Digital Timer Unit

Operating Instructions

Model #: 160643

(HU2164001-GW)

Specifications

Program up to 6 feeds per day

Duration 1–30 seconds per feed

Adjustable spinning speed

Battery charge indicator.

Made in China

Table of Contents

Need help?

Do you have a question about the 160643 and is the answer not in the manual?

Questions and answers

Summary of Contents for Game Winner 160643

Page 1 Digital Timer Unit Operating Instructions Model #: 160643 (HU2164001-GW) Specifications Program up to 6 feeds per day Duration 1–30 seconds per feed Adjustable spinning speed Battery charge indicator. Made in China...
Page 2 Connecting Wires Identify the blue and the white wires extending from the timer unit. Attach the blue wire to the copper lead of the motor (either end) and then attach the white wire to another copper lead of the motor. Reversing the attachment of wires only changes the spinning direction and it does not cause damage to the unit.
Page 3 on the battery. The battery indicator on the display shows the power status while in use Setting Time Change from “READY” mode “CLOCK” mode by pressing the ▲ or ▼ buttons and then press “OK” button to enter “Clock” mode. Press ▲ and ▼ buttons and the “OK”...
Page 4 the time. Press “OK” button again when finish. Setting Feed Time Move to “FEED” mode by pressing the ▲ or▼ buttons and then press the “OK” button to enter “FEED” mode. Select feed # and set feed time using the▲ and▼...
Page 5 feeds, just set the feed time to “OFF” for the feeds not to be used. Once the feed time is set, select duration of feed from 1 to 30 seconds.
Page 6 Select RPM (Hi/Med/Low) to set spinning speed.
Page 7 Repeating the above steps to set next feed time, duration and spinning speed. Press “OK” button to return to “FEED” mode. Test Mode The “Test” mode allows you to test the unit. Move to “Test” mode by pressing ▲ or▼ buttons. The unit will run after 10 seconds once you press the “OK”...
Page 8 Resetting the Unit If you observe a malfunction of the unit, reset the unit by moving to “RESET” mode and then press “OK” button. The unit will restore to default factory setting...
Page 9 Trouble Shooting Jam or Short- When you see either one or both of these signs on the display, the timer unit has stopped automatically to protect itself from short circuit. Disconnect the power supply first and then check the entire feeder unit for any abnormal set up eg, the spinning plate is clogged by feed, the timer unit...
Page 10 experienced an unstable current input due to external interference or other reasons. Having fixed the problem, reconnect the power supply and the unit should resume normal. If problem persists, call our customer service for help.
Page 11 Safety disconnect the power supply before relocating the feeder or adjusting the spinning plate when the unit is in operation, stay at a safe distance as feed may hit your eyes and body. Battery Every time you disconnect the battery from the unit, you need to reset the time when reconnecting.
Page 12 responsiveness of the LCD display. However, functionality of the unit is not affected. Should you have any question in regard to this timer unit, call our customer service for help. Rankam (China) Manufacturing Co. Ltd. 1-888-837-1380 Monday thru Friday 8 A.M. to 5 P.M. Pacific Standard Time or by email customerservice@rankam.com...
