- Page 1 Cooltech SERVICE MANUAL Service Manual Cooltech V1.1...
- Page 2 Service Manual Cooltech Content Equipment description ............................3 1.1. Unpacking and installation ................¡Error! Marcador no definido. 1.2. Equipment components ................¡Error! Marcador no definido. 1.2.1. Electronics ............................8 1.1.1. Refrigeration system ................¡Error! Marcador no definido. 1.1.2. Vacuum system ..................¡Error! Marcador no definido.
- Page 3 3.2.7 - Applicators temperature does not decrease................... 46 3.2.8 - Equipment does not decrease below 0 ° C ....................50 3.2.9 – Equipment does not suck ........................51 3.2.10 – Suction losses ............................54 3.3– Report incidents ............................... 80 Spare part list ....................¡Error! Marcador no definido. Technical data ....................
- Page 4 PACKING ACCESSORIES Each accessory is wraped in a plastic bag and placed in the box A4.02266. Accesorio A4.01454 x2 A4.01454 x2 A4.01454 x2 A4.01455 A4.01455...
- Page 5 A4.01454 x2 A4.01453 A4.01454 A4.01455 A4.01455 A4.01455 x2...
- Page 6 APPLICATORS PACKAGING Ref. of packaging EMB-23.XX. Cooltech applicator packaging. MANUALS PACKING BOX A4.01391A.
- Page 7 Packing layout A4.01389 x2 A4.02266 A4.01591 A4.01415 A4.01391...
- Page 9 Cooltech equipment consists of 3 large blocks: an electronic block - for control of all inputs and outputs of the equipment, a refrigeration block – for cooling the hot part of the peltiers and a vacuum block - for stopping blood circulation in the treated area, avoiding heating the area for better results.
- Page 10 This memory card should have maximum capacity of 2GB and format to FAT32 clouster 4096. On the microSD are stored only 3 '.ars' files: PrjAreas.ars, RrjIcons.ars and PrjImages.ars. If exist other files, may appear an error while the software is being loaded. Main CPU is responsible for controlling temperature, vacuum and refrigeration of each applicator, reading the information from all inputs (sensors, switches, power supplies, resistors ect.) and activating any of outputs (pumps, peltiers, electrovalves ect.) in different moments and also...
- Page 11 Ventilator radiator Ventilator electronics Emergency button Control cable (peltier power supply) applicator 2 Control cable (peltier power supply) applicator 1 Buzzer Backlight TFT Communication cable + power supply 24V TFT Internal temperature sensor 1.1.1. Refrigeration system...
- Page 12 1.1.2. Vacuum system...
- Page 13 General considerations for cleaning and maintenance: For safety reasons, before cleaning the equipment, it is recommended to disconnect the power cord from power socket. For methacrylate surfaces, pay great attention in the use of cleaning products. If this material comes in contact with substances such as alcohol, solvents, ammonia or other aggressive products (thinners, acetone ...), it reacts forming "cracks", which are not visible immediately but in the next days.
- Page 14 It is recommended to clean and sanitize the applicators of the equipment after each treatment. To do this, remove the product residues (gel) deposited in the applicator, clean and disinfect the applicator before using again. Do not use products containing alcohol. For outside cleaning of the casing, dry thoroughly using synthetic fabrics before starting a new treatment.
- Page 15 Press the grey clip of the female connector to disconnect the tube and then pull slightly and progressively from the tank. During the cleaning process, it is recommended to keep the applicator on higher position so that the liquid injected with the cleaning tool supplied with the equipment, not return. Then insert the end of the cannula tube into the internal input of the applicator and inject the distilled water contained in the cannula.
- Page 16 Technical Conditions: service report Warranty Internal Customer: Contract Demo Cargo Customer Installation Other Direction: Date of incident : Description of the equipment and incidence Problem related to the security Model: Serial number (S/N):...
- Page 17 Software version: Applicator: Serial number: Incidence specifications: Repair specifications: Materials for repair: Part Component Quantity Description Price Software updated Ver: Details: - Filled by the manufacturer Warranty details: Replace: Repair: RMA no.:...
- Page 18 Before starting the software update of the equipment, it is necessary to access the Main CPU. Remove the left cover of the equipment by unscrewing the 3 rear screws, as shown on the image1 and access to the electro cabinet (Image2): Once the PCB of the equipment is located, connect the AVR programmer to the PCB.
- Page 19 1. Select "Tools -> Device Programming" as shown in the image: 2. Configure the necessary data for the programming:in the "Tool" drop-menu select "Atmel-ICE" and in the drop-menu "Device" select "ATmega128". Then press the "Apply" button. 3. Before programming it is necessary to read and save the EEPROM information for the equipment. To make this procedure, go to the "Memories"...
- Page 20 4. Specify the location for saving the file and its name. Then click the "Save" button and finally click the "Read" button: 5. Click the "..." button as shown in the image and select the appropriate Cooltech program (.hex file) in the Flash section. Then select the EEPROM file previously saved. Click on the "Program" button in...
- Page 21 6. To ensure that the programming process in the section "Flash" has gone correctly, check if appears at the bottom of the screen the following text:...
- Page 22 7. Click on the "Program" button in the EEPROM section to program the information that was previously saved: 8. To ensure that the programming process in the section "EEPROM" has gone correctly, check if appears at the bottom of the screen the following text: These are the alarms that appear during a treatment as animated image on the screen indicating the type of fault.
- Page 23 3.1.1 - Low coolant level This image appears when the coolant level in the tank is low. The treatment process will stop otherwise could damage the peltiers inside the applicators. To solve the problem, proceed with filling the cooling system with antifreeze of 10-20%, follow the process explained in installation and maintenance section.
- Page 24 This alarm indicates excess pressure or too low value in the hydraulic circuit for proper operation. This error normally `is related to the hydraulic circuit pump and appears during a treatment process. If the unit beeps intermittently before the alert appears, it indicates that there is excess pressure in the circuit due to possible obstruction of one of the applicators.
- Page 25 Option 2 - Older or equal to xx.13 versions: On the last diagram both horizontal lines are the thresholds of the high pressure alarm when 2 connected applicators (red color value 152) and the value for 1 connected applicator (green color value 172).
- Page 26 Follow the procedure and test the hand pieces separately to find out which one has the obstruction. Compare the pressure value and if one of them has a value, much higher than the other, replace the applicator. If both have high values, proceed to check the equipment with other hand pieces for a possible obstruction in the equipment hydraulic circuit.
- Page 27 3.1.4 - High or very low equipment temperature warning When this image appears, it is a warning only and not for treatment. Clicking on it, will disappear and the normally treatment can be continued. When the high temperature warning appears, it indicates that the equipment is not working in the optimum conditions to reach the set temperatures of the applicators.
- Page 28 3.1.5 - Vacuum circuit cleaning reminder Vacuum circuit cleaning warning, appears every 100 treatments and is a reminder only. If turn on the machine or return to home screen 100 times, this reminder will reappear. The equipment does not have any device to know that the cleaning has been carried out, so it is not recommended to reset the warning only.
- Page 29 Applicator type Resistance value Straight Thight Curved 7,68Kohm Oval 4,22Kohm Tiny 6,04Kohm Double In case of having intermittent values, resolder or replace the resistor and recheck if the values are stable. Measure the resistance value between marked pins (4 and 5) of the lower connector of the applicator With 2 wrenches (size 10) remove 1...
- Page 30 Remove the covers to access the connector Pin 4 and 5 of the lower connector 3.1.7 - Applicator temperature error Problem in some temperature sensor or difference in temperature between the plates of a hand piece. The treatment will be cancelled in case of having two faulty sensors in the same applicator, or continue working if it is only one.
- Page 31 3 : Temperature difference higher than 5°C between metal plates of applicator 1 4 : Temperature value is more than 3°C lower than setpoint 5 : Temperature difference higher than 5°C between metal plates of applicator 2 The cause for errors 1, 2 and 4, most probably is in the applicator`s head. To check the temperatures of the applicators in real time it is necessary to start a treatment.
- Page 32 3.1.8 - Applicator programmed vacuum not reached The suction error appears when the equipment has not been able to reach the set vacuum for a minute and a half (90s) and stops the treatment. This type of error is mostly related to the placing of the applicator on the body.
- Page 33 If the tool is not available there are 2 other options, one is to use a balloon to simulate the body and the other is to block with the finger the suction duct of the hand piece. Using the balloon method we would get the same results as with the silicone pad. So if the equipment reaches the set vacuum the fault is the placing on the body.
- Page 34 Disconnect pipes from the tank Connect the 2 tubes with the filter in the center Reconnect the “bridge” to the machine Important: When connecting the bridge to the equipment, make sure that the tubes are not bent, otherwise the suction in the hand piece would be blocked. In case both deposit tanks are in good condition and the problem persists proceed to the next check.
- Page 35 Electrovalves circuit identification Block this tube To the pump input are connected 2 tubes, one goes to and the other one to and 4. Make the test, bending the tube that goes towards EV 3 as shown in the image. If after blocking the tube the vacuum loss persists, proceed replacing the CPU, since possibly the vacuum sensor is faulty.
- Page 36 3.2.1 - The equipment does not turn on If after pressing the power button the equipment does not start (loading software and beeping) and the light indicator also does not light up, check first the power cable. If the power cord is correct and plugged into the wall power socket which has working voltage of 100 to 240V, then check the fuses of the equipment.
- Page 37 Power supply mounting screws For better access to the screws...
- Page 38 For better access to the screws of the sources, it is recommended to remove the hydraulic deposit tank to facilitate the operation. Install the new power supply and reconnect the cables. General power supply connection SP-150-24V...
- Page 39 3.2.2 - Accessories not recognized When accessing to the pre-treatment screen, the following image appears in any of the channels: Applicator not connected or resistance value not correct Indicates either that there is no applicator connected or that the measured resistance value is not correct.
- Page 40 Applicator recognition connector If the wiring is OK and measuring with a multimeter (resistance mode) resistance value is correct according to the table, proceed to replace the CPU.
- Page 41 3.2.3 - Screen does not respond When pressing the touchscreen and it does not respond, to solve this problem, perform first a screen calibration. If the display has a protective plastic it is better to remove it and carry out the process without it. The plastic is only to protect the screen during the manufacture process of the equipment.
- Page 42 Remove the 4 screws fastening the display chassis to the front cover Note: Be careful when removing the screws as there are 4 spacer washers between display chassis and front cover. Spacer washers 3.2.4 -Lined screen Lined screen When this problem appears, check the LVDS cable that between the CPU and the TFT for damage and if is well connected.
- Page 43 LVDC cable connecting Main CPU to the TFT 3.2.5 - Treatment screen not allowed When the equipment is switched on and on the main screen the play button is displayed in grey and does not respond to the pressing, this is because the rental period has expired. It may happen also if occured an error during the firmware update or programming of the equipment.
- Page 44 Information screen The list number should be different than 255255255 and in case of this number, it is necessary to reprogram the equipment. If the number that appears is correct, provide the list of codes (in case is not available, contact Technical Assistance).
- Page 45 3.2.6 - Set temperature not reached For this type of fault several factors could cause it. Cooltech equipment uses Peltier elements to generate the cold. Applying the proper voltage and polarity, one side of the element gets cold, but the other one warm.
- Page 46 - Liquid coolant level. If the equipment`s coolant level is not low enough for the warning to appear, it also can be a reason for unsufficient cooling performance. In this case fill up the deposit tank. If the problem persists continue to the next step. - Radiator fans.
- Page 47 Correct position of the fan Reconnect the fan to the Main board and check the air flow direction. - Dusty radiator. In case the fans work correctly, but the air flow is not enough, it is possible that the radiator externally is obstructed by dust, blocking the passage of air. To solve the problem open the equipment and clean the radiator either with compressed air or remove both fans for better Access and use a vacuum cleaner.
- Page 48 Applicators power supplys The expected value should be about 11V, but if it is 0V, check the source control cable, if it is connected properly. Adjustable power supply control connection Power supply terminal Cable colour White Black If the connection is correct, check also the same cable if is properly connected to Main board, as follows: power supply for applicator 1 to connector 17 and power supply for applicator 2 to connector...
- Page 49 Cable positiosn on the CPU Move the control cable of the source that does not work to make sure it is not a cable fault, and if the source voltage reappear, replace the control cable. On the contrary, if the failure persists, exchange the connectors 17 and 16 to rule out a possible CPU problem.
- Page 50 Power supply screws For better access to the screws...
- Page 51 For better access to the screws of the power sources, it is recommended to remove the hydraulic deposit tank to facilitate the operation. Install the new power supply and reconnect the cables. Appilicators power supplies SPV-300-12 Power supply ternimal Cable colour Brown Blue ...
- Page 52 Information screen The list number must be different than 255255255 but in case it is the same will appears a program error. To solve the problem it is necessary to reprogram the equipment. If the list file is not available, contact Technical assistance.
- Page 53 Rear tanks hoses revision Next step, in case the hoses are OK, is to check the filters above the tanks are not wet. These kind of filters when get in contact with a liquid or if they have some type of particle block loose their permeability.
- Page 54 Connecting the syringe to the suction duct Inject the water in the vacuum line. Repeat the procedure twice. Then perform the same, but injecting air only, in order to remove excess water in the circuit. If, after cleaning the hand piece the problem persists, open the equipment and try to find where the obstruction could be, tracing the vacuum line.
- Page 55 3.2.10 - Suction losses If in case that the equipment reaches the programmed vacuum, but does not maintain it, most probably is caused by an air leaks.In order to detect it follow the procedure step by step. Vacuum circuit The first step is to use the silicone pad or balloon in order to detect if the problem is caused by the placement of the hand piece on the body or the coolpad is misplaced.
- Page 56 In this first step is tested the entire circuit. The objective is with increasing the number steps to trace further the line in direction towards the vacuum pump for possible leaks. It will be necessary to block the lines separating it in different sections, by bending or pinching the hoses. If after using silicone pad or balloon, the air loss disappears, the problem was caused by the placement of the applicator on the body.
- Page 57 Apply Loctite 5331 sealant Apply sealant to the plastic thread. Reconnect the plastic fitting to the metal and tighten carefully using a wrench. Reconnect the tube. In case the leak persists proceed with step 3: Step 3 Step 3: Block the line at the other hose of the tank (tube with filter) and test the circuit from the return connector of the tank to the pump.
- Page 58 Temporary bridge In case the leak persists proceed to step 4: Step 4 From step 4 onwards are checked the internal components of the equipment, in this case block the tube connecting the tank and the solenoid valves.
- Page 59 Return tubes blocking in step 4 If the air leak has stopped, the problem has been in the plastic fitting, proceed to the replacement as explained in step 2. If the problem persists move to step 5: Step 5 Block the tube just before the vacuum sensor, in this case the tested component is only the sensor. So if the error persists, change the CPU.
- Page 60 Solenoid valves on the base Electro-valves mounting screws Release the solenoid valve from the base by removing the screws then disconnect it from the tubes. Disconnect the cable from the CPU. EV1 and EV2 connectors Install the new solenoid valve, reconnect the tubes and the cable. Proceed to perform again step 1 to make sure that the problem is solved.
- Page 61 External support vacuum deposit tank SUB00226 Radiator block assembly Cooltech SWT00005 Emergancy button assembly SUB00215 Hydraulic filter assembly Cooltech SUB00212 Hydraulic deposit tank assembly Cooltech MOC00001 Main board CPU 3408 Cryo 510072 Vacuum deposit tank assembly Cryo SUB00302 Hydraulic pump assembly C-E MME00077...
- Page 62 Basic operation Type of equipment Cold controlled equipment for medical use Technical characteristics Maximum continuous vacuum 250mbar Vacuum regulation range -100mbar to -250mbar (Tolerance ±10%) Maximum cooling power (each applicator) 160W Cooling power (each applicator) 90W @ 0°C and Tamb 25°C Minimum cooling temperature -8°C (Tolerance ±5,±1°C) Program time...
Need help?
Do you have a question about the Cooltech and is the answer not in the manual?
Questions and answers
My temperature light on my cooltech cocoon medical keeps coming on then also the paddle warning
