Page 1: Schematic Diagrams
AV-27260 SCHEMATIC DIAGRAMS COLOR TELEVISION BASIC CHASSIS AV-27260 AV-27260 AV-27260 CD-ROM No. SML200201 No. 51800C COPYRIGHT © 2001 VICTOR COMPANY OF JAPAN, LTD. Dec. 2001... -
Page 2: Standard Circuit Diagram
AV-27260 AV-27260 AV-27260 AV-27260 STANDARD CIRCUIT DIAGRAM q NOTE ON USING CIRCUIT DIAGRAMS • 1. SAFETY Type No indication : Ceramic capacitor The components identified by the symbol and shading are : Mylar capacitor critical for safety. For continued safety replace safety critical : Metalized mylar capacitor components only with manufactures recommended parts. -
Page 3: Table Of Contents
AV-27260 CONTENTS SEMICONDUCTOR SHAPES ..........................2-2 BLOCK DIAGRAM ..............................2-3 CIRCUIT DIAGRAMS ..............................2-5 MAIN PWB CIRCUIT DIAGRAM (1/3) ........................2-5 MAIN PWB CIRCUIT DIAGRAM (2/3) ........................2-7 MAIN PWB CIRCUIT DIAGRAM (3/3) ........................2-9 AV SELECTOR PWB CIRCUT DIAGRAM ...................... -
Page 4: Block Diagram
AV-27260 AV-27260 BLOCK DIAGRAM MAIN PWB CRT SOCKET PWB R, G, B TU001 TUNER R, G, B CF021 SCL0 SCL0 4.5MHz SDA0 VIDEO/Y SDA0 TRAP J601 COM_Y RGB DRIVE IC101 COMPONENT COM_CB CF041 VIDEO-IN COM_CR 4.5MHz BPF 1 CHIP DECODER VC_R VC_G VC_B... -
Page 5: Circuit Diagrams
AV-27260 AV-27260 CIRCUIT DIAGRAMS MAIN PWB CIRCUIT DIAGRAM (1/3) MAIN PWB ASS'Y SGC-1020A-M2 (AV-27260 SGC-1025A-M2 (AV-27260 SGC-1019A-M2 (AV-27260 J601 QNN0349-002 R610 R140 5.6k R237 ∗4 C601 D606 3.9k Q131 Q233 C136 C131 R601 ∗1 R136 C135 ∗1 LC601 47/25 R231 C233 8.8V 10/16... -
Page 6: Main Pwb Circuit Diagram (2/3)
AV-27260 AV-27260 MAIN PWB CIRCUITDIAGRAM (2/3) J810 QNS0001-001 COMPULINK MAIN PWB ASS`Y COMPULIN CN00C SGC-1020A-M2 (AV-27260 R827 R769 6.8k SGC-1025A-M2 (AV-27260 3.0V 3.6V Q701 ∗2 D810 SGC-1019A-M2 (AV-27260 MTZJ5.6B-T2 2.4V R740 R772 IC621 LA4485 AUDIO AMP K941 QQR0621-002Z CONTROL CONTROL R737 CN0SS 2.2k... -
Page 7: Main Pwb Circuit Diagram (3/3)
AV-27260 AV-27260 MAIN PWB CIRCUIT DIAGRAM (3/3) CN0PW QMPD200-200-JC POWER CORD AC120V 60Hz CN0PW R998 2.7M QRZ9041-275 F901 QMF51U1-5R0-J8 VA901 FC901 ERZV10V621CS IC421 IC421 IC421 LA7841 CEMG002-001Z V.OUT ! C997 AC125V QCZ9052-102 R999 D423 55Vp-p(v) 32Vp-p(v) C901 THERMAL QFZ9067-104 (120 1/2W) D958 PROTECTION R431... -
Page 8: Av Selector Pwb Circut Diagram
AV-27260 AV-27260 AV SELECTOR PWB CIRCUIT DIAGRAM R558 Y551 IN1/OTH PiP Video SW(IC502) BA7612AN IC504 IC504 R552 R501 (CTL A) (CTL B) Q513 R520 SV1/OTH 0.9Vp-p(H) 0.55Vp-p(H) SEL_3 SEL_4 R525 R526 R527 Q502 J501 D501 R553 1.8k ∗ ∗ C501 R521 IC503 V1(IN1) -
Page 9: Pip Pwb Circuit Diagram
AV-27260 AV-27260 PIP PWB CIRCUIT DIAGRAM AFT2 QQL244K-4R7Z L101 0.22 QQLZ014-R22 R103 C103 9V_VC L113 SF101 R101 C006 CE42589-201 5.6k R1/2 47/25 C101 0.01 TUNER Q101 R115 TU001 ADRS LOCK C105 R104 C104 QAU0228-001 R102 0.01 0.01 SCL SDA 1.8k TUNER R117 R008... -
Page 10: Crt Socket Pwb Circuit Diagram
AV-27260 CRT SOCKET PWB CIRCUIT DIAGRAM TP-B ∗ V01 Y003 R362 1.5k R1/2 PICTURE TUBE QRZ0111-152 R365 L353 OMR2 148.8V R369 Q353 PICTURE TUBE 2.6V 2SC4544-LB R372 B.OUT Q356 2.3V R375 C356 R353 470p TP-R SK351 R368 C353 R356 R359 QNZ0537-001 1.8k SOCKET... -
Page 11: Front Control And Front Av Input Pwb Circuit Diagrams
AV-27260 FRONT CONTROL AND FRONT AV INPUT PWB CIRCUIT DIAGRAMS -FRONT CONTROL- IC701 GP1U281Q REMOCON D701 RECEIVER (RED) GL2PR6 POWER VOL+ VOL- MENU R708 R707 1.5k 3.3k C701 S701 R709 S706 S705 S704 S703 S702 47/25 Q701 1.7V QSW0619 QSW0619 QSW0619 QSW0619 QSW0619... -
Page 12: Pattern Diagrams
AV-27260 AV-27260 PATTERN DIAGRAMS CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, MAIN PWB PATTERN REPLACE ONLY WITH SAME TYPE AND RATED FUSE (S) AND ROHM'S MFR'S TYPE CP(S). W331 W610 LC601 K941 J601 W655 R531 W628 LC602 Y002 W825 R537 D521 W612 D534... -
Page 13: Av Selector Pwb Pattern
AV-27260 AV-27260 AV SELECTOR PWB PATTERN R229 R230 R231 W220 C237 C251 R242 C244 L251 C243 L201 C241 C242 R245 C232 R246 R236 Q219 R247 R248 R269 C204 C262 R216 FRONT W197 R265 R270 C214 W274 Q262 R566 W060 C263 W317 C212 W105... -
Page 14: Crt Socket Pwb Pattern
AV-27260 AV-27260 CRT SOCKET PWB PATTERN PIP PWB PATTERN FRONT R372 W082 W005 R352 Q101 C101 W011 R104 PIP TUNER/IF W083 R358 R117 W003 W093 C103 R111 R353 W053 C391 C006 R355 R113 W094 R359 Y001 R370 C355 L101 L352 R369 R373 SF101... -
Page 15: Front Control And Front Av Input Pwb Patterns
AV-27260 AV-27260 FRONT CONTROL AND FRONT AV INPUT PWB PATTERNS - FRONT CONTROL - MENU VOL- VOL+ POWER POWER LED FRONT S702 S701 S703 S705 S706 S704 D701 R705 IC701 R707 R708 CKF1531-B01-1 MARK CN007 WATO 01.06.13 UL MARK R709 C701 W003 - FRONT AV INPUT -... -
Page 16: Channel Chart (Us)
AV-27260 CHANNEL CHART (US) MODE CHANNEL MODE CHANNEL TUNER TUNER BAND BAND BAND BAND CATV REAL DISP. CATV REAL DISP. W+35 W+36 W+37 W+38 W+39 W+40 W+41 W+42 W+43 W+44 W+45 W+46 W+47 W+48 W+49 W+50 W+51 W+52 W+53 W+54 W+55 W+56 W+57... -
Page 17: Channel Chart (Ca)
AV-27260 CHANNEL CHART (CA) MODE CHANNEL MODE CHANNEL TUNER TUNER BAND BAND BAND BAND CATV REAL DISP. CATV REAL DISP. W+35 W+36 W+37 W+38 W+39 W+40 W+41 W+42 W+43 W+44 W+45 W+46 W+47 W+48 W+49 W+50 W+51 W+52 W+53 W+54 W+55 W+56 W+57... - Page 18 JVC SERVICE & ENGINEERING COMPANY OF AMERICA DIVISION OF JVC AMERICAS CORP. Head office : 1700 Valley Road, Wayne, New Jersey 07470 (973)317-5000 East Coast : 10 New Maple Avenue, Pine Brook, New Jersey 07058 (973)396-1000 Midwest 705 Enterprise St. Aurora, Illinois 60504...
