- Page 1 4 x 2 Wallplate User Manual Date 11/12/2019 Revision 01_e Attero Tech by QSC 1315 Directors Row, Suite 107, Ft Wayne, IN 46808 Phone 260-496-9668 • Fax 260-496-9879 www.atterotech.com 614-00036...
-
Page 2: Important Safety Instructions
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. Only use attachments/accessories specified by Attero Tech by QSC 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. - Page 3 Attero Tech QSC shipping costs prepaid, within three years from the date of purchase. This Limited Warranty is governed by the laws of the State of Indiana. It states the entire liability of Attero Tech by QSC and the entire remedy of the purchaser for any breach of warranty as outlined above.
-
Page 4: Table Of Contents
3.3 – 3 Party Control ............................... 11 3.4 – Control Interface Type ............................. 11 3.4.1 – Using the Command interface ........................11 ARCHITECTS & ENGINEERS SPECIFICATION ........................ 12 Device Specifications ..............................13 Attero Tech by QSC 2019 Page 3 614-00036 Rev 01_d... -
Page 5: Overview
The following are available as options for the unDX2IO+ and that may be ordered separately: unAX2I - Passive Dual XLR-F single gang Decora wall plate - P/N: 900-00204-01 (Comes with 3-gang Decora cover plate). Attero Tech by QSC 2019 Page 4 614-00036 Rev 01_d... -
Page 6: Device Installation
Dante Controller. The MAC address is also given on the back of the unit. Attero Tech by QSC 2019 Page 5... -
Page 7: Mounting
Ethernet and power (refer to the devices manual if unsure which port is which). *Note: All Attero Tech by QSC products are tested using UTP cabling and it is recommended that UTP cabling be used when installing them. STP cabling can be used for installation though care must be taken not introduce grounding issues into the system by doing so. - Page 8 Figure 3 - Dimensioned Drawing *Note: 2D and 3D CAD models can be downloaded from the Attero Tech by QSC website. Please contact Attero Tech by QSC for any further product related information that is not accessible on the website.
-
Page 9: Error Reporting
If the LED remains on solid red, this indicates a device failure. If power cycling the unit does not correct this problem, contact Attero Tech by QSC technical support. 2.3 – Hardware Connections The unDX2IO+ provides balanced audio outputs to external analog audio equipment. -
Page 10: Factory Reset
“click” when it’s activated. Hold the switch in for 5 to 10 seconds then release. If the factory reset was successful, the unit will actually reset indicated by the power LED will turning red. Attero Tech by QSC 2019 Page 9 614-00036 Rev 01_d... -
Page 11: Device Configuration
PC/Mac IP address is also changed to an IP in range of the devices new IP address. Further information on IP setup for an audio system using Dante can be found in the FAQ’s on the Audinate website (https://www.audinate.com/resources/faqs). Attero Tech by QSC 2019 Page 10 614-00036 Rev 01_d... -
Page 12: Software Control
There are two control interface types available for the unDX2IO+. The first type is a Dante proprietary interface (-C) which is typically used by devices already that have built-in support for Attero Tech by QSC devices. The second type supports party UDP interface (-U) and is available to anyone to use with any device capable of sending and receiving UDP messages. -
Page 13: Architects & Engineers Specification
The Dante interface shall be in-wall mounting in a standard US dual gang junction box. The Dante interface shall be compatible with Attero Tech by QSC unIFY software for flexible control and monitoring in systems applications. The Dante interface shall be compliant with the RoHS directive. The Dante interface shall be compliant with FCC Part 15 Class A, and CE (E60950 and EN55022 Class A) requirements. -
Page 14: Device Specifications
<-85dBu @ 0dB gain FCC CFR 47 Parts 15B Class A, EN55011 <0.05% at any gain, input System THD: ICES-003 signal 3dB below maximum CE (EN55022 / EN55024) RoHS REACH Attero Tech by QSC 2019 Page 13 614-00036 Rev 01_d...
