Notes on simultaneous multi-channel Table of Contents operation ............18 Note on microphone and transmitter combinations ............18 CROSS REMOTE Compatibility ......18 Features ..............3 Specifications ............19 Parts Identification ........... 4 Carrier Frequencies and Channel Steps ....20 Power Supply .............
Encrypted transmissions Features AES 256-bit encryption allows for highly secure wireless transmissions. The DWT-B30 is a digital wireless transmitter for a UHF Switchable mic or line input level and synthesized wireless microphone system to be used for adjustable attenuator broadcast or movie production purpose. This transmitter is...
European model Parts Identification Connector front view 1: GND 2: +5.2 V DC output (for power supply of lavalier microphone) 3: HOT (input impedance 4.7 kohms or more with +5.2 V DC) Connecting the microphone Microphone (optional) To secure the connection, turn the ring on the connection plug to lock it.
• When BATTERY TYPE is set to TYPE1, the power status is indicated based on the use of new LR6 (size For details, see “Battery indication” (page 5). AA) Sony Alkaline batteries. An incorrect indication may result when a different kind of batteries, a different I Menu display section brand of batteries or old batteries are used.
Set the transmitter group (GP) and channel (CH) as follows: For details on groups and channels, refer to “Sony Digital Wireless Microphone System Frequency Lists” on the supplied CD-ROM. For details on menu operation, see “Basic Menu Operations”...
Press the + or – button repeatedly until the GP/CH Using Cross Remote indication is displayed. Hold down the SET button until the item to be set flashes. This transmitter is equipped with a wireless remote control function that can be used to set the parameters (low-cut Press the + or –...
goes up, RF REMOTE turns on, and the remote Using the Encrypted control function becomes operative. Transmission Function To use the Cross Remote with a previous pairing In the RF REMOTE indication, select ON. The unit is capable of transmitting encrypted signals to prevent unwanted surveillance.
Exchange the encryption key. Basic Menu Operations On the receiver side, select REMOTE (wireless remote) as the encryption key exchange method, and perform encryption key exchange. REMOTE cannot be selected when the wireless Function name remote control function is disabled. Note If the receiver does not support AES256 mode, select SECURE KEY.
–13 –10 For details about the frequency range of each band, refer to “Sony Digital Wireless Microphone System Frequency LINE – Lists” on the supplied CD-ROM. The audio attenuator setting can be changed from the...
POWER: Locks POWER button operations only. TYPE1: The power status is indicated based on SETTING: Locks setting change operations only. characteristics of new LR6 (size AA) Sony Alkaline POWER+SETTING: Locks both POWER button and batteries. Select this for LR6 (size AA) alkaline batteries.
For details, see “Using Cross Remote” (page 7). Audio codec mode setting (CODEC MODE) Audio phase switch function PHASE) MODE1: Audio codec mode that is compatible with first generation DWX-series devices. Switch the phase when a microphone that outputs with MODE2: Audio codec mode that prioritizes short delay inverted phase is connected.
For details, see “Setting the maximum RF output power Automatic dimming of the display (MAX RF POWER)” (page 13). (DIMMER MODE) Setting the maximum RF output The organic light-emitting diode display can be set to dim or turn off after a certain amount of time. power (MAX RF POWER) AUTO OFF: The display turns off after 30 seconds.
- Pairing the unit or establishing encrypted transmission Attaching With the Soft with a different receiver. - Pairing the receiver that was paired with the unit with Case a different transmitter. - Establishing encrypted transmission between the receiver and a different transmitter. The transmitter can be attached to the user with the supplied soft case.
Rear Fig. 2 Hook and loop fastener Belt Hook and loop fastener Front Removing the unit from a belt When the soft case is attached to a belt with the unit’s antenna pointing up, be careful to avoid getting the soft case’s hook and loop fastener caught on the belt during removal.
Block Diagram US model Attenuator 1: +5.2 V (output) 2: HOT Digital signal processor 3: COLD 4: GND Head amp. Low-cut filter Audio High- A/D converter codec frequency modulator circuit Internal SG European model Attenuator 1: GND 2: +5.2 V (output) Head amp.
If you encounter a problem using this transmitter, use the following checklist to find a solution. For any problems with the receiver or adapter, refer to the operating instructions supplied with the respective device. If the problem persists, consult your Sony dealer. Symptom...
- where adjacent equipment might knock against the The use of portable telephones and other communication tuner devices near the DWT-B30 may result in malfunction and Keep the transmitter as far from such equipment as interference with audio signals. It is recommended that possible or use buffering material.
Audio attenuator adjustment range (pad) 0 dB to 48 dB (3 dB steps, MIC input mode only) Microphone input connector 17 ( 63 (2 US model: Sony 4-pin (SMC9-4S) * 204 (8 (female) European model: Small 3-pin connector with lock Mass Approx.
