- Page 3 INTRODUCTION Thank you for choosing the N8XJK Super Booster from West Mountain Radio and congratulations on finding the solution to your low voltage problems for mobile, portable, or emergency power operation! This product is designed to boost your battery voltage to a level optimum for transmit allowing the maximum use of a battery’s energy.
-
Page 4: Installation And Setup
Output (load) connects on the right side of the case. Make sure to only connect the RED lead to POSITIVE, and the BLACK lead to NEGATIVE. Visit the West Mountain Radio web site for a large variety of cables with Powerpole connectors. - Page 5 3. Using the RF sensor: Connect an RF-connector in-line with the antenna feed and run a short thin coax (any gauge) to the BNC connector on the Booster. Contact West Mountain Radio if the transmitter is over 200W for help coupling the RF to the Booster.
-
Page 6: Operation
2. Mode switch: DISaBle will shut the unit off and the battery voltage is passed through to the output as-is. eNaBle will turn the booster to be continuously on. West Mountain Radio Operating Manual... - Page 7 Unit shuts OFF 2 seconds Unit ON Three quick button Display shows mini- presses mum battery voltage and maximum output voltage for several seconds Display shows min/ Hold down button for Min/Max is reset 2 seconds West Mountain Radio Operating Manual...
-
Page 8: Specifications
Load = 20A (100W xmit) 4.2mV RMS, 12mVp-p Load = 3A (receive) 3.5mV RMS, 10mVp-p Connectors: Anderson Powerpole , 45A ® Size: 8.0” x 2.3” x 2.2” Weight: 0. lbs Mounting Holes: Four - 0.175 d, #8 hardware West Mountain Radio Operating Manual... - Page 9 15A. Powerpole® Connector-12 Pair #58257-1093 30A. Powerpole® Connector-12 Pair #58257-1095 45A. Powerpole® Connector-12 Pair #58257-1099 PWRcrimp Crimp Tool #58568-1049 Mounting Magnet #58515-1785 To purchase or view other accessories available, call or go online at: www.westmountainradio.com/shop West Mountain Radio Operating Manual...
- Page 10 N8XJK Super Booster & Booster Remote Warranty N8XJK Super Booster & Booster Remote is warranted against failure due to defects in workmanship or materials for one year after the date of purchase from West Mountain Radio. Warranty does not cover damage caused by abuse, accident, misuse, improper or abnormal usage, failure to follow instructions, improper installation, alteration, lightning, or other incidence of excessive voltage or current.
