XRLED 1200 SPOT
PR-8180
This product manual contains important information about the safe installation and use of this
projector. Please read and follow these instructions carefully and keep this manual in a safe place
for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XRLED 1200 SPOT and is the answer not in the manual?

Questions and answers

Related Manuals for PR Lighting XRLED 1200 SPOT

Summary of Contents for PR Lighting XRLED 1200 SPOT

  • Page 1 XRLED 1200 SPOT PR-8180 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD.

  • Page 2: Table Of Contents

    INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS STAND-ALONE MODE MASTER/SLAVE MODE OPERATION MENU REPLACING GOBOS DMX PROTOCOL INDICATION OF LED DISPLAY MAINTENANCE LUBRICATION KEEPING THE PROJECTOR CLEAN...

  • Page 3: Safe Usage Of The Projector

    SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector is for indoor use only, IP20.
  • Page 4 INSTALL THE PROJECTOR SAFETY CORD WARNING CLAMP To pass SAFETY CORD through 2 HOLES for safety! HANDLE CONTROL PANNEL Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp.

  • Page 5: Power Supply - Mains

    POWER SUPPLY-MAINS Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Use the plug provided to connect the mains power to the projector paying attention to the voltage and frequency marked on the panel of the projector. It is recommended that each projector be supplied separately so that they may be individually switched on and off.

  • Page 6: Dmx Terminator

    SETUP OPTIONS-PROJECTOR CONFIGURATION W-DMX PR-8180 XRLED 1200 Spot A device configuration can be set conveniently via pressbutton switch and LCD display. Launch the projector. Press button ENTER more than 5 seconds to unlock panel, LED display shows functional menus which have their own sub-menus for designated functions, the below is the details Press button UP or DOWN if you want to browse through the various Setup Options.

  • Page 7: To Set The Dmx Start Address

    TO SET THE DMX START ADDRESS Each projector must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX start address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the controller.

  • Page 8: Operation Menu

    OPERATION MENU 1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL Standard mode: 1~488 Extended mode: 1~483 DMX Address Short mode:1~495 Reset Are You Sure Standard mode 25 DMX Channel Mode Extended mode 30 (Default is：Standard mode) Short mode 18 Pan Tilt Swap off Pan Tilt Swap (Default is: OFF) Pan Tilt Swap on...
  • Page 9 Self Test Red Dimmer 0-255 Green Dimmer 0-255 Blue Dimmer 0-255 Effect 1 Iris Effect 2 Effect 3 NO Gobo Gobo 1 - Gobo 8 F-Gobo wheel Rotation Reverse Rotation Shake 1 ~ 8 NO Gobo Gobo 1 - Gobo 6 Rotating Gobo Rotation Reverse Rotation...
  • Page 10 DMX Operation Preset Memory User Memory CH1 Strobe 0-255 CH2 Dimmer 0-255 CH3 Red 0-255 CH4 Green 0-255 CH5 Blue 0-255 CH6 Iris 0-255 CH7 F-Gobo 0-255 Operation Mode CH8 R-Gobo 0-255 CH9 Gobo-R 0-255 Static Scene 1～16 CH10 Frost 0-255 CH11 Prism Set 0-255...

  • Page 11: Replacing Gobos

    REPLACING GOBOS ROTATING GOBO WHEEL FIXED GOBO WHEEL Disconnect the fixture from power. Carefully lift off the cover by undoing the 6 fast-fit screws. Before the replacement of fixed gobos, take leaf spring out using finger, push the gobos out carefully and insert new gobos.

  • Page 12: Dmx Protocol

    DMX PROTOCOL Short Standard Extended Function Description mode mode mode No strobe 000-015 Pulse strobe from slow to fast Strobe 016-127 Strobe speed from slow to fast 128-255 Dimmer Dimming from dark to light (0-100%) 000-255 Dimmer Fine Dimmer in 16 Bit precision 000-255 000-000 Color Temp...
  • Page 13 Gobo 4 088-095 Gobo 5 096-103 104-111 Gobo 6 Gobo 7 112-119 Gobo 8 120-127 Rotation from slow to fast 128-159 Reverse rotation from slow to fast 160-191 192-199 Gobo shake 1 from fast to slow Gobo shake 2 from fast to slow 200-207 Gobo shake 3 from fast to slow 208-215...

  • Page 14: Indication Of Led Display

    000-019 Frost 020-255 Frost White 000-019 Prism Prism 020-255 000-063 Stop rotating Prism rotation from slow to fast 064-127 Prism rotation Stop rotating 128-191 Reverse rotation from slow to fast 192-255 Focus 000-255 Linearly focusing Focus Fine 000-255 Focus in 16 precision Zoom Linearly focusing 000-255...

  • Page 15: Lubrication

    LUBRICATION To ensure the continuous rotation of the rotating gobos and linear motion of the lens for focusing, it is recommended that the bearings for the rotating gobos and the 2 shafts for the focusing lens holder be lubricated periodically, preferably every two months.

  • Page 16: Technical Data

    TECHNICAL DATA VOLTAGES: 100V~240V AC，50/60Hz POWER CONSUMPTION: 950W LINGHT SOURCE: Model Atria SL800 Power consumption 800W Rated life 20000 hours COLOURS: RGB(Red Green Blue) Linear Color Mixing with Macros variable speed rainbow effect COLOR TEMP： Linear CT changes: 10000K～2700K GOBOS: 1 Rotating gobo wheel: 6 interchangeable gobos+ white, glass or metal gobos can be fixed Indexable, bi-directionally rotatable and Wheel Scrolling at variable speeds, shakable at variable speeds...
  • Page 17 IRIS: Linearly adjusted with Macro STROBE: Electronic strobe, 0.3~20 F.P.S HEAD MOVEMENT: Pan 0 º ~540º, Tilt 0 º ~270º with auto position correction Swap and Invert functions of Pan and Tilt CONTROL: DMX512, 3 pin, 5 pin interfaces 18 channels in short mode, 25 channels in standard mode, and 30 channels in extended mode. Master/slave mode Stand-alone mode Self-test mode...
  • Page 18 SIZES: DM X W-DMX W - DMX PR-8180 PR-8180 XRLED 1200 Spot XRLED 1200 Spot LIGHT OUTPUT: 11°lux 9771 2443 1086 55°lux 55° ° DISTANCE(m) 1.01 2.02 3.04 4.05 5.06 6.07 11°DIAMETER(m) 55°DIAMETER(m) 4.85 14.55 19.4 24.25 29.1 18/22...

  • Page 19: Electrical Diagram

    ELECTRICAL DIAGRAM 19/22...

  • Page 20: Component Order Codes

    COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 150020260 Atria SL800 600W POWER SUPPLY 192010160 K29-UP600 230W POWER SUPPLY 192010156 ACP-V230D22W3624U1 030060070 40X40X10mm 030060082 120X120X32mm 030060074 92X92X25mm 290151240 HDT-537-3M W10mm PAN BELT 290151328 HTD-885-3M W9mm TILT BELT 030040117 IRIS MOTOR FIXED GOBO WHEEL MOTOR 030040204 ROTATING GOBOWHEEL MOTOR...
  • Page 21 21/22...
  • Page 22 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320020237 Version: 20140507 22/22...
