- Page 1 OPERATING & INSTALLATION INSTRUCTIONS SPLASHBACK ELECTRIC COOKER SB200/3 PLEASE READ THIS INSTRUCTION BOOKLET BEFORE USING THE APPLIANCE...
-
Page 2: Technical Details
TECHNICAL DETAILS MODEL NO. SB200/3 Voltage: Wattage: Height: Width: Depth: Weight: This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC 230-240 Volts AC 50Hz 9.8-10.7kW 1240mm 460mm 585mm 51.4kg... -
Page 3: Table Of Contents
CONTENTS Technical Details ... 2 Contents ... 3 Preface ... 4 Safety ... 5 Before Installation ... 5 During Operation ... 5 After Use ... 6 General ... 6 Introduction ... 7 Rating Plate ... 7 Installation ... 7 General Notes on Using Your Appliance ... 8 About Condensation and Steam ... -
Page 4: Preface
They have been approved by BEAB (British Electrotechnical Approvals Board) and are covered by a 12 month parts and labour guarantee. To get the best from your new Tricity Bendix appliance, we ask that you PLEASE READ THESE INSTRUCTIONS CAREFULLY. Particular attention should be made to cooking times and temperatures, which may differ, from your previous appliance. -
Page 5: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT THEM ALL BEFORE INSTALLING OR USING THE APPLIANCE. PLEASE READ CAREFULLY BEFORE INSTALLATION This appliance is heavy and care must be taken when moving it. Ensure that all packaging, both inside and outside the appliance has been removed before the appliance is used. -
Page 6: After Use
Take care recommendations given for tending the food when grilling. Always use oven gloves to remove and replace food in the oven. Ensure that unobstructed to ensure ventilation of the oven cavity. Ensure the anti-tilt shelves are put in place correctly. Never line any part of the appliance with foil. -
Page 7: Introduction
INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED RATING PLATE This is situated on the lower front frame of the appliance and can be seen upon opening the door. Alternatively the rating plate may also be found on the back or top of some models (where applicable). The appliance must be protected by a suitably rated fuse or circuit breaker. -
Page 8: General Notes On Using Your Appliance
GENERAL NOTES ON USING YOUR APPLIANCE We suggest that you run the oven elements for 10 – 15 minutes at 220 C to burn off any residue from their surfaces. The procedure should be repeated with the grill for approximately 5 – 10 minutes. During this period an odour may be emitted, it is therefore advisable to open a window for ventilation. -
Page 9: Getting To Know Your Appliance
GETTING TO KNOW YOUR APPLIANCE THE CONTROL PANEL FEATURES - Hotplate Controls - Grill Control - Oven Temperature Control - Oven Indicator Neon... -
Page 10: The Radiant Hob
THE RADIANT HOB USING THE HOB · To operate the hotplates, turn the control knobs clockwise from the OFF position (0) to the required setting. · The highest number represents the hottest setting and the lowest number represents the coolest setting. Choose a setting appropriate to the quantity and type of food to be cooked. -
Page 11: Deep Fat Frying
· To prolong the life of the hotplates: · Never use utensils with a skirt, e.g. a bucket. · Never use an asbestos mat. · Never line the spillage tray with foil. · Never leave the hotplates ON when not covered with a saucepan. -
Page 12: The Grill
THE GRILL CAUTION – ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. · To operate the grill, turn the grill control clockwise from the 'OFF' position (0) to the required setting. · The highest number represents the hottest setting and the lowest number represents the coolest setting. -
Page 13: Hints And Tips
HINTS AND TIPS · Food should be thoroughly dried before grilling to minimise splashing. Brush lean meats and fish lightly with a little oil or melted butter to keep them moist during cooking. · Adjust the height of the grilling grid and grill pan runner position to allow for different thicknesess of foods. -
Page 14: The Oven
THE OVEN · To operate the oven turn the oven control to the required temperature. THINGS TO NOTE The indicator neon will glow. It may turn ON and OFF during use to show that the setting is being maintained. TO FIT THE OVEN SHELVES The shelves should be fitted with the straight rods uppermost on the frame and the forms towards the back of the oven. -
Page 15: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. temperatures by 10°C to suit individual preferences and requirements. FOOD Biscuits Flapjacks Shortbread Bread Bread rolls/buns Casseroles- Beef Chicken Cakes: Small & Queen Victoria sandwich Gingerbread Madeira Rich fruit Christmas Meringues Convenience foods... -
Page 16: Oven Roasting Chart
ROASTING CHART MEAT Beef Beef, boned Mutton and Lamb Pork and Veal Chicken Turkey and Goose Duck Pheasant Rabbit Potatoes with meat Potatoes without meat The roasting temperatures and times given in the chart should be adequate for most joints, but slight adjustments may be required to allow for personal requirements and the shape and texture of the meat. -
Page 17: Care And Cleaning
CARE AND CLEANING ALWAYS SWITCH OFF THE ELECTRICITY SUPPLY AT THE MAIN WALL SWITCH AND ALLOW THE APPLIANCE TO COOL BEFORE CLEANING. CLEANING MATERIALS Before using any cleaning materials on your appliance, check that they are suitable and that their use is recommended by the manufacturer. -
Page 18: Hints And Tips
HINTS AND TIPS · Manual cleaning of the Stayclean surfaces IS NOT recommended. Damage will occur if abrasives or aerosol sprays of any kind are used. · Slight discolouration Stayclean surfaces may occur in time. This DOES NOT affect the Stayclean properties in any way. -
Page 19: Something Not Working
SOMETHING NOT WORKING? We strongly recommend that you carry out the following checks on your appliance before calling a Service Engineer. It may be that the problem is a simple one which you can solve yourself without the expense of a Service call. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the appliance is under guarantee. -
Page 20: Service And Spare Parts
Email: service.eid@electrolux.ie CUSTOMER CARE DEPARTMENT For general enquires concerning your Tricity Bendix appliance, or for further information on Tricity Bendix products, please contact our Customer Care Department by letter or telephone at the address below; Customer Care Department Tricity Bendix 55 –... -
Page 21: Guarantee Conditions
Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ·... -
Page 22: Notes
NOTES... - Page 23 NOTES...
- Page 24 Tricity Bendix, 55-77 High Street, Slough, Berkshire SL1 1DZ Consumer care telephone number 08705 950950 IMPORTANT NOTICE In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed.
Need help?
Do you have a question about the SB200/3 and is the answer not in the manual?
Questions and answers
When I switch my oven on it causes the trip switch to activate. The cooker is about 15 years old and I have never used the oven but have recently found this problem also when I switch a certain ring on it again causes this problem. Can you help please?
