Summary of Contents for BESTHEATING Milano Connect
- Page 1 WIFI Touch Screen Thermostat Installation Contents Safety & General Information Page ‑ 2 Installation Page ‑ 2/3 Product Information Page ‑ 4 Aftercare & Recycling Page - 4 Your Guarantee Page ‑ 4 DOC/IM/237/2018...
- Page 2 Safety & General Information Please read carefully... This product is only suitable for use electric radiators and underfloor heating up to 16 Amp. Do not throw away packaging until you have located and confirmed that you have all included parts and the product is in good condition.
- Page 3 Thermostat Installation Dimension (mm) Front(unit:mm) Mounting Hole (unit:mm) Thickness (unit:mm) Electrical Installation Main Connection Brown (Live) - Connection to number 1 (L) Blue (Neutral) - connection to number 2 (N) Load Live (Brown) - connection to number 3 (L) Blue Neutral_ - Connection to number 4 (N) External Temp Sensor Connection to 6 &...
- Page 4 Product Information Voltage 230V, 50/60Hz Backlight Colour 16A Max Load Current Sensor NTC3950，10Kohms at 25℃ Temp. Setting Range 5~35℃ Accuracy ± 0.5℃ Ambient 0~50℃ Protection Class IP30 Relative Humidity Housing ABS to UL94-5 fire retardant plastic Aftercare Clean any marks with a soft dry or damp cloth, for stubborn stains please clean with mild soapy water and dry with a soft cloth.
