4.

Hardware Users Guide

4.1.

Electrical Characteristics

QT5 Xplained Pro can be connected to several Xplained Pro MCU boards and manually connected to
other hardware. Xplained Pro MCU board(s) that does not have 3.3V as it's primary target voltage will
read all ID devices on connected extensions to check if they support the target voltage before enabling it
to the extension headers. The table below shows the static content written in the ID chip.
Table 4-1 QT5 Xplained Pro ID Chip Content
Data field
Product name
Minimum operation voltage
Maximum operation voltage
Maximum current
Related Links
Hardware Identification System
4.2.

Headers and Connectors

4.2.1. Xplained Pro Standard Extension Headers
QT5 Xplained Pro implements one Xplained Pro Standard Extension Header (see also section
Pro Standard Extension Header
to connect the board to an Xplained Pro MCU board with an MCU featuring a PTC module. The pinout
definition for the extension header can be seen in the table below.
Table 4-2 QT5 Xplained Pro Extension Header 1
Pin on EXT
1
2
3
4
5
6
7
8
9
10
11
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
on page 6
on page 6) marked with EXT1 in silkscreen. This header make it possible
Function Description
ID Communication line to ID chip
GND Ground
Y0 Y-line 0: Connected to Slider
Y1 Y-line 1: Connected to Buttons
Not Connected
Not Connected
X0 X-line 0: Connected to Slider and Buttons
X1 X-line 1: Connected to Slider
X2 X-line 2: Connected to Slider and Buttons
X3 X-line 3: Connected to Slider
2
I C SDA Connected to LED driver IC
Atmel QT5 Xplained Pro User Guide [USER GUIDE]
Content
QT5 Xplained Pro
2.7V
5.5V
45mA
Atmel-42637A-QT5-Xplained-Pro_User Guide-12/2015
Xplained
8
