computer radio control system
EN
CZECH REPUBLIC
DC-16 II
2.4GHz & 900MHz NG
Dual Band System
EN
Part I. - User Manual
FW 5.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Duplex DC-16 II and is the answer not in the manual?

Questions and answers

Related Manuals for JETI model Duplex DC-16 II

Summary of Contents for JETI model Duplex DC-16 II

  • Page 1 computer radio control system CZECH REPUBLIC DC-16 II 2.4GHz & 900MHz NG Dual Band System Part I. - User Manual FW 5.00...
  • Page 2 computer radio control system...

  • Page 3: Table Of Contents

    1. Introduction ................... 06 1.1 DC/DS ....................06 3.3.6 Changing the transmitter mode ........16 1.2 Activation method for software modules of JETI model ..06 3.3.7 Transmitter Gimbals with Switch or Button Installation 1.2 Features ..................... 07 ....................17 3.4 Swappable and Assignable Switches ........
  • Page 4 computer radio control system 8.3 Binding ....................41 6.1 Transmitter, Powering-ON ............27 8.3.1 Standard pairing procedure ..........41 6.2 Transmitter Turning-OFF ............... 27 8.3.2 Alternative pairing procedure through the 6.3 Transmitter Restart ..............27 transmitter menu ............. 42 7. Initial switching-on ................28 8.4 Range test ..................
  • Page 5 computer radio control system 11. Battery Safety Handling Rules ............52 11.1 Transmitter Battery Pack ............52 11.2 General Safety Rules ..............52 11.3 Flight Safety Check ..............53 11.4 Application ..................53 11.5 FCC /IC Information ............... 53...

  • Page 6: Introduction

    1 Introduction Activation method for software modules of JETI model 1.1 DC/DS Make sure you have the most current firmware version in your The DC/DS transmitters were developed and produced with the transmitter. cooperation of professional engineers and world champion pilots.

  • Page 7: Features

    Connect the DC-16 II to your computer and enable USB mode. developed by JETI model in the Czech Republic. This system has been reliably used for many years. Duplex 900MHz NG (Next Generation) - the DC-16 II transmitters feature a backup wireless system for unmatched data transmission safety and reliability.
  • Page 8 computer radio control system The DC/DS may also be charged through the USB to PC interface. The to keep you fully informed while also keeping distractions to a charging progress is shown on the DC/DS display. minimum. Integrated Antenna – the antennas are located behind fully Integrated microphone with voice recognition capability - using integrated covers in both the DC/DS cases for protection against the integrated microphone you can easily prepare your own audio...

  • Page 9: Manual Navigation

    CZ distributor or dealer. Third party transactions are not covered by this warranty. Proof of purchase is required for warranty claims. Repair or replacement decisions are at the sole discretion of JETI model CZ or an authorized service provider. This warranty does not cover cosmetic...

  • Page 10: Package Contents

    computer radio control system 1.6 DC-16 II Package Contents JETI DC-16 II Transmitter, Wall Power Supply, JETI DC Transmitter Aluminum Case, USB PC Cable, Installation Key Set (HEX 1,5; TORX 10), Cleaning Cloth, Instruction Manuals,...

  • Page 11: System Specifications

    computer radio control system 2 System Specifications DC-16 II. DC-16 II. Parameter Parameter Channels Variometer Active Control Inputs (Stick/Switch/Knob) Flight Mode Trim Active Data Stream Logging Backup Module 900MHz NG (next generation) (upgradable) * 863 - 870 MHz (EU), 902 - 928 MHz (US) Telemetry Controls Flight Modes Voice Commands...

  • Page 12: Description Of Transmitter Dc-16 Ii

    computer radio control system 3 Description of Transmitter DC-16 II 3.1. Control Identification Right Stick 1, 2 – the DC-16 II Transmitter Supports Modes 1-4, see Control Sticks -> mode change Left Stick 3, 4 the DC-16 II Transmitter Supports Modes 1-4, see Control Sticks ->...

  • Page 13: Assembly Identification

    computer radio control system 3.2. Assembly Identification DC-16 II Transmitter Battery Pack Memory Card Micro SD 8GB PPM Output Connector Left Gimbal Assembly Right Gimbal Assembly 2.4 GHz Module 900MHz Module NG (Next Generation) PPM Input/Output Battery Connector...

  • Page 14: Control Stick Assembly

    computer radio control system 3.3 Control Stick Assembly Warning: If you have installed optional sticks with switch or button ends, make sure that while adjusting the stick length you observe the Note: When handling with back cover removed always wires that pass through the stick shaft and through the gimbal switch off the transmitter and disconnect the opening in order to prevent damaging the connecting cables.

  • Page 15: Control Stick Tension Adjustment

    computer radio control system Loosen both machine screws securing the control stick By turning the screw clockwise, you will tighten spring tension. As a assembly. result the moving resistance of the control stick will increase. Adjust (rotate) to desired position. Securely tighten both machine screws securing the control stick Reconnect transmitter battery pack and reinstall radio back assembly.

  • Page 16: Throttle Stick Travel Adjustment

    computer radio control system calibrate the transmitter stick in the software menu, see section Calibration of Proportional Controls. 3.3.6 Changing the transmitter mode The transmitter is equiped with universal multimode gimbals. Both gimbals are identical and can be adjusted mechanically for modes 1- 5.

  • Page 17: Transmitter Gimbals With Switch Or Button Installation

    computer radio control system Tighten the screw 3.3.7 Transmitter Gimbals with Switch or Button Tightening the the screws and sets the desired arresting with Installation steps and smooth brake. If you want to operate the DC-16 II transmitter using the optional stick end switch or button functions, you must purchase one or more of these separately: B.
  • Page 18 computer radio control system Disconnect the control stick assembly wires from the Tx board. Adjust length of the stick to suit your flying style. (3 wires X, Y, S Note: After installation of the optional stick ends with switch or Remove the stick assembly connecting wires from their holders.

  • Page 19: Swappable And Assignable Switches

    computer radio control system Install stick unit assembly back to correct position. 3.4 Swappable and Assignable Switches Install and secure the machine screws for the control stick assembly. One of the most important features of a JETI transmitter is the switch function assignment flexibility.

  • Page 20: Digital Trims

    computer radio control system Switch Exchange: 3.5 Digital Trims Switch off the transmitter and remove the 10 screws that secure Transmitter gimbals are used for controlling the basic flight the radio back cover. Next, remove the radio back cover. Be sure functions like throttle, roll(aileron), pitch(elevator), and yaw(rudder).

  • Page 21: Transmitter Battery Pack

    computer radio control system 3.6.2 Battery Replacement 3.6 Transmitter Battery Pack Should you decide to replace the transmitter battery, please follow The DC-16 II transmitter is powered by a Li-Ion type battery pack and these steps: comes equipped with its own built-in advanced battery Switch off the transmitter and remove the 10 screws that management and charging circuit.

  • Page 22: Ppm Output Connector

    computer radio control system 3.7 PPM Input/Output Connector 3.8 Handling The DC-16 II transmitter can be comfortably carried by the antenna The PPM output is accessible via internal connector labeled "B". This cover/handle as shown in the image below. connector features a non-stabilized battery voltage output in the range of 3.2V - 4.2V (max.

  • Page 23: Change Sd Card

    computer radio control system 3.9 Change SD Card Disconnect the battery plug . To open the SD card holder, use a fingernail to push the metal frame to the right and then lift it carefully . The micro SD card can now be removed .

  • Page 24: Help Mode

    computer radio control system This help mode is available in FW min. v5.00. We recommend update 4 Help mode your transmitter by Jeti Studio. It is possible to call up the help mode for each item where a "question mark" icon appears in the upper right corner of the screen .

  • Page 25: Rf Transmitter Modules

    computer radio control system • 5 RF Transmitter Modules "Trainer“mode – one of the RF transmitter modules is assigned to communicate with the instructor/student transmitter only. Communication with the model takes place In order to achieve the highest transmission quality and reliability of via instructor’s transmitter only.
  • Page 26 computer radio control system Recommended connection for Rsat 900 NG as a backup receiver Connecting the RSat 900 NG directly to a Primary receiver : with a Central Box • The RSat 900 NG receiver is plugged into the “Sat1” slot of the •...

  • Page 27: Transmitter Powering On/Off

    computer radio control system 6 Transmitter Powering ON/OFF 6.2 Transmitter Turning-OFF The transmitter is switched-off by pressing the "Power“ main 6.1 Transmitter Powering-ON button. Before complete power-down is achieved you will be asked for additional confirmation. In case of an emergency, a fast turn-off Switching-on is achieved by pressing and holding the "Power“...

  • Page 28: Initial Switching-On

    computer radio control system 7 Initial switching-on 7.1 Main display Turn the transmitter on by pressing and holding the „Power“ button The main screen displays basic information about operation of your for a couple of seconds and then press the "F5 (Yes)" button to transmitter, such as the battery level, time, flight mode, etc.

  • Page 29: Navigation In The Menu

    computer radio control system The lower bar is found at the bottom of the main display. 7.2 Navigation in the Menu The lower bar shows: 7.2.1 Navigation The „menu“ button allows you to switch between the main display and the transmitter‘s main menu. Also, If you push this button while turning the 3D Control Advice: Selector to edit values, the values can be changed faster.

  • Page 30: Browsing Through The Menu

    computer radio control system 7.2.3 Basic Menu Structure - Telemetry Controls * Model - Voice Commands - Select Model - Sequencer - New Model - Basic Properties * Timers/Sensors - Model Image & Colors - Timers - Functions Assignment - Alarms - Servo Assignment - Vario - Servo Setup...

  • Page 31: Model Set-Up Guide

    computer radio control system 7.3 Model Set-up Guide Warning: For safety reasons we recommend first removing the propeller. In this section we will guide you, step by step, through the process of Switch-on the transmitter. In the main creating a new model airplane and helicopter. Each step of the guide display push the key „menu“.
  • Page 32 computer radio control system Select your wing type. Because this The screen will now display a request which example has 2 aileron servos, select „Wing asks if you really want to create and activate type“ 0FLP/2WING. Do not change any the new model.

  • Page 33: Helicopter

    computer radio control system From the main screen, push the „menu“ 7.3.2 Helicopter button. Select „Fine tuning“ and push the Let’s create a simple model helicopter. In this example, the „3D button“. helicopter is controlled by a swash plate with three servos at 120° orientation and the motor has no governor.
  • Page 34 computer radio control system Select the helicopter swash plate type"3 Switch on the transmitter. In the main servos (def 120°)“. Change the second display push the key "menu“. Select the menu item "Position of front servo“ to item "Model“ and push the "3D button“. "Rear“...

  • Page 35: Multicopter

    computer radio control system In the "Fine tuning -> Flight modes“ menu you will setup these The "Swash Mix“ menu displays the travel advanced model control functions for your helicopter: range of each particular helicopter flight function for the swash plate for flybarred Collective pitch curve, see: Fine tuning ->...
  • Page 36 computer radio control system Servo assignment to receiver channels: Select the item „New model“ and push Throttle the „3D button“. Roll (ailerons) Pitch (elevator) Yaw (rudder) Mode (multicopter mode channel) Enter the name of your model and press Before you begin creating a model, make sure that you have setup „F5(OK)“...

  • Page 37: General

    computer radio control system This page displays the flight control Bind transmitter with the receiver, see chapter 8.3 Receiver- functions and their transmitter switch >Binding. Once your transmitter has been bound with the receiver assignments. Here you can verify that your and you have re-applied power to the receiver, the last setup phase is flight control functions are correctly the tuning of your flight controller channels, see chapter 7.3.5...
  • Page 38 computer radio control system Before creating a model, make sure that you have setup the correct Choose an optional model image and transmitter mode in "Main menu -> System -> Configuration -> color profile according to your personal MODE 1-4“. The basic, standardized, assignment of transmitter preferences.
  • Page 39 computer radio control system (spring-loaded switch). After you create all of your desired functions, Once your transmitter has been bound with a receiver and has been press the „F5(Next)“ button to confirm. connected to its power supply, the last step consists of tuning the servo output functions, see chapter 7.3.5: Setup of receiver The "Servo assignment“...

  • Page 40: Setup Of Receiver Outputs

    computer radio control system 7.3.5 setup of Receiver Outputs their full travel. You should use the dual rate function to set your model’s useable control throws. Go to the "Model->Servo Setup“ menu. Use the "F2“ and "F3“ buttons to brows through the receiver outputs (channels). You can scrol through the following servo adjustment items for each channel: „Servo reversing“...

  • Page 41: Duplex Receivers

    computer radio control system 8 Receiver A1/A2 - receiver antennas. The antennas should be installed so that the wires form a 90° angle relative to each other. 8.1 Description 8.2 Installation Whenever possible, you should wrap the receiver in foam and place it as far as possible from sources of interference (servos, electric motors).

  • Page 42: Alternative Pairing Procedure Through The Transmitter Menu

    computer radio control system 8.3.2 Alternative pairing procedure through the 8.4 Range Test transmitter menu The range test will verify that the transmitter and receiver are functioning properly. Turn off the receiver. Keep the transmitter turned on. Before the first flight of each flying session or if have any doubts Plug the "BIND PLUG"...
  • Page 43 computer radio control system Each receiver channel can be configured to one of the modes described above. We recommend that you setup "fail safe“ positions for every output, which enables your model to stay in a stable condition. For instance, the elevator and rudder in neutral positions, electric motor switched-off, gas engine idling, spoilers extended.

  • Page 44: Using Device Explorer To Configure The Receiver

    computer radio control system In the picture above, two receivers have been detected and are Using Device Explorer To Configure the Receiver recognized. When you press the rotary button, you are able to configure them in detail. Here is the example how to use the Device The Device Explorer utilizes the latest Explorer to configure an "REX10 EX"receiver: data/command EX Bus protocol to...
  • Page 45 computer radio control system - Output Period – Determines how often the servo signal will Note: Before a device can be recognized, a special predefined be repeated to the outputs of the receiver. You can select periods configuration scheme must be present on the SD card in from 5ms to 30ms (in 1ms steps).
  • Page 46 computer radio control system On this page (picture ) shows the fail-safe function parameters. you can press the "F4 Apply” button while you are editing this column. The selected value will then appear directly on the servo - Fail-Safe – This parameter tells the receiver how to react when a output without the need to turn off the RF modules which would signal loss event occurs.

  • Page 47: Support Of Remote Commands For Ex Bus Devices

    computer radio control system The page Receiver Outputs (picture )) allows you to redirect your at logical 0. Using this way you can simply control for example lights transmitter’s channels to any output of the receiver. For convenience consisting of several LEDs. The fail-safe configuration is applied in the transmitter’s channel numbers are displayed together with the this mode as well as in servo mode.
  • Page 48 computer radio control system On the main screen of the Central Box settings scroll down to display The list of active commands. the maximum telemetry values (Telemetry Min/Max). Here you will find a choice to assign a switch to the command for deleting measured minimums and maximums (Clear Min/Max switch).

  • Page 49: Rc-Switch

    computer radio control system The switch-related settings are located in Model-> Device Explorer - 8.7 R C-Switch > RC-Switch. First, you have to enable the switch by pushing the rotary button on your transmitter with the first row of the transmitter The RC Switch is a special wireless device that allows you to remotely display highlighted.

  • Page 50: Transmitter To Pc Connection

    computer radio control system 9. Transmitter to PC Connection 9.2 Update firmware The JETI Duplex line of transmitters are equipped with a mini USB The JETI Duplex line of transmitters fully support future software port. The Transmitters also come with a standard USB to mini USB updates.

  • Page 51: System Backup

    computer radio control system 9.4 System Backup 9.7 Copying models between the transmitters Data backup is as easy as the standard backup you can perform on Configuration of all models in the transmitter are stored on the your PC. You can save all your data onto a PC hard drive or CD. The internal SD card in the directory /Model/.

  • Page 52: Battery Safety Handling Rules

    computer radio control system 10 Battery Safety Handling Rules 10.2 General Safety Rules 10.1 Transmitter Battery Pack Any repair, installation, or upgrade must be performed with caution and common sense. These will The Installed battery pack must be charged from an AC voltage require some basic mechanical skills.

  • Page 53: Flight Safety Check

    computer radio control system Do not point the transmitter antenna directly towards your direction of movement for your flight surfaces. model or a human body. The radiation pattern from the antenna will Set motor/engine kill switch and test the power train. be shielded and provide poor connection to your model.
  • Page 54 computer radio control system radioélectrique à l'intention des autres utilisateurs, il faut choisir le THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. type d'antenne et son gain de sorte que la puissance OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS(1) isotroperayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité...
