Page 1
Eight screws to secure the chassis and mounting-blades to the rack (not provided) Screwdriver appropriate for your rack-mounting screws (not provided) Two power cords with plugs appropriate for your geographical location (provided, for all EX4600 switches except the EX4600-40F-S switch.
Page 2
EX4600-40F-S switches are not shipped with fan modules or power supplies. Register product serial numbers on the Juniper Networks website and update the installation base data if there is any addition or change to the installation base or if the installation base is moved. Juniper Networks will not be held accountable for not meeting the hardware replacement service-level agreement for products that do not have registered serial numbers or accurate installation base data.
Page 3
The switch weighs approximately 21.4 lb (9.7 kg). Installing the EX4600 switch in a rack or cabinet requires two people; one person to lift the switch while the other secures it to the rack.
Page 4
3. Align the holes in the side mounting-rail with the holes on the side of the chassis. 4. Attach the side mounting-rail to the switch using six mounting screws. Use cage nuts and washers if your rack requires them. 5. Repeat Step 3 and Step 4 on the opposite side of the switch. 6.
Page 5
Connecting EX4600 to AC power | 5 Connecting EX4600 to DC power | 5 All EX4600 switches, except the EX4600-40F-S switch, are supplied with two factory-installed power supplies and power cords. Order separate power cords for the EX4600-40F-S. Connecting EX4600 to AC power To connect power to an AC-powered switch: 1.
CAUTION: There is no standard color coding for DC power cables. The color coding used by the external DC power source at your site determines the color coding for the leads on the power cables that attach to the DC power input terminals on each power supply. 3.
Set Parameter Values You must perform the initial configuration of the switch through the console port. Before you begin, set the following parameter values in the console server or PC: Baud Rate—9600 Flow Control—None Data—8 Parity—None Stop Bits—1 DCD State—Disregard Perform the Initial Configuration To connect and configure the switch from the console: 1.
Page 8
0 family inet address address/prefix-length NOTE: The management ports, em0 (C0) and em1 (C1), are found on the FRU side of the EX4600 switch. 9. (Optional) Configure the static routes to remote prefixes with access to the management port.
Contacting Juniper Networks | 10 See the complete EX4600 documentation at https://www.juniper.net/documentation/product/en_US/ex4600. Safety Warnings Summary This is a summary of safety warnings. For a complete list of warnings, including translations, see the EX4600 documentation at https://www.juniper.net/documentation/product/en_US/ex4600. WARNING: Failure to observe these safety warnings can result in personal injury or death.
For technical support, see: http://www.juniper.net/support/requesting-support.html Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners.
