53-1002177-19 Hardware Installation Guide
Description
mSFP LC - standard LC,
duplex, multi-mode, OM3,
50/125
Patch cables - mSFP to
mSFP
mSFP LC - mSFP LC,
duplex, multi-mode, OM3,
50/125
mSFP LC - mSFP LC,
duplex, multi-mode, OM3,
50/125
mSFP LC - mSFP LC,
duplex, multi-mode, OM3,
50/125
mSFP LC - mSFP LC,
duplex, multi-mode, OM3,
50/125
mSFP LC - mSFP LC,
duplex, multi-mode, OM3,
50/125
Trunk cables - mSFP to
MTP
mSFP LC - MTP-female,
12 fiber, 12" breakout,
OM3, 50/125
mSFP LC - MTP-female,
12 fiber, 6" breakout,
OM3, 50/125
mSFP LC - MTP-female,
24 fiber, 12" breakout,
OM3, 50/125
Bag of clips (quantity 64)

High-density cabling for the FC8-64 port blade

The FC8-64 high density port blade cannot use the standard LC cables because the pitch between optics in the new mini-
SFP (mSFP) transceiver is smaller than in standard SFPs. Patch cables and panels can be used to attach standard size
cabling to the blade if necessary. The following figure illustrates the mSFP to SFP patch cable. Refer to "Best Practices
Guide: High Density Cable Management Solutions" (available at
guidelines for high-density port solutions, and cable and patch panel part numbers.
Broadcom
Length
10 m
1 m
2 m
3 m
5 m
10 m
2 m
2 m
Corning part number
S50502S5120010M
S5S502S5120XXXM
(XXX = length)
S5S502S5120001M
S5S502S5120002M
S5S502S5120003M
S5S502S5120005M
S5S502S5120010M
tbd
H93S5TE9-BMU-XXXM
(XXX = length)
TRIGGER-BP-NP
http://www.brocade.com
Brocade DCX 8510-4 Backbone Hardware Installation Guide
Molex part number
106273-0529
106273-0560
106273-0561
106273-0562
106273-0563
106273-0564
106272-0327
106272-0328
n/a
) for cable management
Amphenol part number
943-99865-10010
943-99866-1XXXX
(XXXX = length)
943-99866-10001
943-99866-10002
943-99866-10003
943-99866-10005
943-99866-10010
943-99867-1XXXX
(XXXX = length)
n/a
53-1002177-19
