- Page 1 Cassette Type Series FB4DEH FB4PEH FB4FEH 4PXEA 4DXEA 4ZXEA Air Conditioner installation manual imagine the possibilities Thank you for purchasing this Samsung product.
-
Page 2: Table Of Contents
Contents Preparation for installation ....................................... 3 Deciding on where to install the indoor unit ................................4 Indoor unit installation ........................................8 Purging the unit ............................................. 9 Connecting the refrigerant pipe ....................................9 Cutting/Flaring the pipes ....................................... 10 Performing leak test & insulation ....................................11 Drainpipe and drain hose installation .................................. -
Page 3: Preparation For Installation
Our units should be installed in compliance with the spaces shown in the installation manual, to ensure accessibility from both Power supply line, fuse or circuit breaker with current local safety standards. to ensure the operation of any other domestic appliance connected to the same electric lines. included in the manual. -
Page 4: Deciding On Where To Install The Indoor Unit
Preparation for installation Accessories The following accessories are supplied with the indoor unit. Installation Insulation pipe Drain hose Clamp band manual Deciding on where to install the indoor unit Indoor unit There must be no obstacles near the air inlet and outlet. Install the indoor unit on a ceiling that can support its weight. - Page 5 body. Insulation installation guide insulated together. Thickness: more than 10mm Indoor unit 090FB4P 100FB4P 100FB4F 0904PX 910X235 940X235 610X235 650X235 (840x288x840) 1254 X 1004PX 1004ZX Cassette type 090FB4D 100FB4D 910X193 940X193 610X193 650X193 (840x246x840) 0904DX 1004DX 052FB4D 910X151 940X151 610X151 650X151 (840x204x840) order to permit accessibility from each side,...
- Page 6 Deciding on where to install the indoor unit Required space for an indoor unit installation 1500mm or more 2500mm or more 20mm Obstruction 100FB4P 100FB4F 090FB4D 052FB4D 090FB4P 1004PX 100FB4D 0904PX 1004ZX 1254DX 1254PX 0904DX 1404PX 1004DX 1404DX 840×204×840 840×246×840 840×288×840 840×288×840...
- Page 7 Drawing of the indoor unit 890~910 (Celling opening) Sub duct connection 100FB4P 100FB4F 090FB4D 090FB4P 1004PX 100FB4D 052FB4D 0904PX 1004ZX 0904DX 1254DX 1254PX 1004DX 1404DX 1404PX 840 X 204 X 840 840 X 246 X 840 840 X 288 X 840 15.0 16.0 18.0...
-
Page 8: Indoor Unit Installation
Indoor unit installation 1. Determine the position of the pipe and drain hose hole as seen in the picture and drill the hole with an inner diameter of 65mm so that it slants slightly downwards. due to temperature or humidity. For this reason, before drilling the holes maintain the correct dimensions between the markings. -
Page 9: Purging The Unit
Purging the unit before connecting the assembly piping. Unscrew the pinch pipe at the end of each refrigerant pipe. ready to connect the piping. Connecting the refrigerant pipe There are two refrigerant pipes of different diameters : The inside of copper pipe must be clean & has no dust 1. -
Page 10: Cutting/Flaring The Pipes
Cutting/Flaring the pipes 1. Make sure that you have the required tools available. (pipe cutter, reamer, flaring tool and pipe holder) 2. If you wish to shorten the pipes, cut it with a pipe cutter, taking care to ensure that the cut edge remains at a 90° angle with the side of the pipe. -
Page 11: Performing Leak Test & Insulation
Performing leak test & insulation Leak test To identify potential gas leaks on the indoor unit, inspect the connection area of each refrigerant pipe using a leak detector for R410A. Before recreating the vacuum and recirculating the refrigerant gas, it is advisable to pressurize the whole system with nitrogen (using a cylinder with pressure reducer) at a pressure above 40 bar in order to immediately detect leaks on the refrigerant fittings. -
Page 12: Drainpipe And Drain Hose Installation
Performing leak test & insulation humidity conditions. e.g. The pipe installed at a corridor of a dormitory and studio or near an exit that opens and closes frequently. Drainpipe and drain hose installation 1 Push the supplied drain hose as far as possible over the drain socket. 2 Tighten the metal clamp as shown in the picture. - Page 13 Check that the indoor unit is level with the ceiling by using the leveler. If it is necessary to increase the height of the drainpipe, install the drainpipe straightly within 300 mm from the drain hose port. If it is raised higher than 550 mm, there can be water leaks.
-
Page 14: Installing Dpm
Drainpipe and drain hose installation Testing the drainage 1. Check the leak test at the connection part of the flexible hose and the distributing pipe (PVC). check part indoor unit, and pour in some water. Hose the distributing pipe is used. 2. -
Page 15: Connecting The Connection Cord
Connecting the connection cord the electric connections. The indoor unit is powered by the outdoor unit by means of a H07 RN-F connection cable (or a more power model), with insulation in synthetic rubber and jacket in polychloroprene(neoprene), in accordance with the requirements of standard EN 60335-2-40. 1. -
Page 16: Installation Procedure
Installation Procedure How to connect your extended power cables 1. Prepare the following tools. Tools Crimping pliers Insulation tape Contraction tube (mm) (mm) Spec 20xØ6.5(HxOD) Shape Power cable the power cable. CAUTION tube. indoor and outdoor units, refer to the installation manual. 3. - Page 17 tion tape. Method 1 Method 2 Insulation tape Insulation tape 40 mm 35 mm Contraction tube Make sure that the connection parts are not exposed to outside. CAUTION on extensions.) Insulation tape WARNING...
-
Page 18: Setting An Indoor Unit Address And Installation Option
Setting an indoor unit address and installation option Set the indoor unit address and installation option with remote controller option. The procedure of setting option MR-DC00, MR-DH00 MR-EC00, MR-EH00 Option setting Entering mode for Option setting Entering mode for mode setting option mode setting option... - Page 19 Option setting ∨ Press High Fan button( ∧ will be selected in rotation. … 2. Setting Cool mode ∨ Press High Fan button( ∧ will be selected in rotation. … 4. Setting Dry mode ∨ Press High Fan button( ∧ will be selected in rotation.
- Page 20 Setting an indoor unit address and installation option Option setting Status 12. Setting Cool mode Press Mode button to be change to Cool mode in the OFF status. ∨ Press High Fan button( ∧ will be selected in rotation. … 14.
- Page 21 Setting an indoor unit address (MAIN/RMC) 1. Check whether power is supplied or not. - When the indoor unit is not plugged in, there should be additional power supply in the indoor unit. 1(L) 2. The panel(display ) should be connected to an indoor unit to receive option. 2(N) 3.
- Page 22 Setting an indoor unit address and installation option Setting an indoor unit installation option (suitable for the condition of each installation location) 1. Check whether power is supplied or not. - When the indoor unit is not plugged in, there should be additional power supply in the indoor unit.
- Page 23 Option No. : 02XXXX-1XXXXX-2XXXXX-3XXXXX Option temperature sensor control Remote Controller Display Indication Details Indication Details Indication Details Indication Details Indication Disuse Disuse Details Option Remote Controller Display Indication Details Indication Details Indication Details Indication Disuse master Details 3minute delay Option Setting the output Buzzer control control...
- Page 24 Setting an indoor unit address and installation option Changing a particular option You can change each digit of set option. Option The option mode The unit digit of you want to change change will change Remote Controller Display Indication Details Indication Details Indication Details Indication Details Indication Details Indication Details Indication Option changed...
-
Page 25: Troubleshooting
Troubleshooting Operation Defrost Timer Filter reset Remarks Power reset (Open/Short) (Open/Short) indoor and outdoor unit (communication error for more than 2minutes) Detection of the float switch Flickering X Off... - Page 26 Memo...
- Page 28 DB98-32787A-16...
