Dorel Ameriwood 9902202WY Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
A Dorel Company
MERIWOOD
INDUSTRIES
THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
TM
0
29986 99021
9902202WY
1
DO NOT RETURN PRODUCT TO THE STORE
STOP
Individual stores do not stock parts.
Date of Purchase
___ / ___ / ___
If a part is missing or damaged, visit our website or call our toll-free
customer service line. We will gladly ship your replacement parts
FREE of charge.
Need Parts or Assistance?
WWW.AMERIWOOD.COM/PARTS
For prompt, reliable service please have your assembly manual ready.
Recommended # of people needed for assembly: 1
(however it is always better to have an extra hand.)
Estimated assembly time is 1 hour.
Spanish translations are located in the center of this manual.
Se localizan las traducciones españolas en el centro de este
manual.
or call toll free:
1-800-489-3351
B349902202WY0 3

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ameriwood 9902202WY and is the answer not in the manual?

Questions and answers

Related Manuals for Dorel Ameriwood 9902202WY

Summary of Contents for Dorel Ameriwood 9902202WY

  • Page 1 9902202WY A Dorel Company MERIWOOD INDUSTRIES 29986 99021 DO NOT RETURN PRODUCT TO THE STORE STOP Individual stores do not stock parts. Date of Purchase ___ / ___ / ___ If a part is missing or damaged, visit our website or call our toll-free customer service line.
  • Page 3 Parts 2hutch backs 2 hutch dividers center hutch divider left hutch panel right hutch panel 39118202091 39118202080 39118202070 39118202050 39118202060 left upper crown molding front crown molding hutch fixed shelf 39118202240 39118202210 hutch top 39118202131 39902202120 right upper horizontal hutch molding upper back panel 2 vertical hutch moldings crown molding...
  • Page 4 Hardware This illustration shows how the CAM fastening system works. Esta ilustración muestra el sistema de fijación de leva y como funciona. 1/2" pan head nail screw angle bracket #A21110 #A12210 #A53600 Qty: 25 Qty: 30 HARDWARE COMPARTMENT Qty: 15 LAYOUT A22430 (X15) A21110 (X25)
  • Page 5 Insert two CAM LOCKS (6) into both of the HUTCH BACKS (I) as shown. Insert one CAM LOCK (6) and tap one COMPRESSION DOWEL (4) into the HUTCH DIVIDERS (G and H). 7/16" Approx. Proper orientation of CAM LOCK Posición correcta de la cerradura de leva B349902202WY0 3 5 /16...
  • Page 6 Insert four CAM LOCKS (6) into the HUTCH FIXED SHELF (M) as shown. Attach the HORIZONTAL HUTCH MOLDING (AA) to the HUTCH FIXED SHELF (M) with four ANGLE BRACKETS (3) and eight SCREWS (2). Molding (AA) is centered on Shelf (M) as shown below. 35 (1-3/8") 35 (1-3/8") ASSEMBLED VIEW...

  • Page 7: Assembled View

    Insert two CAM LOCKS (6) and screw two CAM BOLTS (7) into the LEFT HUTCH PANEL (E) as shown. Attach the VERTICAL HUTCH MOLDING (Z) to the LEFT HUTCH PANEL (E) with three ANGLE BRACKETS (3) and six SCREWS (2). Do not tighten the angle bracket screws. Tighten these screws in later steps after adjustments are made. ASSEMBLED VIEW flush at this end VISTA DEL ENSAMBLAJE...
  • Page 8 Insert two CAM LOCKS (6) and screw two CAM BOLTS (7) into the RIGHT HUTCH PANEL (F) as shown. Attach the VERTICAL HUTCH MOLDING (Z) to the RIGHT HUTCH PANEL (F) with three ANGLE BRACKETS (3) and six SCREWS (2). Do not tighten the angle bracket screws. Tighten these screws in later steps after adjustments are made. ASSEMBLED VIEW Flush at this end.
  • Page 9 Screw eleven CAM BOLTS (7) into the HUTCH TOP (L). Attach the FRONT CROWN MOLDING (U) to the HUTCH TOP (L) with five ANGLE BRACKETS (3) and ten SCREWS (2). DO NOT TIGHTEN UNTIL STEP 9 NO AJUSTE HASTA LLEGAR AL PASO 9 x 10 x 11 B349902202WY0 3...
  • Page 10 Align the HUTCH DIVIDERS (G and H) with the HUTCH TOP (L) so that the CAM BOLTS (7) insert into the CAM LOCKS (6). Turn the CAM LOCKS (6) clockwise to lock in place. Align the HUTCH BACKS (I) with the HUTCH TOP (L) so that the CAM BOLTS (7) insert into the CAM LOCKS (6).
  • Page 11 Align the HUTCH PANELS (E and F) with the HUTCH FIXED SHELF (M) so that the CAM BOLTS (7) insert into the CAM LOCKS (6). Turn the CAM LOCKS (6) clockwise to lock in place. LOCK UNLOCK APRETAR DESAPRETAR B349902202WY0 3 11 /16...
  • Page 12 With assistance of another person align the HUTCH PANELS (E and F) with the HUTCH TOP (L) so that the CAM BOLTS (7) insert into the CAM LOCKS (6). Turn the CAM LOCKS (6) clockwise to lock in place. Secure the HUTCH FIXED SHELF (M) to the HUTCH DIVIDERS (G and H) and the HUTCH BACKS (I) with ten SCREWS (8). Attach the LEFT UPPER CROWN MOLDING (X) to the LEFT HUTCH PANEL (E) with two SCREWS (5).
  • Page 13 With assistance of another person, carefully turn the unit over NOTE: You need to use a 3/16" diameter drill onto the finished edges. Position the UPPER BACK PANEL bit and make the four holes depicted below (TT) as shown. One person needs to hold up the bottom edge into through holes.
  • Page 14 The hutch is now ready to attach to the desk. Assemble the desk up to this point of assembly (step 10 of the desk assembly). With assistance of another person, carefully position the hutch and desk as shown. Align the left and right assemblies with the DESK TOP (K) so that the CAM BOLTS (7) insert into the CAM LOCKS (6). Turn the CAM LOCKS (6) clockwise to lock in place.
  • Page 15 With assistance of another person, carefully stand the unit upright. Attach the LEFT LOWER BACK (RR) and RIGHT LOWER BACK (SS) using the thirty-six nails (16) from the desk (9151202W) hardware bag. Use five nails (1) to fasten the Hutch Back Panel to the rear edge of the Desk Top (K).
  • Page 16 Visit our Website or call our toll free number for any assistance you should need: www.Ameriwood.com/parts 1-800-489-3351 Clean the product with your favorite furniture polish and a soft cloth. DO 10 lbs. NOT USE harsh chemicals or abrasive cleaners. 4.53 kg. Move your new furniture carefully with two people.
