Fault Codes, Descriptions, and Possible User Actions

FAULT
FAULT DESCRIPTION
CODE
F100 PDU Fuse Fault
F101 Keyswitch Fault
F102 Voltage Out Of Tolerance
F108 E-Stop Switch Closed
F110 Heat Exchanger Flow Fault
F114 Manifold Temperature Sensor Open
F115 Manifold Temperature Sensor Shorted
F116 Heat Exchanger Temperature Sensor Open
F117 Heat Exchanger Temperature Sensor Shorted
F120 Program CRC Error
F121 Calibration Data Corrupted
Communication Fault Between User Console
F123
and Laser Controller
F124 Laser Diode 1 MOSFET Fault
F125 Laser Diode 2 MOSFET Fault
F126 Laser Diode 3 MOSFET Fault
F127 Laser Diode 4 MOSFET Fault
F128 Laser Diode 1 Power When Not Expected
F129 Laser Diode 2 Power When Not Expected
F130 Laser Diode 3 Power When Not Expected
F131 Laser Diode 4 Power When Not Expected
F300 Chiller Temperature High
F301 Chiller Temperature Low
F302 Chiller State Fault
F303 Manifold Temperature Fault
F304 Heat Exchanger Over Temperature
F305 HCPS Readback Fault
F306 Chiller Communication Fault
F307 Internal HCPS Fault
F308 No Applicators Available
F309 Heat Exchanger Coolant Level Low
F313 Chiller Coolant Level Low
F314 Treatment Timeout
F315 Remote Interlock Open
F400 Laser Diode 1 Temperature Sensor Open
F401 Laser Diode 2 Temperature Sensor Open
F402 Laser Diode 3 Temperature Sensor Open
F403 Laser Diode 4 Temperature Sensor Open
F404 Laser Diode 1 Temperature Sensor Shorted
F405 Laser Diode 2 Temperature Sensor Shorted
F406 Laser Diode 3 Temperature Sensor Shorted
F408 Applicator 1 Contact Open
F409 Applicator 2 Contact Open
850-7026-000 Rev 6 SculpSure
POSSIBLE USER ACTIONS
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Release E-stop switch & restart system using key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Restart the system using the key. If problem persists, call Service.
Retry. If problem persists, call Service.
Retry. If problem persists, call Service.
Retry. If problem persists, call Service.
Allow system to cool and retry. If problem persists, call Service.
Allow system to cool and retry. If problem persists, call Service.
Retry. If problem persists, call Service.
Retry. If problem persists, call Service.
Retry. If problem persists, call Service.
Retry. If problem persists, call Service.
Add coolant to Heat Exchanger tank and retry. If problem persists, call Service.
Check coolant level in right-hand tank, fill if necessary, then retry. If problem
persists, call Service.
Retry. If problem persists, call Service.
Close door; install shorting plug; and retry. If problem persists, call Service.
Continue to operate without the disabled applicator, or restart the system using
the key. If problem persists, call Service.
Continue to operate without the disabled applicator, or restart the system using
the key. If problem persists, call Service.
Continue to operate without the disabled applicator, or restart the system using
the key. If problem persists, call Service.
Continue to operate without the disabled applicator, or restart the system using
the key. If problem persists, call Service.
Continue to operate without the disabled applicator, or restart the system using
the key. If problem persists, call Service.
Continue to operate without the disabled applicator, or restart the system using
the key. If problem persists, call Service.
Continue to operate without the disabled applicator, or restart the system using
the key. If problem persists, call Service.
Continue to operate without the disabled applicator, or restart the system using
the key. If problem persists, call Service.
Continue to operate without the disabled applicator, or restart the system using
the key. If problem persists, call Service.
