Summary of Contents for Jugee R05BP400S20-2200
- Page 1 User Manual Applicable Battery Models： R05BP400S20-2200 R05BP405S20-3000 R05BP405S35-3000 R05BP410S35-3000 R05BP405D35-3500 Applicable Charger Models： CUA52 CUC54 Read instruction carefully before use...
-
Page 2: Table Of Contents
Table of Contents 1. Safety ................ 5 2. Special Notes ............6 3. First Time Use ............7 4. Battery Discharge ............ 10 4.1. 1.5V Constant Voltage Discharge ...... 10 4.2. Low Voltage Warning ......... 10 4.3. Usable discharged energy ......... 11 4.4. - Page 3 5.2. Use with a USB 5V power source ...... 18 5.3. Charging from a computer USB port....19 5.4. Under temperature charging ......20 5.5. LED Indicator of Charging status ....... 20 5.6. Charging Characteristics ........21 5.7. Charging Temperature Protection ..... 23 5.8.
- Page 4 9.5. Jugee Charger Operational Characteristics ..45 9.6. Charger Fault Indicator ........46 Appendix 1: Quick Index ..........48 Appendix 2: Battery Rating mWh and mAh Differences . 49 Appendix 3: Estimate Jugee Battery Charge / Discharge 50 Appendix 4: Intellectual Properties ....... 52...
- Page 5 Appendix 5: Product Certifications ........ 53 EN5C3W0 Specifications ..........55 EN7C1W0 Specifications ..........56 CUA51 Specifications ......错误!未定义书签。 CUA52 Specifications ............. 57 CUA72 Specifications ......错误!未定义书签。 CUM52 Specifications ............ 57...
-
Page 6: Safety
1.5. It is prohibited to charge or use the battery in or near inflammable, explosive or corrosive environment. 1.6. It is prohibited to mix the use of Jugee battery with other type batteries, doing so can damage Jugee or other batteries, and may lead to serious consequences such as battery leakage, fire and even explosion. -
Page 7: Special Notes
1.8. Please observe polarity signs when using Jugee with electrical product, as mistakes may damage the battery and / or the product. 1.9. Jugee battery and charger are not suitable for use in high- power underwater or other sealed equipment, nor inside of high-power electrical equipment. -
Page 8: First Time Use
High power products that drain 1.5V alkaline batteries within 0.5 hour. 2.2. For easy understanding and reference, usage and specific guidelines of Jugee battery and charger will be given in detail in sections related to these applications. Please refer to these for details. - Page 9 (1.1V) or zero voltage state after some battery unpacking. 3.3. There are no special requirements for first charge or use of Jugee battery, and any of the following practice is acceptable: Jugee battery does not need to be charged full, and can be taken out to use any point during charging.
- Page 10 This must be removed to allow before charging can proceed. 3.5. If Jugee battery is to be left idle some time, please follow instructions in Chapter 7 pertinent to “Battery Long Term Storage and Maintenance.
-
Page 11: Battery Discharge
“as fresh”. 4.2. Low Voltage Warning Jugee battery will lower output voltage to 1.1V when its internal energy is nearly depleted, as a signal in order to avoid sudden power cut without warning. -
Page 12: Usable Discharged Energy
4.3. Usable discharged energy Jugee battery capacity rated in accordance with the “5- hour discharge method”, a standard adopted in China and internationally. Below is table of measured energy using this method for different Jugee battery models: Rated Battery Model Min. -
Page 13: Over-Discharge Protection
This is a normal for battery in over-discharge protection. 4.5. Timely Recharge After Depletion The Jugee battery is exhausted or stored in a depleted state. It is best to charge it within 10 days after the battery is discharged. The maximum length is not recommended for more than 30 days to avoid damage to the battery and affect the use of the battery. -
Page 14: Over-Current Protection And Reverse Polarity By
⚫ Attention: Serial connection of cells of different state of charge or relative age is limited to Jugee battery models listed in this manual, namely EN5C3W0 and EN7C1W0. It is not permitted to mix Jugee batteries with other makes of batteries, or... -
Page 15: Discharge Overload Or Short-Circuit Protection
Jugee batteries or the other cells can be caused. Jugee battery in depletion shut-off mode does not have active over-current or over-temperature protection. It is therefore necessary to limit working current of series string to 1A. 4.7. Discharge overload or short-circuit protection:... -
Page 16: Discharge Temperature Protection
~ - 30℃. ⚫ Note: Do not store or use Jugee battery in environment of temperature higher than 60℃ (e.g. inside of a car on a summer day) or lower than -30℃, to avoid damages to the battery. - Page 17 Take the 4-cell Jugee battery in series as an example. After any one of the batteries is exhausted, the output voltage of the series battery pack is: 1.5*4- 1.5-0.4=4.1V...
-
Page 18: Discharging In Parallel
4.10. Discharging in parallel When multiple Jugee batteries are connected in parallel, current will never flow from batteries of higher remaining charge to lower ones (even when batteries operate in 1.5V and 1.1V modes co-exist). However, energy released or discharging power of individual batteries in the group... -
Page 19: Charging The Battery
⚫ Notes: The Jugee battery of the model listed in this manual can also be charged using MILBEP's old 4-cell charger (CUM54). It should be noted that the charging time of the old charger may be longer, and may be accompanied by the phenomenon that the battery LED indicator flickers at a low frequency. -
Page 20: Charging From A Computer Usb Port
When charging from USB port with any Jugee charger, use the following guideline to determine the number of Jugee batteries that can be charged at the same time: For USB port V1.0 or lower, 1 type AA batteries; For USB port V2.0 or higher, 2 type AA batteries;... -
Page 21: Under Temperature Charging
Long-term use in low temperature environment will still affect the life of Jugee battery. Therefore, users should try to avoid charging in the environment below 0 °C. 5.5. LED Indicator of Charging status On Jugee battery positive end there is a charging status LED. -
Page 22: Charging Characteristics
If above mentioned b), c) state occur, it suggests that Jugee battery is in Protection Charging. Please consult Chapter 6 Battery Charging Protection for possible solutions. If condition e) should occur, the Jugee charger is in Protection mode. Please check solutions in sections 9.6 or 9.3. - Page 23 The amount of discharge available is the same as the amount charged into the battery. A Jugee battery can be charged at any stage of use of storage, with any amount of remaining charge, without...
-
Page 24: Charging Temperature Protection
1 day of standard wireless keyboard or mouse; 2 days or more of a remote control handset. 5.7. Charging Temperature Protection Jugee battery has over-heating protection capability against possible damages caused to the lithium-ion core during charging. Overheat... -
Page 25: Charging Under-Power Protection
When used with a USB 5V power source having a current output rating lower than the combined charging current Jugee batteries in the charger, these batteries may activate under-power protection mode, indicated by the blinking LED on the batteries. -
Page 26: Factors Affecting Charging Speed
Always try to use USB 5V power sources that meet the requirements outlined in Section 5.2, to avoid the activation of under-power protection, which will slow down charging. Always try to charge the Jugee batteries in a well- conditioned environment with good ventilation and heat dissipation ⚫... -
Page 27: Full Charge Time
5.12. Battery LED On for Too Long Jugee battery LED will be on during charging under 30℃. It is abnormal if the LED is still on after 4 hours. It is recommended to take Jugee battery out of charger, lay idle for 5 minutes, and inserted back to charger by itself. - Page 28 Battery should complete a full charge under 2 hours. If not, please consult Chapter 6.6 to determine the cause. ⚫ Note: A number of reasons could cause prolonged charging, for instances, battery repairs trickle charge, under-power protection, over-heating protection, intermittent power shutdown etc.
-
Page 29: Battery Charging Protection
6.1. Battery Charge Protection Type Indication Jugee battery has multiple protection modes such as: under-power protection, over-temperature protection, battery core fault protection, battery core failure protection. A battery is in protective mode when its LED indicator blinks. -
Page 30: Blinking Immediately Upon Charging
Select a USB 5V power source that is able to charge standard cell phone. Connect empty charger and observe the green indicator on. Insert a Jugee battery that was blinking, observe which of the following situation occurs, and follow the suggested actions:... - Page 31 If the second battery also blinks, then likely the charger or the power source cable could be faulty. Please follow instruction in Section 6.5. If the charger is the problem, please stop using it and contact your retailer or Jugee Customer Service. ⚫ Note: Jugee battery charging current is reduced below rated level when its remaining charge is above 85%.
-
Page 32: Blinking After Charging Some Time
6.3. Blinking After Charging Some Time When a Jugee battery LED is long on at the start of charging, and then goes into blinking after some time, the battery is in charge over-temperature protection mode. Battery can still continue and complete charging under temperature protection, but charge speed will be reduced. -
Page 33: Blinking After Charging Over Time
20%. 6.4. Blinking After Charging Over Time When a Jugee battery LED is long on at the start of charging, and then goes into blinking after 4 hours charging, take the battery out of charger, wait for 5 minutes, and then place it back to charger alone. -
Page 34: Under Power Protection Remedies
After re-insertion, the battery LED immediately starts blinking, then follow instructions in Section 6.2. If the USB 5V adaptor, charger and charger cables are verified to function properly, then go to Section 6.6. 6.5. Under Power Protection Remedies Under power conditions occurs when power supply current is lower than the required battery charging current. -
Page 35: Indicators Of Battery Fault Or Degradation
Select a USB 5V adaptor that can charge cells phones normally to power the Jugee charger, place one fully depleted Jugee battery into charger, and if the LED is long on, use this adaptor for testing other suspected faulty HUJEE batteries. - Page 36 Jugee battery after-sales service consultation. ⚫ Note: The Jugee charger selected in step A should be compatible with the suspected faulty battery, and the charger cable and USB 5V adaptor must have ratings higher than battery rated charging current.
-
Page 37: Long Term Storage And Maintenance
Long Term Storage Maintenance If Jugee battery is temporary unused and stored away, please follow storage and maintenance instructions in this section to avoid damages to the battery. 7.1. Preparation and Storage Conditions Jugee battery must be fully charged before storage. -
Page 38: Battery Care During Storage
7.2. Battery Care During Storage If Jugee battery need to be stored for longer than the allowed period, then recharging must be one before the end of the period, to extend the storage period counting from the recharging day. ⚫... -
Page 39: Battery Usage And Maintenance
LED is still flashing, it means that the battery core is depleted and cannot be repaired. If this happens, please do not use it again, and contact the dealer or Jugee battery after-sales service consultation. Battery Usage Maintenance After careful reading sections of this Manual, and under... - Page 40 Can release all stored energy, hence a high actual usable energy output; Can mix use batteries of different types of batteries, old and new batteries, charge the battery with different power. Output maximum current under short-circuit or over-load conditions; Can charge at any time irrespective of remaining charge;...
-
Page 41: Charge / Discharge Precautions
8.2. Charge / Discharge Precautions Caution! Please follow the instructions below carefully when using Jugee battery, to ensure proper performance and longevity. Always follow the safety guidelines of Chapter 1; Charge battery when depleted, according to Section 4.5; Follow storage and maintenance instructions of Chapter 7;... - Page 42 Store battery for no longer than 70% of the Permissible longest storage period; Use battery in temperatures -10℃～30℃; Charge battery in temperatures 10℃～30℃; Keep the positive and negative contacts clean’...
-
Page 43: Jugee Charger
9.1. Select Suitable USB 5V Power Adaptor Jugee chargers should be used with USB 5V adaptors for the following description: For AA Chargers: Select USB 5V power adaptor with rated current above # of charge slots X 0.7A. -
Page 44: Use Usb Ports Of Computer
When using multi-slot Jugee charger with USB port on PC, please note the number of Jugee batteries being charged should follow the following guidelines: For USB port lower than USB2.0: 1 AA type of Jugee batteries; For USB port USB2.0 or higher: 2 AA type of Jugee batteries;... -
Page 45: Charging Thermal Management
Once in lock protection mode, Jugee charger must be powered off, and all batteries removed, leave for 2 seconds before power on again, for the lock protection to be reset and resume normal operation. -
Page 46: Jugee Charger Operational Characteristics
Do not place the charger on top of heater, radiator or electric appliances; 9.5. Jugee Charger Operational Characteristics Jugee charger has built-in MILBEP battery compatible control system, and exhibits the following operation characteristics: Charger LED status indicator will show GREEN upon power on indicating normal, and turns RED when it is in protective modes. -
Page 47: Charger Fault Indicator
2 seconds and re-power to restore normal charging operation. 9.6. Charger Fault Indicator If Jugee charger status LED shows RED upon power on, with no battery inserted, it is in protection mode. Causes for protection modes include: USB 5V adaptor has output voltage is too high, charger was damp or submersed, charger has been damaged by force etc.. - Page 48 Jugee USB 5V connector is compliant to the USB standard, and can be damaged by high voltage.
-
Page 49: Appendix 1: Quick Index
Rated Battery Charge to Full Time 5.10 Battery LED Blinking During Charging Charger LED on l\Long RED 9.3, 9.6 Inserting and Removing Battery from Charger Interchangeability of Jugee Charger and Battery Models Maximum Permissible Battery Storage Period Customer Service Contacts... -
Page 50: Appendix 2: Battery Rating Mwh And Mah Differences
One unit of electricity is sometime used to denote 1 kWh = 1,000 Wh = 100,000mWh. Jugee battery is a constant voltate source, and therefore it is suitable to use mWh as a unit to measure its energy storage and release when a user tries to gage its energy actual performance. -
Page 51: Appendix 3: Estimate Jugee Battery Charge / Discharge
Example of Working Hour Estimate Suppose an electric shaver has rated working voltage 3V, and rated power of 1.5W, and 2 fully charged Jugee AA 3000mWh batteries are used to power it. Shaver Working Current Calculation 1.5W / 3V = 0.5A = 500mA, less than 600 mA. - Page 52 3 minutes, the batteries can support 80 days of use. Battery Charging Energy Consumption If a Jugee charger is used to charge 4 depleted Jugee batteries, the following is calculation of electricity consumed to charge them to full: Batteries absorb 4 x 3000mWh = 12Wh.
-
Page 53: Appendix 4: Intellectual Properties
Appendix 4: Intellectual Properties Jugee products and related technology have applied for patent protection in China, USA, European Union, Japan, South Korea, and is protected by applicable IP laws of these countries or regions. Granted patents in China: ZL201110219892.0 ZL201310436748.1 ZL201310436714.2... -
Page 54: Appendix 5: Product Certifications
Appendix 5: Product Certifications EN5C3W0&EN7C1W0 have passed various 3 party certifications: Lithium Battery Core Safety Certification UL 1462 IEC 62133 GB31241-2014 Transportation Safety Certification UN 38.3 EU Battery Directive: 2013/56/EU MSDS USA FCC (Part 15 Subpart B) EU: EN55032, EN55024... - Page 55 Jugee Battery Common Specifications R05BP400S20-2200 R05BP405S20-3000 Applicable Models R05BP405S35-3000, R05BP410S35-3000 R05BP405D35-3500 Rated Discharge Voltage 1.5V ±2% (Iout≤1.0A) Low SoC Output Voltage 1.1V ±2% (Iout≤0.5A） Low SoC Threshold 1%～2.4% (0.2C, 25℃） ≤20mVp-p (Iout≤1.0A） Discharge Voltage Ripple Discharge Max Current 2.5A ±25% Max Continuation Current 1.5A (Max)
-
Page 56: En5C3W0 Specifications
R05BP405S20-3000/R05BP405S35- 3000/R05BP410S35-3000 Specifications 5 号/AA/R6 Product Type Li-Ion Battery Core 900mAh, 3.8V Rated Capacity 2000mAh (0.2C, CC) Rated Discharge Energy 3000mWh (0.2C, CC) Minimum Discharge Energy 2900mWh (0.2C, CC) Rated Discharge Current 600mA (BET) Maximum Constant Voltage 2000mA (Max) Discharge Current Permissible Recharge Wait... -
Page 57: En7C1W0 Specifications
R05BP400S20-2200 Specifications 5 号/AA/R6 Product Type Li-Ion Battery Core 650mAh，3.7V Rated Capacity 1467mAh（0.2C，CC） Rated Discharge Energy 2200mWh（0.2C，CC） Minimum Discharge Energy 2100mWh（0.2C，CC） Rated Discharge Current 400mA（BET） Maximum Constant Voltage 2000mA（max） Discharge Current Permissible Recharge Wait 10 Days (Max) Time After Depletion... -
Page 58: Cua52 Specifications
CUA52 Specifications Charging Slots 2 X AA Type Suitable Battery Type MILBEP Rated Input Voltage DC 5.2V±0.5V Adaptor Output 1.5A ≥ Current Charging Ambient -20℃～35℃ Temperature Charger Specifications MILBEP 2.0 Executed Standard GB 4706.18-2014 CUC54 Specifications Charging Slots 4 X AA Type Suitable Battery Type MILBEP Rated Input Voltage... - Page 59 Embedded Battery Management technology Shenzhen Jugeestar Technology Co. Ltd. Floor, Building C, Haikexing Industrial Address: 3 Park, Pingshan New District, Shenzhen, China. Tel: 400-895-8820 Email: Sales@Jugee.com www.Jugee.com...
