Fastcabling 5838-18 Quick Start Manual

Thank you for picking us over the competition. For years we have been a leading provider of PoE over cat5 and Power Fiber
System. Please take a few minutes to read through this guide before you get start. Not only there are some helpful tips, but
also we have some guides to help you plan and install your switch.
The 5838-18 is industrial hardened fiber PoE extender, which is specially designed to operate under -40℃ to 75℃
environment temperature. It has combined Ethernet media convertor from 1000BASE-X to 10/100/1000BASE-T with
802.3at power over Ethernet Plus (PoE+) injector to deliver both power and high speed data transmission to your powered
device installed in the remote area. The special and convenient power system of 5838-18 supports 12-48VDC power input
for operational flexibility.

Hardware Overview

Front Panel

Port Description
SFP SFP port - support gigabit SPF
Ethernet RJ45 port - 10/100/1000 Ethernet with PoE, support IEEE802.3af/at
DC12-48VDC DC12V-DC48V power input
LEDs Status
OFF – power off
PWR
Yellow- Power ON
OFF-No POE
PoE
Yellow - 48V standard PoE.
OFF -No Link
RJ45 Link/Act
Red-10/100/1000mbps link flashing indicates data exchanging.
OFF -No Link
SFPLINK
Yellow – the fiber link is formed.
Quick Start Guide
