Summary of Contents for Bushranger Black Max 55X12

  • Page 1 |Black Max Compressor Page 1...
  • Page 2 | Black Max Compressor Page 2...
  • Page 3 Congratulations on your purchase of the Bushranger® Black Max Compressor. To take full advantage of this product, please read this manual carefully before using. Retain this manual for future reference for installation and warranty. |Black Max Compressor Page 3...
  • Page 4 General Operating Instructions (please read) Please read and follow the operating instructions carefully to understand and get the most from your Black Max Compressor. Important: Always operate the compressor within its maximum pressure rating. Refer to the specifications section of this manual for details. Operations exceeding maximum pressure rating will result in damage to air compressor and void warranty.

  • Page 5: Maintenance

    Maintenance • The air filter housing has a screw-on lid to gain access to the replaceable air filter element inside. The compressor’s performance will be greatly reduced by a clogged filter element. Old elements should be replaced before performance is affected. •...

  • Page 6: Tyre Inflation

    Tyre Inflation Attach quick connect coupler to air compressor. Fit brass connector onto tyre valve stem. Check to make sure deflator collar lock is disengaged. Turn compressor switch ‘On’ to begin inflation. When desired pressure is reached turn compressor ‘Off’. Hands Free Continuous Deflation Fit connector onto tyre valve stem.

  • Page 7: Important Safety Instructions

    Fitting Air Filter Unit The air compressor comes originally packed without the air filter unit fitted Procedure: Remove the temporary protective red plug from the air inlet port. Screw in the air filter unit & hand tighten. Do not use Teflon tape or lubricants on the thread.
  • Page 8 Warning: To prevent injuries • Parts of this compressor will become very HOT during & immediately after use. Do not touch any of these parts with your bare hands as you could receive a severe burn. • Never allow children to operate this compressor. Close supervision is necessary when this compressor is being used near children.

  • Page 9: Troubleshooting

    Troubleshooting Problem Cause Action Compressor will not run 1. No power is reaching the 1. Make sure compressor compressor. switch is “On”. 2. Blown fuse. 2. Disconnect compressor from power source, replace fuse (Refer to Specifications sections for correct fuse). 3.

  • Page 10: Specifications

    Specifications Part number: 55X12 Description: Black Max Compressor Motor voltage: 12 Volt Motor type: Permanent Magnetic Max Working Pressure: 150 psi Max flow rate @ 0 psi (13.8V): 66 Litres per minute Max Duty Cycle: 30 mins @ 40psi @ 24°C Max.
  • Page 11 Kingsley Products - Warranty Policy Our Warranty We warrant to you that the Kingsley product is free from defects in workmanship and materials for the warranty period. Fitting and use Please ensure you: a. fit the Kingsley product in accordance with the product information and all relevant vehicle safety and compliance laws b.
  • Page 12 Free Call |1800 654 767 (Australia only) International |+61 2 8700 0400 Fax |+61 2 8700 0499 Email | sales@kingsleyenterprises.com.au Address | 6A Brooks Road, Ingleburn NSW 2565 | Black Max Compressor Page 12...
