Reset Picture Mode

Return all Picture settings to factory default. A screen will come up to confirm your selection or to
cancel it. Press ◄ or ► to make the selection, and then press OK to accept it.
Note: Only settings under the Picture will be reset.

PIP Menu

Your TV features PIP mode so you can watch two pictures at the same time. One picture is displayed as
the full screen (main screen) and the other picture is displayed in a small window (sub screen).
Note: PIP is only available when the Rating Enable option in Parental Controls is set to Off.

PIP Mode

Select from Off, PIP (Picture-inside-picture) or POP (Picture-outside-picture). In PIP mode a smaller sub-
screen is displayed on top of the main screen. In POP mode the main screen and sub-screen are of equal
size and are positioned side-by-side.

Source

Select the input source for the sub-screen. The input sources available will vary according to which input
is used for the main screen.
SUB
MAIN
TV
AV (Composite)
Component
HDMI-1
HDMI-2
HDMI-3
HDMI Side
RGB (Computer)
" " – Indicates which inputs are available for PIP and POP modes.

Position

Select where you want the PIP screen positioned over the main screen. Choose from Top Left, Top
Right, Bottom Left, and Bottom Right.

Size

Set the size of the PIP window. Choose from Small, Medium or Large.

Audio

Select which source will play the audio. Choose from the Main screen or the PIP (sub) screen.
Version 2/23/2010
AV
TV Component
(Composite)
39
www.VIZIO.com
VIZIO M420NV User Manual
HDMI-1
HDMI-2
RGB (Computer)
HDMI-3
HDMI SIDE
