V2-08.14
Assembly Instructions
(W x D x H) 1.35m x 0.80m x 2.14m
Product Name: Gloucester Pergola Seat
Pressure Treated products should not be treated with any other products for the first month.
PLEASE KEEP THESE INSTRUCTIONS
Zest4Leisure
01352 752555 option 1 – sales@zest4leisure.co.uk
Advertisement
Table of Contents
Related Manuals for Zest 4 Leisure Gloucester Pergola Seat
Summary of Contents for Zest 4 Leisure Gloucester Pergola Seat
- Page 1 V2-08.14 Assembly Instructions (W x D x H) 1.35m x 0.80m x 2.14m Product Name: Gloucester Pergola Seat Pressure Treated products should not be treated with any other products for the first month. PLEASE KEEP THESE INSTRUCTIONS Zest4Leisure 01352 752555 option 1 – sales@zest4leisure.co.uk...
- Page 2 Gloucester Pergola Seat Assembly Instructions Requires 2 person assembly. All screw holes to be pre-drilled. Tools required: Corded / Cordless Drill, Pozi-drive Bit / Screwdriver, 3mm Drill Bit, Tape Measure. Gloucester Pergola Seat Pack List Item Description Quantity Seat Support...
- Page 3 Position Trellis Battens J to front posts and attach using 4no 60mm Screws – 2no per batten (Fig.6a) Fix Trellis Infills K to Trellis Battens J and Rail G using 4no 40mm Screws per Infill (Fig.6b) Gloucester Pergola Seat is now complete.
- Page 4 www.zest4leisure.co.uk...
- Page 5 www.zest4leisure.co.uk...
