SERVICE MANUAL
MimioProjector
Date
Revise Version
Description
2013.03.06
V1.0
Initial Issue
TSE: Chris
Check: Amy
Approved: Alick

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MimioProjector and is the answer not in the manual?

Questions and answers

Related Manuals for Mimio MimioProjector

Summary of Contents for Mimio MimioProjector

  • Page 1 SERVICE MANUAL MimioProjector Date Revise Version Description 2013.03.06 V1.0 Initial Issue TSE: Chris Check: Amy Approved: Alick...
  • Page 2 Preface This manual is applied to MimioProjector. The manual gives you a brief description of basic technical information to help in service and maintain the product. This manual is for technicians and people who have an electronic background. Please send the product back to the distributor for repairing and do not attempt to do anything that is complex or is not mentioned in the troubleshooting.

  • Page 3: Table Of Contents

    Disassemble Engine Module 2-19 Disassemble SYS FAN and Blower 2-22 Disassemble Bottom Cover Module 2-24 Re-write Lamp Usage Hour 2-26 Repair Action 2-27 Chapter 3 Troubleshooting LED Lighting Message Main Procedure No power troubleshooting Power troubleshooting Image troubleshooting MimioProjector Service Manual...
  • Page 4 HDMI port Test 3D Test Video port Test Run In Test Test Inspection procedure 4-10 ADC Calibration 4-11 Waveform Download 4-12 Fan Calibration 4-13 Chapter 5 Firmware Upgrade Section 1: Scalar Firmware Upgrade Section 2: PIC Firmware Upgrade Procedure MimioProjector Service Manual...
  • Page 5 Chapter 6 EDID Upgrade EDID Upgrade Appendix A Exploded Image Appendix B Serial Number System Definition PCBA Code Definition MimioProjector Service Manual...

  • Page 6: Chapter 1 Introduction

    • Normal mode: 3500 hours min, 50% survival rate Lamp Life • Eco mode: 5000 hours min, 50% survival rate • VGA cable, 10M (R/G/B with impedance:75Ω±10%, Long cable supportable H/V with impedance:50Ω±10%) • HDMI cable: 10M • 80%(Typical) Uniformity • 65% (min.) MimioProjector Service Manual...
  • Page 7 • SECAM: B, D, G, K, K1, L • HDTV: 720p, 1080i, 1080p • EDTV: 480p, 576p • SDTV: 480i, 576i • Operating: 5°C -- 40°C (0~2500ft) Altitude 5°C -- 35°C (2500~5000ft) 5°C -- 30°C (5000~10000ft) Operation temperature • 5 ~ 40°C MimioProjector Service Manual...

  • Page 8: Compatible Mode

    1024 x 768 68.70 1024 x 768 Apple, Mac II 1152 x 864 68.7 1280 x 1024 SXGA 1280 x 1024 1280 x 1024 1280x960 Quad VGA 1280x960 SXGA+ 1400 x 1050 65.3 UXGA 1600 x 1200 75.00 MimioProjector Service Manual...
  • Page 9 640x480 35.0 640x480 37.90 640x480 37.5 640x480 43.3 640x480 61.9 720x400 31.5 800 x 600 35.10 800 x 600 37.90 800 x 600 48.10 SVGA 800 x 600 46.90 800 x 600 53.70 800 x 600 77.4 MimioProjector Service Manual...
  • Page 10 45.0 720p 1280x720 37.5 1080i 1920x1080 60(30) 33.8 1080i 1920x1080 50(25) 28.1 1080p 1920x1080 23.98/24 27.0 1080p 1920x1080 67.5 1080p 1920x1080 56.3 Note:If the compatibility supportive signal is different from user's manual, please refer to user's manual. MimioProjector Service Manual...

  • Page 11: Chapter 2 Disassembly Process

    8. + NO.0 Phillips Screwdriver * Before you start: This process is protective level II. Operators should wear an anti- static wrist band. Please place the protective cover or protective plastic on the lens and mirror to prevent scratching. MimioProjector Service Manual...

  • Page 12: Disassemble Lamp Module And Mesh Inlet

    1. Loosen 2 screws (red circles) on the Lamp Cover. 2. Separate the Lamp cover and Lamp cover strap (green squares). LAMP COVER 3. Loosen 2 screws (yellow circles) on the Lamp Module. 4.Slide out the Lamp Module. LAMP MODULE MimioProjector Service Manual...

  • Page 13: Disassemble Top Cover Module

    5. Remove the two mesh inlet filters. BACK MESH INLET SIDE MESH INLET 2-3 Disassemble Top Cover Module 1. Push (A) part and pull the (B) part of the corner cover at the same time to remove it. MimioProjector Service Manual...
  • Page 14 Chapter 2: Disassembly Process 2. Unscrew 2 screws (red circles). 3. Disassemble the Bottom Cap (green squares). 4. Unscrew 2 screws (yellow circles). 5. Remove the front mirror cover module. FRONT MIRROR COVER MODULE MimioProjector Service Manual...
  • Page 15 Chapter 2: Disassembly Process 6. Remove the rear mirror cover. REAR MIRROR COVER 7. Unscrew 2 screws (green circles) to remove wireless top cover. WIRELESS TOP COVER MimioProjector Service Manual...
  • Page 16 Chapter 2: Disassembly Process 8. Uscrew 2 screws (red circles). 9.Unscrew 2 screws (green circles). 10. Unscrew 3 screws (blue circles). 11.Unscrew 3 screws (yellow circles). 12.Unscrew 2 screws (red circles). MimioProjector Service Manual...
  • Page 17 (yellow squares). Then unscrew 2 screws to disassemble the IR camera transform board. 16. Unplug 1 connector to remove the IR camera transform board. IR CAMERA TRANSFORM BD 17.Unscrew 4 screws (red circles) and take off keypad board module. KEYPAD BUTTON MimioProjector Service Manual...

  • Page 18: Disassemble Main Board

    Chapter 2: Disassembly Process TOP COVER 18.Separate the keypad board and FPC cable. KEYPAD BOARD FPC CABLE 2-4 Disassemble Main Board 1.Unscrew 11 screws (red circles) to disassemble the main board shielding. MimioProjector Service Manual...
  • Page 19 Chapter 2: Disassembly Process 2.Unscrew 6 screws (green circles) . 3. Unscrew 8 screws (blue circles) and 4 hex screws (yellow circles). 4. Tear off the tape (red squares). MimioProjector Service Manual...
  • Page 20 Composed of Red/Blue/Black FAN1 wire, White connector(3 pin) Composed of Red/White/Black- PHOTO SENSOR wire, Green connector and Gray wire tube (3 pin) LAMP DRIVER Black wire tube (5 pin) LVPS TO M/B Black wire tube (16 pin) 2-10 MimioProjector Service Manual...
  • Page 21 (3 pin) SPK_R Compose of Red/Black wire(2 pin) SPK_L Compose of Red/Black wire(2 pin) 6. Remove the main board module. 7. Unscrew 2 screws (green circles) to disassemble daughter board. 8. Unscrew 2 screw hexs (yellow circles). 2-11 MimioProjector Service Manual...

  • Page 22: Disassemble Io Cover And Bottom Shielding

    Chapter 2: Disassembly Process MAIN BOARD DAUGHTER BOARD 2-5 Disassemble IO Cover Module and Bottom Shielding 1. Remove the IO cover module (green arrows). 2. Separate the IO cover module. IO COVER MODULE 2-12 MimioProjector Service Manual...

  • Page 23: Disassemble Lamp Driver And Lvps Module

    Lamp Driver Module. Note:1. The Interlock switch and IR camera transform cable should be from the notch (blue square). 2. The 16-Pin cable and 5-Pin cable should be from the notch (yellow square). 2-13 MimioProjector Service Manual...
  • Page 24 Chapter 2: Disassembly Process 2. Unplug 2 connectors (red square) to disassemble the lamp driver module. 3. Unscrew 1 screw (green circle) to disassemble the Thermal sensor board. THERMAL SENSOR BOARD 4. Unplug 1 connector (blue square). 2-14 MimioProjector Service Manual...
  • Page 25 5.Separate Lamp Driver and Lamp Driver Shielding. LAMP DRIVER 6.Unplug 4 connectors (green squares). 7. Unscrew 4 screws (red circles) to disassemble LVPS. 8. Unplug 1 connector to get the LVPS module. LVPS 9. Take off Mylar (yellow square). 2-15 MimioProjector Service Manual...

  • Page 26: Disassemble Speaker And Ac Inlet

    Chapter 2: Disassembly Process 2-7 Disassemble Speaker and AC Inlet Module 1. Unscrew 2 screws (red circles) to disassemble the left speaker module. 2. Unscrew 4 screws (yellow circles) to remove the left speaker. LEFT SPEAKER 2-16 MimioProjector Service Manual...
  • Page 27 3. Unscrew 3 screws (green circles) to disassemble the right speaker module. 4. Unscrew 4 screws (green circles) to remove the right speaker. RIGHT SPEAKER 5. Unscrew 3 screws (red circles) to disassemble AC Inlet bracket. 2-17 MimioProjector Service Manual...
  • Page 28 Chapter 2: Disassembly Process 6. Remove AC Inlet module. 2-8 Disassemble Engine Module 1. Unscrew 6 screws (red circles) and remove the Engine Module. 2-18 MimioProjector Service Manual...
  • Page 29 Chapter 2: Disassembly Process 2.Tear off the tape (blue square) and disassemble IR sensor board. IR SENSOR 3. Tear off the EMI tape and EMI gasket (green square). 2-19 MimioProjector Service Manual...

  • Page 30: Disassemble C/W Module

    Chapter 2: Disassembly Process 2-9 Disassemble C/W Module 1. Unscrew 2 screws (red circles) to remove color wheel module. 2. Unscrew 1 screw (blue circle) to separate C/W module and photo sensor board. 2-20 MimioProjector Service Manual...
  • Page 31 Chapter 2: Disassembly Process 4.Unscrew 3 screws (blue circles) to disassemble focus ring. The engine module disassembly process is completed. 2-21 MimioProjector Service Manual...

  • Page 32: Disassemble Sys Fan And Blower

    2-10 Disassemble SYS FAN and Blower 1. Unscrew 4 screws (red circles) to disassemble SYS fan module. 2.Unscrew 1 screws (green circle) to disassemble the thermal switch. THERMAL SWITCH 3.Unscrew 4 screws (yellow circles) to disassemble SYS fan. 2-22 MimioProjector Service Manual...
  • Page 33 Chapter 2: Disassembly Process SYS FAN 4. Unscrew 1 screws (red circle) to disassemble the Interlock switch . INTERLOCK SWITCH 2-23 MimioProjector Service Manual...

  • Page 34: Disassemble Bottom Cover Module

    Chapter 2: Disassembly Process 5. Unscrew 3 screws (yellow circles) to disassemble the Blower. 6. Separate the Blower and Blower Rubber. BLOWER 2-11 Disassemble Bottom Cover Module 1. Unscrew 4 screws (red squares) and remove the lamp holder rail. 2-24 MimioProjector Service Manual...
  • Page 35 Chapter 2: Disassembly Process 2.Unscrew 6 screws (green circles) and remove the Bottom Shielding. 3.Unscrew 4 screws (blue circles) to disassemble the side mesh frame and back mesh frame. BOTTOM COVER 2-25 MimioProjector Service Manual...

  • Page 36: Re-Write Lamp Usage Hour

    "right" key to re-write "Operatiing Hour". 6. Exit Service Menu - Use "Up" or "Down" key to select "Exit", press "Enter" to exit the service mode. Note: Left key = decrease Lamp/Projection hour Right key = increase Lamp/Projection hour 2-26 MimioProjector Service Manual...

  • Page 37: Repair Action

    Firmware Wheel Firmware Update Chapter 5 Color Wheel Index Chapter 4-4-1.7 OSD Reset Chapter 4-6.2 EDID Chapter 6 Re-write Lamp Chapter 2-12 Hours Usage Chapter 4-9 Fan Calibration Waveform Chapter 4-8 Download ADC Calibration Chapter 4-7 2-27 MimioProjector Service Manual...

  • Page 38: Chapter 3 Troubleshooting

    Thermal sensor error(System Over Temperature),OSD shows”Projector Overheated” Fan lock error OSD shows red”Fan 0.5 second(ON) Fail,Will automatically turn off 0.5 second(OFF) soon” flashing Lamp error(Lamp,ballast) Color Wheel fail 0.5 second(OFF) Photo sensor fail flashing Steady light No light MimioProjector Service Manual...

  • Page 39: Main Procedure

    Chapter 3: Troubleshooting 3-2 Main Procedure MimioProjector Service Manual...

  • Page 40: No Power Troubleshooting

    Chapter 3: Troubleshooting 3-3 No Power troubleshooting MimioProjector Service Manual...

  • Page 41: Power Troubleshooting

    Chapter 3: Troubleshooting 3-4 Power troubleshooting MimioProjector Service Manual...
  • Page 42 Chapter 3: Troubleshooting 3-4 Power troubleshooting MimioProjector Service Manual...
  • Page 43 Chapter 3: Troubleshooting 3-4 Power troubleshooting MimioProjector Service Manual...

  • Page 44: Image Troubleshooting

    Chapter 3: Troubleshooting 3-5 Image troubleshooting MimioProjector Service Manual...
  • Page 45 Chapter 3: Troubleshooting 3-5 Image troubleshooting MimioProjector Service Manual...
  • Page 46 Chapter 3: Troubleshooting 3-5 Image troubleshooting MimioProjector Service Manual...
  • Page 47 Chapter 3: Troubleshooting 3-5 Image troubleshooting 3-10 MimioProjector Service Manual...

  • Page 48: Remote Control Troubleshooting

    Chapter 3: Troubleshooting 3-6 Remote control troubleshooting MimioProjector Service Manual 3-11...

  • Page 49: Pin Assignment

    Full power mode : 9V ±5% °C Eco mode : 6.5V ±5% ED Mode (30% lamp power)3.5V ±5% FAN3_2 High (3.3V) Pin3 Pin1 FAN3_3 J19: Ballast Description Voltage(V) LAMPLIT_IN high (5V) P5V_LAMP_DRV 5V±5% LAMPEN_OUT high (5V) LAMP_TXD31 high (5V) Pin1 Pin5 3-12 MimioProjector Service Manual...
  • Page 50 TS_BD_VCC 3.3V±5% TS_BD_GND TS_BD_SDA high (3.3V) TS_BD_SCL high (3.3V) Pin4 Pin1 J20: Photo sensor Description Voltage(V) PHOTO_1 5V±5% PHOTO_2 0.9V±5% PHOTO_3_GND Pin1 Pin3 J5: Front IR Description Voltage(V) IR_F_VCC 5V±5% IR_F_GND IR_F high (5V) Pin3 Pin1 MimioProjector Service Manual 3-13...

  • Page 51: Electronic Function Block Diagram

    Chapter 3: Troubleshooting 3-8 Electronic Function Block Diagram 3-14 MimioProjector Service Manual...

  • Page 52: Function Test&Alignment Procedure

    - Blue- ray DVD player support “S-Video”,3D source files,"HDMI" and "Video" 4-2 Test Condition - Product must be warmed up for 5 minutes. - Screen size: 87.2 inches diagonal. Zone Definition < Figure: Zone A(as green line) Definition > MimioProjector Service Manual...

  • Page 53: Test Procedure

    Chapter 4: Function Test&Alignment Procedure 4-3 Test Procedure MimioProjector Service Manual...

  • Page 54: Vga Port Test

    Chapter 4: Function Test&Alignment Procedure 4-4 I/O Port Test 4-4-1 VGA Port Test Note: For all test patterns, please refer to the “MIMIO FINAl TEST” file. 1. Frequency and tracking boundary Procedure - Test equipment: PC support HDTV resolution &...
  • Page 55 - Test equipment: PC support HDTV resolution & Independent graphic card - Test signal: analog 1280 x 800@60Hz - Test Pattern: blue 60 Inspection item - Dark blemish check Criteria - Please refer to Pixel specification table. MimioProjector Service Manual...
  • Page 56 (Blur word on one of the corner after adjustment is acceptable. However, the word should at least be recognizable.) MimioProjector Service Manual...
  • Page 57 (The unidentified color levels on both left and right sides should not over 4 color levels.) - Gray level should not have abnormal color or heavy lines. - If color appears abnormal, please get into service mode to do color wheel index adjustment. MimioProjector Service Manual...

  • Page 58: Audio Test

    4-4-4 HDMI Port Test Procedure - Test equipment: Blue- ray DVD player support “S-Video” & 3D source files,”HDMI” and “Video“ - Test signal: 720p, 1080p, 1080i Inspection item - HDMI performance test. Inspection Distance - 200mm ~250mm MimioProjector Service Manual...

  • Page 59: Test

    “S-Video”,3D source files,"HDMI" and "video" - Test signal: video Inspection item - Video performance test Inspection Distance - 200mm~250 mm Criteria - Check any abnormal color, line distortion or any noise on the screen. - Check the sound from speaker. MimioProjector Service Manual...

  • Page 60: Run In Test

    Press right key to adjust the time (50) Lamp Off Press right key to adjust the time (10) Set burn in cycle Press right key to adjust the cycle After setting up the time, choose “Get into Burn-In Mode” and press enter MimioProjector Service Manual...

  • Page 61: Test Inspection Procedure

    After final QC step, it is necsssary to erase all saved changes and restore the OSD default setting. The following actions will allow you to erase all end-users' settings and restore the default setting: (1) Enter OSD menu. (2) Choose "Setting" and then execute "Reset" function 4-10 MimioProjector Service Manual...

  • Page 62: Adc Calibration

    Chapter 4: Function Test&Alignment Procedure 4-7 ADC Calibration Note: After replacing main board or upgrading firmware, the ADC calibration should be done. For the test pattern, please refer to “MIMIO FINAL TEST” file. Procedure - Test equipment: PC (1) Test signal: 1280 x 800@60Hz...

  • Page 63: Waveform Download

    4. The “Power LED” will light blue about 5s, then it will light (Note: If the power LED solid blue or the lamp LED light, please repeat the step 1-3 5.The waveform download is finished. 6. Pull out the power cord. 4-12 MimioProjector Service Manual...

  • Page 64: Fan Calibration

    (picture “A” shown). 4. After 70 seconds,Please check value. Note: - If the Factory Fan RPM Value doesn’t meet the above range,please repeat the step again. - Make sure the value of “Factory RPM” is 2090~3880. MimioProjector Service Manual 4-13...

  • Page 65: Chapter 5 Firmware Upgrade

    Software: (DDP 442X-USB) - DDP 442X Firmware Downloader.exe - Firmware (*.img) - NET Framework 4.0 Hardware: - Projector - Power Cord - Mini USB Cable: 42.00284G001 (USB Cable mini USB to USB (A)) - PC or Laptop MimioProjector Service Manual...
  • Page 66 5-1-2 NET Framework 4.0 Setup Procedure 1. Choose "dotNetFX40_Full_X86_X64 Microsoft.NET Framework 4.0 Microsoft Corporation" Program. 2. Click "Run". 3. Preparing 4. Read "License terms". - Choose "I have read and accept the license terms". - Click "Install". MimioProjector Service Manual...
  • Page 67 Chapter 5: Firmware Upgrade 5. Installing 6. Click "Finish". MimioProjector Service Manual...
  • Page 68 (USB A to mini USB B). Power cord USB cable 5. Get into firmware download mode. - Hold down "MENU" button and plug in the power cord. - Release the "MENU" button once all LEDs are solid on. MimioProjector Service Manual...
  • Page 69 9. Check the firmware version. - Unplug the power cord and USB cable, then re-plug the power cord to power on the projector . - Press "power->left->right->menu" sequentially to get into service mode to check firmware version. MimioProjector Service Manual...

  • Page 70: Section 2: Pic Firmware Upgrade Procedure

    Section 2: PIC Firmware Upgrade Procedure 5-2-1 Equipment Needed Software: - RS232.EXE - xxx_xxx_xxx.hex Hardware: - Projector - Power Cord - RS232 Cable :42.86603G001 (RS-232 9 Pin Cable (pin to pin, F-F)) - PC or Laptop with RS-232 connector MimioProjector Service Manual...
  • Page 71 - Hold down "MENU" button and plug in the power cord. - Release the "MENU" button once all LEDs are solid on. 2. Download the firmware file from website, then unzip the firmware file, and unzip the “RS232.zip”. 3. Execute “RS232.exe” program. MimioProjector Service Manual...
  • Page 72 1) PORT: Check the COM port is “COM 3” (Select the COM port which you are using). 2) Baudrate : Set to 19200 3) Program : Set to “NON-ECHO”. 5. Click the “Load” button to choose the firmware file. 6. Click the “Rescue Program” button. MimioProjector Service Manual...
  • Page 73 Chapter 5: Firmware Upgrade 7. Click the “OK” to start firmware upgrading. 8. The firmware will be upgraded automatically. 9. Finish. - Click "OK". MimioProjector Service Manual...
  • Page 74 10. Check the firmware version. - Unplug the power cord and USB cable, then re-plug the power cord to power on the projector . - Press "power->left->right->menu" sequentially to get into service mode to check firmware version. MimioProjector Service Manual 5-10...
  • Page 75 Note: - If a display device has digital input ports, like DVI or HDMI, but without EDID in its Main Board, the display device will show no image while the input source is digital signal. MimioProjector Service Manual...
  • Page 76 - Generic Fixture (80.00001.001) for EDID Key-in - RS-232 9 Pin Cable (pin to pin, F-M) (42.83C07G001) - Power Adapter (47.57803G001) - Monitor - PC with RS-232, VGA, HDMI and DVI connectors Note: - Please use EDID Tool _Ver.0.91 or above version. MimioProjector Service Manual...
  • Page 77 DVI to HDMI Cable . VGA1 Cable (4) Plug Power Adapter to P4 of fixture. HDMI TO DVI Cable 6-4 EDID Key-In Procedure (VGA1 &HDMI) 1. Execute EDID Program - Double click "EDID" to execute EDID program. MimioProjector Service Manual...
  • Page 78 (5) Key in the Serial Number into the Barcode blank space. (6) In "Write Source Select" item, select "VGA1" and "HDMI". (7) Click "Program". (8) When the message "Please change the cable to VGA1" appears on the screen,click "OK". MimioProjector Service Manual...
  • Page 79 "Trans", then click the "Read". - EDID "Analog" information will show the result. (12) Read EDID "Digital" information - In "Read item", select "Digital" and "Trans", then click the "Read". - EDID "Digital" information will show the result. MimioProjector Service Manual...
  • Page 80 (3) Plug Power Adapter to P3 of fixture. VGA2 Cable 6-6 EDID Key-In Procedure (VGA2) 1. Execute EDID Program - Double click "EDID" to execute EDID program. 2. Process (1) Select Select the COM Port which you are using. (2) Click "Model". MimioProjector Service Manual...
  • Page 81 (5) Key in the Serial Number into the Barcode blank space. (6) In "Write Source Select" item, select "VGA2". (7) Click "Program". (8) When the message "Please change the cable to VGA2" appears on the screen,click "OK". MimioProjector Service Manual...
  • Page 82 (9) When the EDID program is completed, a "OK" message will appear on the screen. (10) Read EDID "Analog" information. - In "Read item", select "Analog" and "Trans", then click the "Read". - EDID "Analog" information will show the result. MimioProjector Service Manual...
  • Page 83 Administrator Password which will be accepted by projector anytime no matter what the Administrator Password is. 1. Get universal password. (1). Double click "Mimio Password Translation". (2).Input SNID number(The SNID number should be got from the service mode.) (3).The password will appear.
  • Page 84 (2) Enter the default password (123456) using the number buttons on the remote control, then press “Enter” to confirm it. (3) Enter the default password again and press “Enter” to confirm it. (4) The password has been changed. MimioProjector Service Manual 6-10...
  • Page 85 Appendix A (Exploded Image) Appendix A (Exploded Image) Note: This chapter is only designed to show the exploded image of the projector. For updated part numbers, please refer to the Recommended Spare Parts List report. D.C. MimioProjector Service Manual...
  • Page 86 CAP WIRELESS IO BLANK MN3600 G3.5 35.8PE02G001 WIRELESS LABEL BLANK PC-835 G3.5 51.8PE07H002 COVER MIRROR REAR MN3600 WHITE G3.5 75.8PE01G001 COVER COSMETIC MODULE G3.5 75.8PE20G001 BUY COVER BTM ASS’Y MimioProjector 85.1A523G060 SCREW PAN MECH M3*6 NYLOK, GREEN SP.8PE01GC01 LAMP MODULE 75.8PE16G002 LAMP COVER ASSY 61.00061G001 LOCK SCREW PAN MECH M3*8.5-3.5 Ni...
  • Page 87 COVER COSMETIC MODULE G3.5 51.8PE12H001 KEYPAD MN3600 G3.5 51.8PE13H001 KEYPAD MENU MN3600 G3.5 80.8PE03G001 PCBA KEYPAD BOARD 8PE FR4 FOR G035 PROJECTOR 80.8PE12G001 PCBA IR CAMERA TRANSFORM BOARD 8PE FR4 FOR G035 PROJECTOR 41.80J03G001 GASKET FOR MAIN BOARD EMI MimioProjector Service Manual...
  • Page 88 LAMP DRIVER MYLAR FORMEX GK-17 0.43t G3.5 75.8ML02G011 ASSY OSRAM LAMPDRIVER PT VIP O3 MID 240W-UNIPRO AS WITH DYNAMIC ECO 51.8PE45G001 THERMAL SENSOR MYLAR G3.5 80.8PE09G001 PCBA THERMAL SENSOR BD FOR PROJEC- TOR G035 85.1F323G060 SCREW PAN MECH W/SF M3*6 BLACK MimioProjector Service Manual...
  • Page 89 (KLIXON YS11) G035 49.8PE01G011 SUNON 105mm*32mm / AXIAL FAN / RoHS2.0 61.8PE06H004 FAN SYSTEM BRACKET 70.8PE08G001 BLOWER DUCT ASS’Y G3.5 75.8PE10G001 BUY ASSY INTERLOCK SWITCH 2P #26 320mm G3.5 51.89W18G001 LIMIT SWITCH HOLDER PC MN3600H BLACK TDP-SP1 MimioProjector Service Manual...
  • Page 90 Appendix A (Exploded Image) ASSY LEFT SPEAKER MODULE Item Description Parts Supply 49.8PE04G001 SPEAKER 10W 6-OHM 280mm G3.5 61.8PE12H002 SPEAKER BRKT LEFT SECC 0.8t G3.5 52.8PE02G001 PORON SPEAKER G3.5 85.1F123G080 SCREW PAN MECH W/SF M3*8 NI GREEN MimioProjector Service Manual...
  • Page 91 Appendix A (Exploded Image) ASSY FRONT SPEAKER MODULE Item Description Parts Supply 49.8PE04G001 SPEAKER 10W 6-OHM 280mm G3.5 52.8PE02G001 PORON SPEAKER G3.5 85.1F123G080 SCREW PAN MECH W/SF M3*8 NI GREEN 61.8PE11H003 SPEAKER BRKT FRONT MimioProjector Service Manual...
  • Page 92 ASSY MAIN BOARD MODULE Item Description Parts Supply 61.83404G001 HEXAGON COPPER STICK M3 L18 SCREW L4.5 EzPro 735 80.8PE01G006 PCBA MAIN BD 80.8PE06G001 PCBA DAUGHTER BD FOR G035 PROJEC- 85.1F123G060 SCREW PAN MECH W/SF M3*6 Ni GREEN VIII MimioProjector Service Manual...
  • Page 93 Appendix A (Exploded Image) ASSY LAMP BLOWER MODULE Item Description Parts Supply 49.8PE02G011 SUNON 70mm*25mm /LAMP BLOWER/ RoHS2.0/WIRE LENGTH 230mm 52.8KZ01G001 7025 BLOWER RUBBER HD33 52.8KZ06G001 7025 BLOWER DUCT AIR TIGHT HD33 MimioProjector Service Manual...
  • Page 94 Appendix A (Exploded Image) ASSY ENGINE MODULE Item Description Parts Supply 75.8SP05GR01 ASSY ENGINE MODULE FOR 8SP 75.8PE03G001(SERVICE) 85.YA322H040 SCREW FLAT HEAD TAP M2*4MM SWRCH18A H BLACK 51.8PE10H003 FOCUS RING 75.8SP06GR01 ASSY COLOR WHEEL MODULE FOR 8SP(SERVICE) MimioProjector Service Manual...
  • Page 95 Appendix A (Exploded Image) Item Description Parts Supply DC.8PE01G001 D.C. G3.5 56.8JL03G001 EPE BAG S500WI 56.8PE01G001 EPE CUSHION LEFT G3.5 56.8PE02G001 EPE CUSHION RIGHT G3.5 55.8PE01G001 CARTON BOX G3.5 AK.8PE01G001 A.K. G3.5 MimioProjector Service Manual...
  • Page 96 Appendix A (Exploded Image) Item Description Parts Supply 55.8PE03G001 AK BOX 55.8PE05G001 AK PARTITION PAPER W/O IR CAMERA 42.50115G001 CABLE POWER CORD 1.8M SP30+IS14 US 42.00200G005 CABLE VGA 15P 1.8M BLK EP739 45.8PE01G001 INFRARED REMOTE CONTROLLER FOR MimioProjector Service Manual...
  • Page 97 = 39) 0001 = Serial Code A = Manfacture factory number (A=CPC, B=Vimax) EX: PW012310001A This label "PW012310001A" represents the serial number for MimioProjector. It is produced at CPC on thirty-ninth of 2012. Its serial code is 0001. MimioProjector Service Manual...
  • Page 98 Appendix B II. PCBA Code Definition PCBA Code for Projector XXXXXXXXXX EEEE Vendor Code Revision Date Code MimioProjector Service Manual...
