application note. Go to
note.
Note
If you plan to use the PXIe-6570 as part of an integrated system, such as a
Semiconductor Test System (STS), refer to the system documentation for guidance
on device interface board design and connection guidelines. For system
documentation, contact your NI sales engineer.
To connect a custom device interface board to the VHDCI Digital Data and Control connector
on the PXIe-6570, use a mating connector for the VHDCI cable from NI.

PXIe-6570 Accessories

Caution
shielded cables and accessories. Do not use unshielded cables or accessories unless
they are installed in a shielded enclosure with properly designed and shielded input/
output ports and connected to the product using a shielded cable. If unshielded
cables or accessories are not properly installed and shielded, the EMC specifications
for the product are no longer guaranteed.
NI CB-2162 Connector Block and Prototyping Board
SCB-68 HSDIO Shielded Connector Block for R Series
and HSDIO Devices
SMB-2163 SMB Breakout Box for High-Speed Digital
Devices
NI SHC68-C68-D4 Shielded Single-Ended Cable for
High-Speed Digital Devices
SHC68-H1X38 High-Speed Digital Flying-Lead Cable,
1.5 m
VHDCI connectors
NI-Digital Pattern Driver and Digital Pattern Editor
Media
Note
For more information on recommended accessories for use within a system
such as STS, contact your NI Sales Engineer.
10 | ni.com | PXIe-6570 Getting Started Guide
ni.com/info and enter the info code
To ensure the specified EMC performance, operate this product only with
Description
to locate the application
rdinwa
NI Part Number
778592-01
782914-01
778747-01
781013-01 - 0.55 m
196275-01 - 1 m
152870-01 - 1 m
Low Leakage
781293-01 - 2 m
192681-1R5
780389-01
778914-01
780390-01
785249-03
