Summary of Contents for Best Choice Products SKY2856
- Page 1 INSTRUCTION MANUAL Ride-On Truck with Remote SKY2856 + SKY2857 + SKY2858 + SKY5164 + SKY5165 + SKY5166 Ver. 8...
- Page 2 Charge for 12 hrs before initial use. After initial charge, follow the normal recommended charging time. bestchoiceproducts.com...
- Page 3 Before assembly, remove the rear axle from under the ride-on. This is step 1 of the instructions. bestchoiceproducts.com...
-
Page 4: Battery Warnings
SAFETY Please retain these instructions for future reference. This vehicle must be assembled by an adult who has read and understood the instructions in this manual. Keep the packaging and bags away from children and dispose of all packaging before use. Always use common sense and safe practices when operating this vehicle. -
Page 5: Specifications
WARNING To reduce the risk of injury, adult supervision is required. Never use on roadways, near motor vehicles, on or near steep inclines or steps, swimming pools or other bodies of water; always wear shoes, and never allow more than one rider. •... -
Page 6: Tools Required
TOOLS REQUIRED PHILLIPS 2 PLASTIC 65 LBS 1 PERSON APPROXIMATELY SCREWDRIVER WRENCH ASSEMBLY 1 HR. CAPACITY (PROVIDED) ASSEMBLY HARDWARE M4 x 12mm M3 x 12mm SCREW SCREW 12 PCS 2 PCS PARTS REAR AXLE REAR WHEEL FRONT WHEEL 1 PC 2 PCS 2 PCS HUB CAP... -
Page 7: California Proposition
PARTS HOOK WINDSHIELD SIDE MIRROR 1 PC 1 PC 2 PCS SEAT FRONT AXLE STEERING WHEEL 1 PC 1 PC 1 PC FRONT REFLECTOR REMOTE CONTROL CHARGER 2 PCS 1 PC 1 PC CALIFORNIA PROPOSITION 65 WARNING: Battery posts, terminals, and related accessories can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm, and are toxic and corrosive. -
Page 8: Product Assembly
PRODUCT ASSEMBLY FRONT REAR Flip the vehicle over and lay it on a level surface. Remove nuts and washers from the part A rear axle underneath the vehicle, then remove the axle. GEAR BOX STABILIZER Remove packaging from gear boxes Remove packaging from gear boxes and place them in position. - Page 9 PRODUCT ASSEMBLY SHOCK Line up the holes on the stabilizer with the shocks, then slide the part A rear axle through. Replace the two bolts/nuts on the stabilizer to secure the axle. Slide the gear boxes onto the rear axle. Insert the ends of the gear boxes into the designated slots.
- Page 10 PRODUCT ASSEMBLY Slide a part B rear wheel onto the axle and replace a nut and washer to secure the wheel. Repeat on the other side. Snap a part D hub cap onto each wheel. Use the provided plastic wrench to attach the nuts.
- Page 11 TOOLS REQUIRED PRODUCT ASSEMBLY Remove a nut and washer from each side of the Use the provided front axle (leave a washer on each side). plastic wrench to attach the nuts. Slide a part C front wheel onto the axle and replace a nut and washer to secure the wheel.
- Page 12 PRODUCT ASSEMBLY Join the connector from the part L steering wheel to the connector from the steering mount, then snap the steering wheel into place. Secure the part G hook to the rear of the vehicle with two part 1 screws. 12 |...
- Page 13 PRODUCT ASSEMBLY Insert the two part E frame pieces into the designated holes on the rear of the vehicle. Slide the part F bar light into the holes located on the frame pieces and secure it with two part 2 screws.
- Page 14 PRODUCT ASSEMBLY Snap on the part H windshield. Snap on two part I side mirrors.
- Page 15 TOOLS REQUIRED PRODUCT ASSEMBLY...
- Page 16 TOOLS REQUIRED PRODUCT ASSEMBLY Slide the two part M front reflectors onto the front of the vehicle and they will snap in place. TOOLS REQUIRED PRODUCT ASSEMBLY Under the hood, connect the red wire to the red terminal on the battery SPEAKER CONTROL MODULE...
- Page 17 DASHBOARD DIAGRAM FORWARD: DRIVE FORWARD POWER SWITCH PEDAL PARK: PARK VEHICLE BATTERY CHARGING (PEDAL IS DISABLED) SOCKET LIGHT SWITCH REVERSE: DRIVE IN REVERSE Push down on the pedal to drive forward/reverse. Release the pedal to slow down and stop. MP3 FUNCTIONS USB port: play music from a USB drive •...
-
Page 18: Remote Control Diagram
REMOTE CONTROL DIAGRAM FREQUENCY KEY TURN LEFT FORWARD TURN RIGHT EMERGENCY HIGH-SPEED LED BRAKE MEDIUM-SPEED LED REVERSE LOW-SPEED LED SPEED • Insert 2 AAA batteries into the remote control • After 10 seconds of non-operation, the indicator light will turn o and the remote will go into power-saving mode. -
Page 19: Troubleshooting
TROUBLESHOOTING Problem Reason Solution Fully charge the battery Low battery Stop use for several minutes and restart Electrical protection Vehicle does not move Switch not in the correct position Completely press in switches Plug in battery connectors Battery connectors disconnected Battery connectors disconnected Plug in battery connectors Battery does not recharge... -
Page 20: Help Center
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If the reason for return is a result of an error by Best Choice Products then Best Choice Products will provide a pre-paid shipping label via email. Boxes for return shipping will not be provided by Best Choice Products, and is the customer’s responsibility to either use the original shipping boxes or purchase new boxes.
