PRODUCT NAME: UMBRELLA CANOPY & FRAME
ITEM NUMBER: FO062
DIMENSIONS OF ITEM ASSEMBLED: 9' DIAMETER
REPLACEMENT CANOPIES ALSO SOLD SEPARATELY (FO026)
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
WARNING: We recommend that you always close and tie the ropes around your
umbrella in windy conditions as well as when not in use to avoid damage to your
umbrella frame and table top. Always secure umbrellas in at least a 50 lb. umbrella
base. WIND DAMAGE is NOT COVERED under any umbrella warranty.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
Page 1 of 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FO062 and is the answer not in the manual?

Questions and answers

Related Manuals for Ballard Designs FO062

Summary of Contents for Ballard Designs FO062

  • Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: UMBRELLA CANOPY & FRAME ITEM NUMBER: FO062 DIMENSIONS OF ITEM ASSEMBLED: 9’ DIAMETER REPLACEMENT CANOPIES ALSO SOLD SEPARATELY (FO026) WARNING: We recommend that you always close and tie the ropes around your umbrella in windy conditions as well as when not in use to avoid damage to your umbrella frame and table top.
  • Page 2 Attaching Canopy STEP 1: With the frame closed, unscrew finial counter clockwise from top Finial STEP 2: Slide canopy over top of frame. Line up the metal ring in the canopy top to the extrusion in the top of the frame. Then pull canopy over frame. Frame Metal Ring in Canopy...
  • Page 3 Removing Canopy STEP 1: Wind the umbrella to the closed position. STEP 2: Unscrew finial counter clockwise from top of the umbrella frame. Finial Metal Ring in Canopy STEP 3: Gently pull downwards on the arm pockets, removing the canopy from the frame (total of 8 arms). Arm of Frame Arm of Frame Arm Pocket...
  • Page 4 Instructions for working the umbrella To Open: When the umbrella is closed, crank the handle clockwise until umbrella is extended to desired height. clockwise counter clockwise To engage Tilt: Once the umbrella is open, keep cranking clockwise & the umbrella will begin to tilt. Stop cranking the handle once you have reached the desired tilt.
