE6 Installation and Connection...

  • Page 19: Chapter 4: Care, Storage And Disposal

    MU-1 Chapter 4: Care, Storage and Disposal Refer to the “Care, Storage and Disposal” of Instruction Manual. ISSUE6 Care, Storage and Disposal...

  • Page 21: Chapter 5: Inspection

    MU-1 Chapter 5: Inspection Refer to the “Inspection” of Instruction Manual. 1. Inspection Check Sheet Please copy and use check sheet on next page. A check item may change with the destination and specifications. There may be a check item which is on this list and is not in the instruction manual.
  • Page 22 MU-1 Inspection ISSUE6...

  • Page 23: Chapter 6: Safety Check

    MU-1 Chapter 6: Safety Check 1. External Leak Current • Criteria External leak currents should not exceed the values indicated below. Criteria Inspection item Normal condition Single fault 100 A 500 A External leak current • Inspection procedure Measure the leak current at the external screw that is farthest from the inlet.

  • Page 24: Grounding Resistance

    MU-1 3. Grounding Resistance • Criteria The resistance between the external case and grounding line should be 0.2 ohm or less. • Inspection procedure Measure the resistance between the grounding terminal in the removable power supply cord and the screw that is farthest from the inlet.

  • Page 25: Safety Check Sheet

    MU-1 4. Safety Check Sheet Date of inspection Product MU-1 Inspected by Serial number Checked by Electrical Safety Inspection Item Criteria Result 100 A or less Normal Condition 2-1-1 External leak current 500 A or less Single Fault 500 A or less...

  • Page 27: Chapter 7: Troubleshooting

    MU-1 Chapter 7: Troubleshooting Refer to the “Troubleshooting” of Instruction Manual. ISSUE6 Troubleshooting...
  • Page 28 2951 Ishikawa-machi, Hachioji-shi, Tokyo Japan Medical Service Engineering Department Medical Repair Service Division PRINTED IN JAPAN FIRST EDITION : 10.2003...
