Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instructions
1. SAFETY
WARNING! Disconnect the hose reel from the water supply before changing accessories, servicing or performing any maintenance.
‰
Maintain the hose reel trolley in good condition.
9
Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the
9
warranty.
DO NOT operate the hose reel trolley if any parts are damaged or missing as this may cause failure and/or personal injury.
8
DO NOT exceed the rated capacity of the hose reel trolley.
8
DO NOT use the hose reel trolley for any purpose other than that for which it is designed.
8
DO NOT operate the hose reel when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
DO NOT direct water from the water hose at yourself or others.
8
2. INTRODUCTION
Lightweight & durable tubular steel design. Perfect for keeping longer water hoses neat and tidy. Includes a 1.8m leader hose with 3/4" BSP
brass fittings. Can hold up to 120m of Ø13mm standard water hose or 50m of Ø19mm H/D hose (hose not included). Features a non-slip
handle and a storage basket for frequently used tools. Fitted with easy rolling 10" puncture proof PU wheels and solid axle for rough terrain.
3. SPECIFICATION
Model No: .................................................................. HRCHD
Nett Weight: ................................................................ 18.5kg
4. ASSEMBLY
© Jack Sealey Limited
HEAVY-DUTY HOSE REEL CART
HRCHD
MODEL NO:
fig.1
Original Language Version
fig.2
HRCHD Issue 1 28/08/19
Advertisement
Related Manuals for Sealey HRCHD
Summary of Contents for Sealey HRCHD
- Page 1 HRCHD MODEL NO: Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions, and properly maintained, give you years of trouble free performance. IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED.
- Page 2 (fig.2.4) and slide both bolts through mounting holes of handle (fig.12.F). Place basket (fig.12.H) mounting tabs onto bolts (fig.2.4) then place flat washer (fig.2.8) onto both bolts. Fasten basket using hex nuts (fig.2.7). Original Language Version HRCHD Issue 1 28/08/19 © Jack Sealey Limited...
- Page 3 Prior to storing the hose and reel, ensure that the water supply is turned off and any accessories are disconnected. Drain as much water from the hose as possible. Place in a dark, safe, dry, childproof location, where the hose will be protected from frost. Parts support is available for this product. Please email sales@sealey.co.uk or telephone 01284 757500 ENVIRONMENT PROTECTION Recycle unwanted materials instead of disposing of them as waste.
