Verano Pergola 10x10 ft
ASSEMBLY INSTRUCTION
ITEM#:L-PG108PST-B
SKU#810326090
If you have any issues with the product,do not return
the product back to the store
For any questions or issues about our product
Call Sunjoy Customer Service
1(866) 578-6569
8:00 AM EST – 8:00 PM PST
For further assistance,please write to us at
biglots@sunjoygroup.com
Country of Origin: China
Production number:xxxxxxxx
Advertisement
Table of Contents
Related Manuals for Sunjoy Verano L-PG108PST-B
Summary of Contents for Sunjoy Verano L-PG108PST-B
- Page 1 If you have any issues with the product,do not return the product back to the store For any questions or issues about our product Call Sunjoy Customer Service 1(866) 578-6569 8:00 AM EST – 8:00 PM PST For further assistance,please write to us at biglots@sunjoygroup.com...
-
Page 2: Safety Information
2 / 23 Safety Information This unit is heavy! Do not assemble DANGER: Two people are required for this assembly. Some parts may contain sharp edges. Wear this item alone. protective gloves. Do not leave the gazebo where there WARNING: When assembling and using this product, basic safety precautions should always be... -
Page 3: Tools Needed
3 / 23 TOOLS NEEDED Provided in hardware pack IMPORTANT How many people needed for the installation work Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com... -
Page 4: Exploded Drawing
4 / 23 EXPLODED DRAWING Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com... - Page 5 5 / 23 Parts List Label Part Number Description Part Image Top Beam 1 P12701A01101 P12702A01101 Top Beam 2 Top Arc Beam 1 P11001B01101 Top Arc Beam 2 P11002B01101 Top Arc Beam P11401A01101 Connector Support Beam 1 P11005A01101 Support Beam 2 P11006A01101 Crossbeam Decoration P10001B01101...
- Page 6 6 / 23 Long Arc Support 2 P11804C01101 Fabric Tube Connector P11401B01101 Rail Tube Connector 1 P11402B01101 Rail Tube Connector 2 P11403B01101 Rail Tube Connector 3 P11404B01101 Fabric Tube 1 P12801A01101 Fabric Tube 2 P12802A01101 Rail Tube P12803A01101 Canopy P00101N07011 Country of Origin: China Call 1(866) 578-6569 for assistance.
-
Page 7: Hardware Pack
7 / 23 Hardware Pack Label Part Number Description Part Image H02015C11 Bolt M6*15 Actual Size Flat Washer M6 H19001C11 （Large） Actual Size H02045C11 Bolt M6*45 Actual Size H09015C11 Bolt M6*15 Actual Size H09070C11 Bolt M6*70 Actual Size H09045C11 Bolt M6*45 Actual Size P12401A01 Stake ￠8*180... - Page 8 8 / 23 STEP 1:Assembly of Base and Base Cover P11502A01101 P11602A01101 P11102A01101 P11103A01101 Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
- Page 9 9 / 23 STEP 2:Assembly of Crossbeam Decoration and Post Decoration P10001B01101 P10002B01101 P10901A01101 Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
- Page 10 10 / 23 STEP 3:Assembly of Top Arc Beam P11001B01101 P11002B01101 P11401A01101 Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
- Page 11 11 / 23 STEP 4:Assembly of Support Beam P11005A01101 P11006A01101 Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
- Page 12 12 / 23 STEP 5:Assembly of Support Beam and Post Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
- Page 13 13 / 23 STEP 6:Assembly of Top Arc Beam and Post Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
- Page 14 14 / 23 STEP 7:Assembly of Arc Support P11803C01101 P11804C01101 P11802C01101 P11801C01101 Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
- Page 15 15 / 23 STEP 8:Assembly of Rail Tube P12803A01101 P11403B01101 P11404B01101 P11402B01101 P11401B01101 Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
- Page 16 16 / 23 STEP 9:Assembly of Top Beam P12702A01101 P12701A01101 Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
- Page 17 17 / 23 STEP 10:Assembly of Top Beam Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
- Page 18 18 / 23 STEP 11:Assembly of Canopy P00101N07011 Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
- Page 19 19 / 23 STEP 12:Assembly of Fabric Tube P12802A01101 P12801A01101 Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
- Page 20 20 / 23 STEP 13:Assembly of Fabric Tube and Canopy Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
- Page 21 21 / 23 STEP 14:Assembly of Stake Country of Origin: China Call 1(866) 578-6569 for assistance. Or visit us at www.sunjoyonline.com...
-
Page 22: Care And Maintenance
Periodically check and ensure that all bolts are well-tighten during use Limited Manufacturer’s Warranty Sunjoy Group warrants to the original purchaser that this item is free from defects in workmanship and materials for a period of 1 year from the date of purchase, provided the item was factory-sealed at the time of purchase and is maintained with care and used only for personal, residential purposes. - Page 23 23 / 23 Maintenance and Care of your Canvas Canopy: While the canvas canopy is extremely durable and water repellant. The Summerhouse Pergola is recommended for shade and shelter from the sun in addition to *light rain and wind. Please use good judgment, as the elements and seasons vary from region to region. It is recommended to remove the canopy top when: ...
