Capt'n Cook DF01 Owner's Manual

Capt'n Cook DF01 Owner's Manual

Ovenplus salamander grill

Advertisement

Quick Links

Ovenplus Salamander Grill
5000528
Conforms to ANSI STD Z21.89-2017
Certified to CSA STD 1.18-2017
Outdoor Cooking
Specialty Gas Appliance
FREE HELP
FROM THE GRILL EXPERTS
Do not return to the store.
Assembly questions
Gas grill operation
Replacement of damaged or missing parts
Visit www.ovenplus.com or call: 1-800-474-5587
Monday - Friday 8:30am-4:30pm PST
IMPORTANT:
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
NOTE TO
USER:
Keep this manual for future reference.
RECORD YOUR SERIAL # __________________
(See ETL label at hose of the grill regulator)
Manual # P80159004A - Date:2020/4/23
In this manual we'll help you
WARNING
Failure to comply with these instructions could result in
with:
a fire or explosion that could cause serious bodily injury,
death or property damage.
Whether this gas grill was assembled by you or someone
else, you must read this entire manual before using your
gas grill to ensure the grill is properly assembled, installed
and maintained.
Use your gas grill at least 3 feet away from any wall or
surface. Use your gas grill at least 3 feet away from com-
bustible objects that can melt or catch fire such as vinyl or
wood siding, fences and overhangs or sources of ignition
including pilot lights on water heaters and live electrical ap-
pliances.
THIS GAS APPLIANCE IS DESIGNED FOR OUTDOOR USE
ONLY.
Never use this gas grill on a balcony, deck, or patio above
the ground floor of your home.
Never use your gas grill in a garage, porch, shed, breeze-
way or any other enclosed area.
Never obstruct the flow of ventilation air around your gas
grill.
Never disconnect the gas regulator or any gas fitting while
your gas grill is lit. A lit gas grill can ignite leaking gas and
cause a fire or explosion which could result in property
damage, personal injury or death.
1
OWNER'S MANUAL
Model: DF01

Advertisement

loading
Need help?

Need help?

Do you have a question about the DF01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Capt'n Cook DF01

  • Page 1 Ovenplus Salamander Grill OWNER’S MANUAL Model: DF01 5000528 Conforms to ANSI STD Z21.89-2017 Certified to CSA STD 1.18-2017 Outdoor Cooking Specialty Gas Appliance FREE HELP WARNING FROM THE GRILL EXPERTS • Failure to comply with these instructions could result in Do not return to the store.
  • Page 2 WARNING TABLE OF CONTENTS • Improper installation, adjustment, alteration, service or Primary Safety Warnings maintenance can cause injury or property damage. • Read the installation, operating and maintenance instruc- Assembly 4~10 tions thoroughly before installing or servicing this equip- ment. Gas Cylinder Safety •...
  • Page 3 WARNING CAUTION • Failure to comply with these instructions may result in a Never turn the lid handle to the back of grill, dur- hazardous situation which, if not avoided, may result in ing use. injury. • Spiders and small insects can spin webs and nest in the gas grill burner tube during transit and warehousing which can lead to a gas flow obstruction resulting in a fire in and around the burner tube.
  • Page 4 ASSEMBLY Front View Right-Side View Cross Head Screwdriver For Assembly Use Bottom View...
  • Page 5 ASSEMBLY Unscrew this black bracket and discard. For shipping only. Please recycle. (1) Remove the two pre-assembly screws from the slide bracket. (2) Attach the slide bracket to the bottom of slide by using the two pre-assembly screws.
  • Page 6 ASSEMBLY...
  • Page 7 ASSEMBLY Screw in the slide rail chain hook...
  • Page 8 ASSEMBLY Note: flat edge face front...
  • Page 9 ASSEMBLY...
  • Page 10 ASSEMBLY Table top use (1) Turn the lid handle to front of lid. (2) Pull the slot of the handle into the handle screws. Hand Carry...
  • Page 11 LP GAS CYLINDER • Never allow children to operate your gas grill. Do not allow • This gas grill is designed to use a 20 lb. Liquid children or pets to play near your gas grill. Always super- Propane(LP) gas cylinder (not included). The regulator vise children and pets if they are in the vicinity of the unit.
  • Page 12 LP GAS TANK INSTALLATION LP TANK LEAK TEST Installation Location: • All leak tests must be repeated each time your LP gas • Place the gas cylinder to the right rear side of the grill. cylinders are replaced or refilled. •...
  • Page 13 LIGHTING INSTRUCTIONS Before each use, check all hoses for cracks, nicks, cuts, burns, or abrasions. If a hose is damaged in any way, do not use your gas grill before replacing the hose with an authorized part from the Parts List. Also make sure all gas supply connections are securely tightened.
  • Page 14 CLEANING AND MAINTENANCE • Routine care and maintenance is required to preserve Proper care and maintenance will keep your gas grill in top the appearance and corrosion resistance of stainless operating condition and prolong its life. Follow these steel. The fact is stainless steel can corrode, rust cleaning procedures on a timely basis and your gas grill and discolor under certain conditions.
  • Page 15 Prepare Cooking Grids for Grilling because pizza stones are porous: soap will get Greasing the cooking surface will help keep foods from sticking inside its pores and cause the food to have a and reduces the amount of cleanup required. Use a brush to soapy taste.
  • Page 16 Question: Question: Can I convert my grill from one fuel type to another in other words What causes grill parts to rust and what effect does it have on my from LPG to NG? gas grill? Answer: Answer: No, your gas grill is manufactured according to exact Rusting is a natural oxidation process and will not affect the short...
  • Page 17 DIAGRAMS PART LISTS DESCRIPTION PART NUMBER DESCRIPTION PART NUMBER 1 Lid Assembly P0015318E4 14 Slide Set, Right P055161514 2A Temperature Gauge P00601601C 15 Pizza Stone P05817002A 2B Temperature Gauge Tray Set P033230024 16 Pizza Stone Tray P01318006A 3A Lid Handle P00212010R 17A Gas Valve and Manifold Y0060889...
  • Page 18 Lovinflame Limited Warranty Lovinflame will warrant to the ORIGINAL PURCHASER of this product that it will be free of defects in material and workmanship for set periods below from the date of purchase when used under normal outdoor use and correct assembly: •...
