Summary of Contents for JACS TD191
- Page 1 TD191 USB Dongle Quick Start Guide Please read this Quick Start Guide and save it for future reference before using the TD191 USB Dongle.
-
Page 2: Legal Information
Unless otherwise required by law, there are no clear guarantee and/or acquiescence are made for the accuracy, reliability and content of this manual. To the maximum extent permitted by applicable law, JACS Solutions Inc. shall not have any liability for any special, incidental, indirect, consequential or punitive damages whatsoever, including but limited to any damages for lost profits, loss of data or information, or any other pecuniary loss, no matter how the loss is caused. -
Page 3: Product Appearance
Product Appearance Thank you for purchasing the JACS product. The following figure is only for your reference. The actual product may be different. 1.Dongle Cap 2.Front Cover 3.Indicator Light 4.USB Connector 5.T-Flash Card Slot 6.Nano-SIM Card Slot Hardware Installation Please use standard nano-SIM card. Inserting non-standard nano-SIM card or standard-SIM card or micro-SIM card could cause the SIM card to be unrecognized or the damage of the card slot. - Page 4 Step2. Install a nano-SIM card to the nano-SIM card slot and a T-flash card to the T-flash card slot. Step3. Slide the front cover gently back into place.
- Page 5 Using Your Dongle Insert the dongle into your device’s USB port securely. The operating system will automatically detect, identify your dongle and start the driver installation wizard. The device will then be recognized as a “Remote NDIS based Internet Sharing Device” in Device Manager on Windows operating systems.
-
Page 6: Health And Safety Information
After the dongle is correctly powered, the indicator light will be on. Different colors indicate the different working status of the dongle, as shown in the following table. Status Description No Light Airplane/Standby mode Solid Red Light Booting up / Searching for a network / Malfunction Solid Green Light Registered on 3G network Blinking Green Light... - Page 7 are choking hazards and may lead to lethal danger and/or critical injury; If improperly shielded, some electronic devices may be affected by the electromagnetic interference from the dongle, such as the electronic system of vehicles. Consult the manufacturers of such devices before using the dongle if necessary; Operating the dongle may interfere with medical instruments such as pacemakers, cochlear implants, and hearing aids.
-
Page 8: Warranty
Defects or damages from allowing any personnel other than a qualified service center or individual authorized by JACS Solutions Inc. to open, modify, or repair the product, or if it is repaired using unauthorized spare parts;... - Page 9 Hereby, JACS SOLUTIONS INC declares that this radio equipment is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. For full text declaration of conformity, visit the Web site www.jacs-solutions.com/certification. Notice: Observe the national local regulations in the location where the device is to be used.
- Page 10 Statement This device complies with part 22/24/27/90 of the FCC rules and Innovation, Science and Economic Development Canada’s licence-exempt RSS(s), operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 11 - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help - This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.
