T-2810
Riser ring, bike and Smartphone not included with trainer.
ROCK AND ROLL | SMART 2
LOCK RING
LEFT
LEG EXTENDER
Supported ANT+ Device Profiles:
©2018 KINETIC BY KURT ALL RIGHTS RESERVED
LEFT
TENSIONING
KNOB
LEG
BOLT
TRAINER
TENSION BOLT
Newest user manual available at:
kurtkinetic.com/support
NON-DRIVE SIDE
CONE CUP
RESISTANCE UNIT
Download
the Kinetic
Fit app and
activate your
free trial
subscription
Today
www.kinetic.fit
DRIVE SIDE
QUICK RELEASE
CONE CUP
LEVER
FLYWHEEL
ROLLER TENSION KNOB
RIGHT
TENSIONING
KNOB
RIGHT
LEG EXTENDER
INRIDE SENSOR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KINETIC ROCK AND ROLL SMART 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kurt KINETIC ROCK AND ROLL SMART 2

  • Page 1 LOCK RING RIGHT TENSIONING KNOB NON-DRIVE SIDE CONE CUP LEFT TENSIONING KNOB FLYWHEEL RESISTANCE UNIT RIGHT LEG EXTENDER BOLT LEFT LEG EXTENDER INRIDE SENSOR Supported ANT+ Device Profiles: ROLLER TENSION KNOB TRAINER TENSION BOLT ©2018 KINETIC BY KURT ALL RIGHTS RESERVED...
  • Page 2: Getting Started

    GETTING STARTED Getting Started With Training Apps Kinetic Smart 2 fluid trainers connect to training apps and send speed, cadence, power data and more. Check on each app web site to learn how to connect your trainer. Our partner apps all offer iOS and Android versions Kinetic Fit Zwift to connect directly with Kinetic Smart 2 trainers via Bluetooth Smart.
  • Page 3 MOUNTING THE BIKE QUICK Grip RELEASE frame at seat stay Roller tension knob is fully tightened at factory and must CENTER WHEEL ON be loosened before ROLLER ROLLER mounting bike. TENSION KNOB First loosen roller tension knob to create space for tire. Next loosen lock Push right tensioning knob tight against skewer, close quick release ring and turn left tensioning knob to center bike and tighten right tensioning knob until tire is centered on roller...
  • Page 4: Safety Warnings

    SAFETY WARNINGS RECOMMENDED SKEWER AND CONE COMBINATION* » Be sure that your bike is correctly installed and securely locked into the trainer before riding. » Do not over-tighten the roller tension knob. Over-tightening will cause both tire and unit damage. Tighten only enough to avoid tire slippage.
  • Page 5 TRAINER PARTS T-2302 Bottom Frame T-2301 T-2303 Top Frame Leg Extenders hex key T-2201 Cross bar and screws T-2202 Roller Tension Knob WHEEL and Washer ROLLER T-2203 Spring SERIAL NUMBER T-2204 Because we T-699C Mounting Bolt test each T-740 trainer there Resistance and Nut will be tire...
  • Page 6: Warranty

    WARRANTY Kinetic by Kurt offers the original owner a lifetime warranty against WARRANTY CLAIMS/REPLACEMENT PARTS manufacturing defects for the frame and the resistance unit. This If you experience problems with your trainer, please call our Customer warranty is not applicable to damage caused by misuse, abuse, neglect, Service Hotline at 877-226-7824 or contact us at www.kurtkinetic.
  • Page 7: Montage

    Sie bitte unsere Hotline an: Kunden Hotline: 877-226-7824 oder schreiben Sie an BEFESTIGEN DES RADES kineticbykurt@kurt.com. Um Ihr Problem schnellstmöglich zu behandeln, halten Sie bitte 1. Lösen Sie den Rollenwiderstand am Drehknopf um genug Raum für den Reifen zu die Seriennummer für unsere Servicemitarbeiter bereit.
  • Page 8: Montaje

    GARANTÍA PUESTA EN MARCHA Kinetic by Kurt ofrece al propietario original una Garantía ilimitada de por vida en el Kinetic Fit Power Training App : GRATIS 6 meses de suscripción con la compra de un Smart bastidor, garantía de 2 años en la unidad de resistencia. Esta garantía no es aplicable Control a daños causados por mal uso, abuso, negligencia, accidente o modificaciones no...
  • Page 9 3. Créez un compte d’utilisateur et un profil GARANTIE 4. Branchez le Trainer et couplez-le à l’application Kinetic by Kurt offre au premier propriétaire une garantie à vie inconditionnelle sur le “Kinetic Fit” châssis, garantie de deux ans sur l’unité de résistance. Cette garantie ne s’applique 5.
  • Page 10: Garanzia

    GARANZIA 4. Collegare il trainer e accoppiarlo alla app kinetic fit Kinetic by Kurt offre al proprietario originale una Garanzia incondizionata a vita sul telaio, 5. Seguire le istruzioni ed iniziare l’allenamento garanzia di due anni sull’unità di resistenza. Questa garanzia non si applica ai danni...
  • Page 11 GARANTIE Kinetic Fit Power Training App: GRATIS 6 maanden abonnement bij aankoop van een Smart Kinetic by Kurt biedt de onvoorwaardelijke levenslange garantie op het frame, 2 jaar Control garantie op de weerstandsunit Deze garantie geldt niet voor schade veroorzaakt door 1.
  • Page 12 5280 Main Street NE Minneapolis, MN 55421 • 1.877.226.7824 www.kurtkinetic.com ©2018 KINETIC BY KURT ALL RIGHTS RESERVED...
