Designed
around your life
Easy Installation
Our products are designed
to make your life easier,
so installing this child restraint
doesn't require outside assistance.
While we encourage the use of
Certified Child Passenger Safety
Technicians to ensure you have
installed the seat correctly,
you can install the restraint
in your vehicle without these
professionals by carefully reading
and following these instructions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PIPA rx and is the answer not in the manual?

Questions and answers

Related Manuals for Nuna PIPA rx

Summary of Contents for Nuna PIPA rx

  • Page 1 Designed around your life Easy Installation Our products are designed to make your life easier, so installing this child restraint doesn't require outside assistance. While we encourage the use of Certified Child Passenger Safety Technicians to ensure you have installed the seat correctly, you can install the restraint in your vehicle without these professionals by carefully reading...

  • Page 2: Table Of Contents

    Base Parts List ™ REFERENCE: Product Overview READ CAREFULLY Using PIPA ™ Product Use Installation With RELX base ™ Child Restraint Only Install In an Aircraft On a Stroller Accessories Cleaning and Maintenance 2 PIPA rx instructions PIPA rx instructions...

  • Page 3: Product Information

    1.855.NUNA.USA please contact our customer service department. or register online at: www.nunababy.com In the USA: Click on the “Register Car Seat” link infousa@nunababy.com on the homepage. www.nunababy.com 1.855.NUNA.USA 4 PIPA rx instructions PIPA rx instructions...

  • Page 4: Child Usage Requirements

    Use the bottom of the base for to severe crash. See page 11 instruction manual storage. to learn what is classified as a moderate to severe crash. 6 PIPA rx instructions PIPA rx instructions...
  • Page 5 To find out if damaged can fall from a shopping cart. parts are replaceable, call DO NOT use on 1-855-NUNA-USA. a shopping cart. NEVER modify any part of the child restraint. 8 PIPA rx instructions PIPA rx instructions...

  • Page 6: Car Seat Use After A Crash

    DO NOT use any products or accessories with this child a Crash restraint unless they are approved by Nuna for use with The National Highway Traffic this child restraint. Doing so Safety Administration (NHTSA) may be unsafe and may void recommends that car seats be the warranty.

  • Page 7: Vehicle Compatibility

    Airbags inflate with great force and can cause severe injury to a child’s neck and spine. 12 PIPA rx instructions PIPA rx instructions...
  • Page 8 This belt cannot be used to install this child restraint. - Lap Belts forward of Seat Bight This belt (Where the seat bottom and seat back meet) should not be used to install this child restraint. PIPA rx instructions PIPA rx instructions...

  • Page 9: Pipa

    13 Dream drape Zipper ™ 14 Canopy Window 15 Seat Cover 16 Handle 17 Shoulder Belt Guide 18 Stroller Release Handle 19 Harness Slots 20 Base Attachment Bars 21 Harness Straps 22 Splitter Plate 16 PIPA rx instructions PIPA rx instructions...

  • Page 10: Relx

    Recline Adjustment Button Child Restraint Release Button 10 Stability Leg Stability Leg Adjustment Button 12 Stability Leg Indicator 13 Stability Leg Storage Release Button 14 Stability Leg Storage 15 Instruction Manual Storage (under Stability Leg) 18 PIPA rx instructions PIPA rx instructions...

  • Page 11: Product Overview

    Press the button in the canopy mount. Pull the canopy bow out. Shoulder Pads - Shoulder pads are removable. Buckle Holders - Loosen and unfasten harness. Place buckle tongues in buckle holders. PIPA rx instructions PIPA rx instructions...
  • Page 12 The body support can be used for smaller babies, but MUST be removed once a snug fit can be achieved without it, at approximately 11 pounds. 22 PIPA rx instructions PIPA rx instructions...
  • Page 13 An unlocked handle could move unexpectedly, causing injury to child. Handle MUST NOT contact the vehicle interior (side of car or seat in front) when installed. PIPA rx instructions PIPA rx instructions...
  • Page 14 Infant car seat adapters for strollers sold separately. - Grasp the seat pad and pull it out from under one edge of the adjustment button. Work around the adjustment button to release the remainder of the seat pad. PIPA rx instructions PIPA rx instructions...
  • Page 15 - Then turn child restraint over and remove one harness loop from metal splitter plate. - Pull loose ends of harness out through slots and place in correct slot. PIPA rx instructions PIPA rx instructions...
  • Page 16 - This position provides a medium fit. Crotch belt is threaded into rear slot as shown. - This position provides the largest fit. Crotch belt is threaded through front slot as shown. 30 PIPA rx instructions PIPA rx instructions...

  • Page 17: Product Use

    Do not allow child to slouch. Gently guide child’s arms through harness loops. - Insert buckle tongues into buckle. (continued on the next page) 32 PIPA rx instructions PIPA rx instructions...
  • Page 18 Buckle is fastened. Harness straps are not twisted. Harness is snug – A snug harness cannot be pinched horizontally, and should not allow any slack. Chest clip is level with armpits. (continued on the next page) PIPA rx instructions PIPA rx instructions...
  • Page 19 Serious injury or death could occur to a child that is not secured properly. If child is not secured properly, child could be ejected in a sudden stop or crash, resulting in serious injury or death. 36 PIPA rx instructions PIPA rx instructions 37...
  • Page 20 If the stability leg indicator shows red, the stability leg is not making firm contact with the vehicle floor. Adjust as needed. Stability leg should be perpendicular to the floor. (continued on the next page) 38 PIPA rx instructions PIPA rx instructions 39...
  • Page 21 Push until the release button clicks into place. The stability leg can be used or stored for both rigid latch and vehicle belt installation. 40 PIPA rx instructions PIPA rx instructions 41...
  • Page 22 Be sure that the base bottom is firmly seated on vehicle seating surface and there is no gap between the base bottom and vehicle seat. (continued on the next page) 42 PIPA rx instructions PIPA rx instructions...
  • Page 23 “click” indicates it’s locked into a retracted position. A gap is acceptable if the base clicks through all retracted positions but is still not fully against the vehicle seat. (continued on the next page) 44 PIPA rx instructions PIPA rx instructions...
  • Page 24 There should be no gap between the vehicle seat and the bottom of the base. It is acceptable to install with both rigid latch and the vehicle belt. (See vehicle belt installation on the next page.) 46 PIPA rx instructions PIPA rx instructions...
  • Page 25 - While pressing the base firmly downward onto the vehicle seat, (1) tighten the vehicle belt by pulling upward on the shoulder belt (2). (continued on the next page) 48 PIPA rx instructions PIPA rx instructions...
  • Page 26 There should be no gap between the vehicle seat and the bottom of the base. It is acceptable to install with both rigid latch (p.42) and the vehicle belt. 50 PIPA rx instructions PIPA rx instructions...
  • Page 27 Gently push or pull the top of the base until it locks into position. (continued on the next page) 52 PIPA rx instructions PIPA rx instructions...
  • Page 28 When Installed with Lap and Lap/Shoulder Belt: - Lift the lock off release button. - Unbuckle the vehicle belt and un- route the shoulder and lap belt from the base. Remove the base. 54 PIPA rx instructions PIPA rx instructions...

  • Page 29: Child Restraint Only Install

    - Angle is correct when blue line on child restraint (located on the label on the side of the child restraint) is level with ground. (continued on the next page) PIPA rx instructions PIPA rx instructions...
  • Page 30 Blue line must be level with ground. Vehicle belt must be buckled, tight and must stay locked. Child restraint should be stable and not move side to side more than 1 inch at belt path. PIPA rx instructions PIPA rx instructions...
  • Page 31 Check that lap belt does not move by pulling and pushing hard on infant restraint. If belt loosens or lengthens, repeat procedure. The locking clip should be 1/2 inch (12.5 mm) from the vehicle buckle. PIPA rx instructions PIPA rx instructions...

  • Page 32: In An Aircraft

    Installation on a Stroller This infant carrier can attach to Nuna strollers as well as other brands of strollers using adapters (see next page). Adapters are sold separately. Visit nunababy.com for more information.

  • Page 33: Accessories

    - Infant Car Seat Post Adapters This infant carrier can also attach to other brands of strollers using adapters. Visit nunababy.com for more information. PIPA series base PIPA rx is also compatible with the PIPA series base, sold separately. PIPA rx instructions PIPA rx instructions...

  • Page 34: Cleaning And Maintenance

    Check regularly if everything functions properly. If any parts are torn, broken, or missing, stop using this product. Nuna Baby Essentials, Inc. Nuna and all associated logos are trademarks.
