SERVICE MANUAL
Ver. 1 2005D
Revision History
Area
Model
Lineup
VGN-S53B/S
VGN-S73PB/B
Japanese
Japanese
VGN-S93PS/S∗
VGN-S93PSY∗
VGN-S93S/S∗
VGN-S430P/S
VGN-S460/B
VGN-S460P/B
US Canadian
VGN-S470P/S
American
VGN-S480∗
VGN-S480B∗
VGN-S480P∗
∗ : CTO Model
9-876-417-01
VGN-S53B/S73PB/S93PS/S93PSY/S93S
VGN-S430P/S460/S460P/S470P/S480/S480B/S480P
Design and specifications are subject to
change without notice.
PERSONAL COMPUTER
S400
Advertisement
Table of Contents
Related Manuals for Sony VAIO VGN-S53B
Summary of Contents for Sony VAIO VGN-S53B
- Page 1 VGN-S53B/S73PB/S93PS/S93PSY/S93S VGN-S430P/S460/S460P/S470P/S480/S480B/S480P SERVICE MANUAL Ver. 1 2005D Revision History Area Model Lineup VGN-S53B/S VGN-S73PB/B Japanese Japanese VGN-S93PS/S∗ VGN-S93PSY∗ VGN-S93S/S∗ VGN-S430P/S VGN-S460/B VGN-S460P/B US Canadian VGN-S470P/S American VGN-S480∗ VGN-S480B∗ VGN-S480P∗ S400 Design and specifications are subject to change without notice. PERSONAL COMPUTER ∗...
- Page 2 1. Obey precautionary markings and 4. Inspect after completing service Sony, VAIO and CLIE are trademarks or regis- and the service instructions. instructions tered trademarks of Sony. Microsoft, Windows,...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Section Title Page Section Title Page CHAPTER 1. SPECIFICATIONS CHAPTER 5. OTHERS 1-1. Specifi cations ...........................1-1 5-1. The Barcode Label ........................5-1 (to 1-1) 5-2. Replacing the CPU ........................5-2 (to 5-2) CHAPTER 2. BLOCK DIAGRAM ..................2-1 (to 2-1) CHAPTER 3. -
Page 4: Specifications
CHAPTER 1. SPECIFICATIONS 1-1. Specifi cations Model VGN-S73PB/B VGN-S53B/S VGN-S93PS/S∗ VGN-S93PSY∗ VGN-S93S/S∗ VGN-S460P/B VGN-S470P/S CelM/Do/360/1.40GHz or CelM/Do/360/1.40GHz or CelM/Do/360/1.40GHz or PM/Do/730/1.60GHz or PM/Do/730/1.60GHz or PM/Do/730/1.60GHz or PM/Do/750/1.86GHz PM/Do/730/1.60GHz PM/Do/740/1.73GHz PM/Do/740/1.73GHz PM/Do/750/1.86GHz or PM/Do/750/1.86GHz or PM/Do/750/1.86GHz or PM/Do/770/2.13GHz PM/Do/770/2.13GHz PM/Do/770/2.13GHz Chipset 915PM 915GM 915GM or 915PM... -
Page 5: Chapter 2. Block Diagram
CHAPTER 2. BLOCK DIAGRAM Port Replicatior VGN-S Series Main Unit Battery VGP-PRS2 DC Jack Power (6 cell) supply 16-19.5V Block_Diagram Dothan DC Jack PROCESSOR-M 19.5V ATF0 Clock DC/DC 13.3" XGA 478uFCPGA ADM1032 Gen. TMDS DVI-D (socket) LVDS Graphics PCI Express nVIDIA NV44M-V Microphone Alviso-GM... -
Page 6: Chapter 3. Frame Harness Diagram
CHAPTER 3. FRAME HARNESS DIAGRAM Side L MODEM MODEM CARD IFX-385 BOARD SIDE A AUDIO IN AUDIO OUT INVERTER HARNESS UNIT FFC (CNX-IFX) Rear SPEAKER SPEAKER Side R SWX-186 CNX-298 BOARD SIDE B BOARD SIDE B BLUETOOTH DC HARNESS MODULE COAXIAL CABLE IFX-331 CNX-299... -
Page 7: Chapter 4. Exploded Views And Parts List
Palmrest CHAPTER 4. Palmrest EXPLODED VIEWS AND PARTS LIST The parts list is compiled by blocks of a palmrest and bottom etc. The sections of the parts list are different depending on the model. Main Board Please refer to list of contents shown in the below. Main Board Section Page... - Page 8 P-1. Palmrest 10 ( 1) 1 The form and the printing of LED cover differs for every part number. 4-683-211-01 COVER LED 4-683-211-11/4-683-211-31 COVER LED Confidential VGN-S53B/S73PB/S93PS/S93PSY/S93S (J) VGN-S430P/S460/S460P/S470P/S480/S480B/S480P (AM)
- Page 9 P-1. Palmrest Ref. No. Part No. Description 1-830-252-12 CABLE, FLEXIBLE FLAT (10PIN) Ref.No. Part No. Description 1-830-252-41 CABLE, FLEXIBLE FLAT (10PIN) z z z z X-2025-555-2 ASSY PALMREST z z z z X-2048-845-2 ASSY PALMREST(SILVER) 1-829-195-11 CABLE, FLEXIBLE FLAT (12PIN) z z z z 4-683-211-31 COVER LED...
- Page 10 M-1. Main Board BT model only 335 ( 4) L-1, 2 ( 4) L-1, 2 L-1, 2 4 Ref. No. 333 and 335 are parts used only for Ref. No. 305: A-1124-111-A. Confidential VGN-S53B/S73PB/S93PS/S93PSY/S93S (J) Memory x2 model VGN-S430P/S460/S460P/S470P/S480/S480B/S480P (AM)
- Page 11 M-1. Main Board Ref. No. Part No. Description 4-662-881-02 CUSHION, KEY BOARD Ref.No. Part No. Description 4-672-493-01 COVER (SC) 1-805-554-21 BLUETOOTH MODULE z z z 1-829-369-11 CABLE, COAXIAL (WITH U.F.L CON) z z z 1-756-544-11 LITHIUM RECHARGEABLE BATTERY A-1124-110-A COMPLETE MBX-129 (EXT) (S) z z z z z z z z z A-1124-111-A...
- Page 12 B-1. Bottom BT model only L-1, 2 L-1, 2 L-1, 2 B11 ( 1, 2 ) B4 ( 3 ) 1 Since Ref No. B11 is special screw, one of the following special tools is needed for removal. 1022 DRIVER (H4M 6.0G), SPECIAL (Part No.: J-2507-713-1) BIT (H4, 6.0G), SPECIAL (Part No.: J-2507-712-1)
- Page 13 B-1. Bottom Ref. No. Part No. Description X-4626-768-2 ASSY ESCUTCHEON L Ref.No. Part No. Description X-2048-427-4 ASSY HOUSING BOTTOM X-2024-607-1 ASSY BEZEL OPT COMBO z z z z z z z X-2055-753-1 ASSY BEZEL OPT +-RW DL z z z z z z X-2048-428-1 &...
- Page 14 L-1. LCD 13.3-inch WXGA (Brighter) – Made by TO – 1017 1016 1019 1020 1010 1007 1022 1002 1015 1018 1013 1001 1011 1004 1008 1021 1023 1003 1006 1014 1009 1006 1005 1009 1012 1009 1005 Confidential VGN-S53B/S73PB/S93PS/S93PSY/S93S (J) VGN-S430P/S460/S460P/S470P/S480/S480B/S480P (AM)
- Page 15 L-1. LCD 13.3-inch WXGA (Brighter) – Made by TO – Ref. No. Part No. Description 4-662-881-02 CUSHION, KEY BOARD Ref.No. Part No. Description 1001 A-1072-481-A LCD UNIT(13.3 WXGA) (S) 1005 4-683-220-01 & COVER DISPLAY SCREW LO 4-683-220-11 & COVER DISPLAY SCREW LO z z z z * 1002 4-683-218-01...
- Page 16 L-2. LCD 13.3-inch WXGA (Brighter) – Made by SH – 1017 1016 1019 1020 1010 1007 1022 1002 1102 1018 1013 1101 1011 1004 1008 1021 1023 1003 1006 1014 1009 1006 1005 1009 1012 1009 1005 Confidential VGN-S53B/S73PB/S93PS/S93PSY/S93S (J) VGN-S430P/S460/S460P/S470P/S480/S480B/S480P (AM) 4-10...
- Page 17 L-2. LCD 13.3-inch WXGA (Brighter) – Made by SH – Ref. No. Part No. Description 4-662-881-02 CUSHION, KEY BOARD Ref.No. Part No. Description * 1002 4-683-218-01 BRACKET LCD L z z z 1005 4-683-220-01 & COVER DISPLAY SCREW LO 4-683-220-11 &...
- Page 18 L-3. LCD 13.3-inch WXGA 1017 1016 1019 1020 1010 1007 1022 1002 1015 1018 1013 1201 1011 1004 1008 1021 1023 1003 1006 1014 1009 1006 1005 1009 1012 1009 1005 Confidential VGN-S53B/S73PB/S93PS/S93PSY/S93S (J) VGN-S430P/S460/S460P/S470P/S480/S480B/S480P (AM) 4-12...
- Page 19 L-3. LCD 13.3-inch WXGA Ref. No. Part No. Description 4-662-881-02 CUSHION, KEY BOARD Ref.No. Part No. Description * 1002 4-683-218-01 BRACKET LCD L 1005 4-683-220-01 & COVER DISPLAY SCREW LO z z z 4-683-220-11 & COVER DISPLAY SCREW LO z z z * 1003 4-683-219-01 BRACKET LCD R...
- Page 20 A-1. Accessories 2001 AC Adaptor Ref.No. Part No. Description z z z z z z z 0 2001 1-479-114-23 & ADAPTOR, AC z z z z z 1-479-116-21 & AC ADAPTOR z z z z z 0 2003 A-1072-505-A $ &...
-
Page 21: Chapter 5. Others
CHAPTER 5. OTHER 5-1. The Barcode Label The hatched portion of the barcode is used as the repair data. [MBX-129 Board] [MBX-129 Board] [Drive] [HDD (FUJITSU)] (Side A) (Side B) (Rear) (Top) [W-LAN Card] [HDD (HITACHI)] (Top) (Top) [LCD Unit] [Keyboard Unit] [W-LAN Card] (Rear) -
Page 22: Replacing The Cpu
5-2. Replacing the CPU Note: We have two kinds of CPU for this set, and either of them is used. Two kinds of CPU have differences in the lock position and the unlock position. 1. Socket confi guration 1 2. Socket confi guration 2 1. - Page 23 VGN-S480∗ This manual and the constituent data may not be VGN-S480B∗ replicated, copied nor reprinted in whole or in part VGN-S480P∗ 9-876-417-XX without prior written authorization of Sony Corporation. ∗ : CTO Model : Additional Models English/Japanese 2005D0500-1 Sony Corporation 9-876-417-01 ©...
- Page 24 Revision History Suffi x Ver. Date Contents QM No. Ver. 1 2005.04.20 First Edition <Remarks> [Confi dential] VGN-S53B/S73PB/S93PS/S93PSY/S93S (J) VGN-S430P/S460/S460P/S470P/S480/S480B/S480P (AM)
