Summary of Contents for Easypix Cyberscanner View
- Page 2 WELCOME Thank you for purchasing the Easypix Cyberscanner View. Please take a moment to read through this manual. Before using the Cyberscanner, please ensure that you read and understand the safety precautions described below. Always ensure that the Cyberscanner is operated correctly.
- Page 3 Keep the Cyberscanner and its accessories out of reach of children and animals to prevent accidents or damage to the Cyberscanner. If you notice smoke or a strange odour coming from the Cyberscanner, turn the power off immediately. Take the Cyberscanner to the nearest authorized service center for repair.
- Page 4 harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment on to off, the user is encouraged to try to correct the interference by one or more the following suggestion.
- Page 5 INCLUDING Cyberscanner User’s Manual 135 Slide Holder /Main Holder 135 Film Adaptor 110 Film Adaptor 126 Film Adaptor Clean brush...
- Page 6 Description...
- Page 7 Note: We suggest using bundled brush to insert into the Cyberscanner slot and clean the glass surface periodically to produce a clear image. Please make sure your film negatives/ mounted slides and cover trays are clean before inserting into the Cyberscanner as well. Dust or dirt from the negatives and cover trays will affect the quality of your scanned images.
- Page 8 Start Using Your Cyberscanner 1. Insert the SD Card into the Cyberscanner. Insert the SD card into the SD Card Slot located at the back of the scanner. Make sure that the golden print on the card is facing downward. The card will be locked into place with a gentle push when correctly inserted.
- Page 9 Press the Power Button of your scanner to turn on the scanner. You will see a pop up screen of Home Page on the LCD, select the item you want to operate. There are 4 items (icons) for selection. Note: The Home Page and the Button The Home Page is an important page for the operation of the scanner.
- Page 10 Film Icon: This is the main function of the scanner, and where you to make all the settings for scanning film. For example the setting the type and size of film, the selection for scanning 50x50mm transparent slide, or negative film for 135, 110 and 126 films.
- Page 11 Operation of the Cyberscanner: Settings for film scanning On the home page of the LCD Screen, select the Film icon (preset) by pressing the Button, then OK/( Button to confirm your selection. You will then move to the 2 page of options to select the type of film: 50x50mm slide Colour Negative B&W Negative...
- Page 12 Select the size of film you want to scan by pressing the / Button, then OK/( ) Button to confirm your selection. A preview screen will appear on the LCD screen, you may now insert the film into the scanner through the film holder, and photo of the film will be shown on the LCD Screen, ready for you to convert the photos into digital images and store them on the SD Card.
-
Page 13: Image Resolution
Image Resolution: There are 2 resolutions of scanning and storing your image in the SD Card,14 mega pixels scan and 22 mega pixel scan (by interpolation). The resolution is set by pressing the ( ) button on the Preview mode. The set value is shown on the lower right hand side of the preview screen. - Page 14 Place Slide / Film Into The Holder The Cyberscanner supports 50X50mm transparent slides, color negatives and B&W negative films, for 135/110/126 size films. 1. Scanning 50X50mm Transparent (Positive) Slide: Insert the Main Holder (Slide Holder) according to the triangular mark on the scanner and the holder, in to the slot on the right hand side.
- Page 15 Main Holder to its original position until it locks with a click. Insert the Main Holder (with selected negative Film Adaptor) into the scanner as described in (1). Insert your film strip from the right side of the Holder. Keep the film in position by referring the image shown on the LCD screen.
- Page 16 Image Brightness and Color Adjustment The brightness and color of the image are preset automatically. Normally additional adjustment is not needed however from time to time film brightness and color fade out may need adjustment. Depending on what you want to adjust press the Brightness or RGB buttons and you will see the...
- Page 17 Playback and Delete mode Playback: In scanner Preview mode(Press the button if required), you may review the previously captured images by pressing the (Playback) button and then button for image selection. Pressing the OK/( ) button will allow you to review the selected captured images stored in the SD card.
- Page 18 Important Note: The scanner’s Photo Gallery mode only displays images scanned by the scanner. Images from other devices, for example digital cameras or smartphones, may or may not be displayed by the scanner, due to different file names or image formats. Delete: To delete a captured image, in Playback mode, select the picture you want to delete using the...
- Page 19 SD Card Formatting: If the SD Card (maximum 32GB) used is not compatible with the scanner and not able to perform a scan, your card must be formatted using your computer. Select file system FAT32 to format your card. Formatting your SD Card will delete all the files in your card.
- Page 20 Reviewing the images on a TV screen Connect your Scanner to your TV set using the HDMI Cable. Select the correct HDMI input on your TV that you are connected to, turn on the scanner power and press the Home/Preview Button to allow you to preview the image of your film.
- Page 21 8. Downloading the images from Card to Computer Connect the Type-C USB cable to the scanner and terminal of your computer USB port. Turn on the power of both your computer and scanner. From the Home Page of the scanner, select the USB Icon by button then press the OK/(...
- Page 22 Date and Time settings: You may set the Date and Time in the image file before scanning the image. The Date and Time set will not be printed on the picture of the scanned image, it will only be stored in the electronic file of the image. From the Home Page of the scanner, select the Calendar icon using the buttons and then the OK/(...
-
Page 23: Specifications
The purpose of having Time and Date settings: This setting is useful if you want to apply an estimated time or date to when the images were originally taken. Specifications Image Sensor 1/2.33” 14 Mega CMOS Sensor, Preview and Review 5”... - Page 24 Icons and their functions: Icons Functions and Indication Scanning films Connect SD Card to Computer Reviewing scanned photos in the SD card Setting date and time For transparent film and 50X50mm slides For color negative film For black and white film For 135 film, 24X36mm picture size film For 110 film, 13X17mm picture size film For 126 film, 28X28mm picture size film...
- Page 25 SD card malfunction: Not loaded, locked, or not compatible Reviewing picture from card: single picture Reviewing pictures from card: Slide show Brightness(EV) adjustment scale RGB color adjustment scale RGB color adjustment recover to default setting RGB color selection and reset Single image delete selection All scanned images delete selection Indicate SD card and computer successfully connected...
-
Page 26: Mac System Requirements
V1.0 All product specifications are correct at time of print and are subject to change without prior notice. Easypix GmbH reserve the right for errors or omissions. For technical help please visit our support area on www.easypix.eu. -25-... - Page 27 CONFORMITY The manufacturer hereby declares that the CE marking was applied to the product Cyberscanner View in accordance with the basic requirements and other relevant provisions of the following CE Directives: 2014/53/EU 2011/65/EC RoHs 2014/30/EU EMV 2012/19/EC WEEE The EC Declaration of Conformity can be downloaded here: http://www.easypix.info/download/pdf/doc_cyberscanner_view.pdf...
