Summary of Contents for LEXIN FT4 Pro
-
Page 2: Table Of Contents
Table of Contents: 1.Introduction................1 2. Package Contents..............2 3. Installation Instructions............3-5 4. General Operation Instructions..........6-9 5. Bluetooth Intercom Connection for 2-4 units ....9-12 6. Maintenance and Care............12 7. Warranty..................13 8. Waiver and General Release..........13-14 9. Certification and Safety Approvals........14-17... -
Page 3: Introduction
Battery: The FT4 Pro features an 800 MaH battery, that provides the unit with 18 hours of music or 12 hours of intercom with two weeks of standby time. Function Priority: The Lexin FT4 Pro operates in the following order of priority: 1. -
Page 4: Package Contents
Package Contents: ➔ Lexin FT4 Pro Main unit ➔ Clamp Plate ➔ Boom/Button Microphones ➔ Mounting Bracket ➔ Boom Microphone Holder ➔ 3M Double Sided Tape ➔ Installation screws ➔ Pad for clamp plate ➔ Allen Wrench ➔ 40MM HD Ultra-Slim speakers ➔... -
Page 5: Installation Instructions
Installation: Installing Bracket for Lexin FT4 Pro to a Helmet: With Adhesive Pad: With Screws: - If you have any problems with the mounting - Mount the bracket between the internal bracket you may want to use the 3M tape to padding and external shell of the helmet. - Page 6 Step 3: Press the wires between the helmet liner and shell. Mounting the Lexin FT4 Pro Unit to Bracket: Mount the Lexin FT4 Pro main unit on the bracket. Insert the device into the top clip, then press in the bottom until it clicks into place.
-
Page 8: General Operation Instructions
Charging/Battery life - The device charges through a Type C to USB cable. It takes to fully charge the Lexin FT4 Pro. hours While charging the LED turns red. When fully charged the LED turns blue. - Page 9 Pairing Lexin FT4 Pro with Bluetooth Devices: Note: A single Lexin FT4 Pro can be connected with up to two different Bluetooth devices at once. Step 1: With power off, press and hold the A Button for 3 seconds until the LED flashes blue and red.
- Page 10 Change LED- 7 Color Trim: The Lexin FT4 Pro features an RGB LED light with 7 color options. Press both the Jog Dial and the B Button simultaneously to enter color change mode (solid,fade and multicolor cycling)then scroll the jog dial to select color.
-
Page 11: Bluetooth Intercom Connection For 2-4 Units
Universal Pairing To enter pairing mode: Step 1: Power on the Lexin FT4 Pro, press and hold the B Button for about 2 seconds until the LED begins flashing blue and red. Step 2: Follow your other units Bluetooth pairing instructions to enter pairing mode. - Page 12 Three Devices: Note: Before pairing decide which units will be unit one, unit two aka the bridge unit, and unit three. It is best to designate these in the order riders will be riding to increase range. Step 1 Pairing unit one with unit two - Step 2 Pairing unit two-bridge, with unit becomes bridge unit: three:...
- Page 13 Four Devices: Note: Before pairing decide which units will be unit one, unit two aka the first bridge unit, unit three aka the second bridge unit, and unit four. It is best to designate these in the order riders will be riding to increase range. Step 1 Pairing unit one with Step 2 Pairing unit three - Step 3 Pairing unit two - first...
-
Page 14: Maintenance And Care
Maintenance and Care: Follow the suggestions below for optimal care of your Lexin FT4 Pro device and to maintain warranty protection. - Do not use or store the device in dusty or dirty environments. Moving parts and electronic components can be damaged. -
Page 15: Warranty
Product; or (d) any associated or complementary equipment or software not furnished by LEXIN. Limited warranty service may be obtained by delivering the Product to LEXIN or to the distributor or retailer. It was purchased through and providing proof of purchase or receipt date. -
Page 16: Certification And Safety Approvals
You hereby assume all risks and dangers and all responsibility for any losses and/ or damages, whether caused in whole or in part by the negligence or other conduct of others, including LEXIN. By using the Product, you confirm that you have read this release of liability and fully understand and accept its terms and conditions. - Page 17 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 18 Italiano - Per il Manuale Utente Online in Englese, Spagnolo, Tedesco, Italiano, Francese, Jiapponese ... Visita lexinmoto.com, vai su Support - User Manual, e seleziona " Lexin FT4 Pro " Deutsch - Online Bedienungsanweisung auf Englisch, Spanisch, Deutsch, Italienisch, Französisch, Japanisch usw, besuchen Sie lexinmoto.com, gehen Sie zur Unterstützung -...
- Page 19 Español - Para el Manual del Usuario en Línea en Inglés, Español, Alemán, Italiano, Francés, Japonés…Visite lexinmoto.com, vaya al Soporte - Manual de Usuario, y seleccione “Lexin FT4 Pro” Watch Instruction Videos online: English - Subscribe to our Youtube channel @lexinmoto, and find "LEXIN Lexin FT4 Pro Instruction"...
- Page 20 WWW.LEXINMOTORCYCLE.COM support@lexinmotorcycle.com +1 (800) 380-8248...
