Toshiba WAL7C User Manual

Wall mounting WAL7C for LCD color TV
Instruction for Installation
Thank you for purchasing this Toshiba Wall mounting.
For correct installation, please read this manual carefully.
This manual should be saved and kept on hand as a convenient reference.
This Wall mounting is designed exclusively for a Toshiba LCD color TV.
Special technology and knowledge are required for the wall fixing. Please ask qualified applicators for
installation.
Notice for dealers and installation applicators
For safety of the user, please make sure the installation area has strength enough to bear the weight of LCD
color TV and Wall mounting, and install with care.
Please read the warnings and notice on the back carefully for correct use.
Installation Notice
To prevent human hazards or property damage and ensure safe and correct use, this manual has recorded
some important content such as the installation method. Please read it with full understanding of the
following diagram & marks and observe the recorded items.
[Marks]
Mark
Indicates "It could result in your death or serious injury*
Warning
instructions"
Indicates "It could result in your injury*
Caution
instructions"
*1: Serious injury herein refers to conditions such as blindness, wound, burn
(whatever high or low temperature), electric shock, fracture, poisoning etc.
which may leave a sequela and require hospitalization or long medical
treatment.
*2: Injury herein refers to conditions such as wound, burn or electric shock etc.
which does not require hospitalization or long medical treatment.
*3: Property damage herein refers to damage of house, household, livestock or
pet involved.
[Diagrams]
Diagram
" " indicates a prohibited action (Do not do).
The action prohibited is described within or near the symbol by diagram or word.
Prohibition
" " indicates a required action (Do).
The action required is described within or near the symbol by diagram or word.
Direction
Exemptions
•
Toshiba is not liable for any damage caused by natural disaster (such as fire, earthquake), uses by third person,
accidents, owner's intentional misuse, or uses in other improper conditions.
•
Toshiba is not liable for incidental damages (such as profit loss or interruption in business, TV watching fee loss
etc.) caused by use or unable use of the product.
•
Toshiba is not liable for any damage caused by neglect of the instruction described in the instruction manual.
• Toshiba is not liable for any injury/damage caused by improper installation of this product.
• If the product is installed to the wall and then disassembled, the screw hole and fixing bolts will remain on the wall.
• Over an extended period of use of your LCD color TV, dirt or discoloration may occur to the supporting wall.
Meaning of the mark
1 if you don't follow
2 3
or property damage* if you don't follow
Meaning of the diagram
Please observe the following instructions
Warning
•
Please ask qualified applicators to install the equipment to the wall. The inadequate
application may cause the fall of a LCD color TV, resulting in injury.
Direction
•
Reinforce the installation area to make sure it is capable to bear the weight including the LCD
color TV and resistant to impact of earthquake or shock. The inadequate application may
cause the fall of the LCD color TV resulting injury. So, please reserve the following instructions.
Direction
• A socket should be used for the power supply of a LCD color TV. Please use a socket out
of which the plug can be pulled easily.
<Installation on wood walls>
Make sure the total weight is borne by the beam. The beam should be reinforced in case of
inadequate strength. Please do not install the product on the plasterboard.
<Installation on concrete walls>
Please use the market available anchor bolt which can bear the weight of the LCD color TV.
•
Embed the metal hook fixed on the wall into the metal hole of the LCD color TV completely,
slide and make sure it will not fall. Otherwise the TV may fall resulting in injury.
Direction
•
The wall mounting is designed exclusively for a Toshiba LCD color TV Do not use it elsewhere.
Otherwise it may fall causing injury.
Prohibition
Caution
•
Do not jam the LCD color TV blowhole on the top of the screen. If the blowhole is jammed,
heat will gather inside the TV, causing a fire.
Prohibition
•
Do not install at places near the vent of air conditioner or frequently vibrate, or places directly
blown by moisture, dust, smoke or steam (stove, electric cooker, humidifier etc.). Otherwise
may cause fire or electric shock.
Prohibition
•
The angle of the screen of an installed LCD color TV cannot be changed. The forced turn
may loosen fixing bolt leading to the fall of the LCD color TV.
Direction
