Important: Retain these instructions
These instructions shall be used be used by trained service personnel only
If the equipment is used in a manner not specified by these instructions, the protection provided by the equipment may be impaired.
ConTenTS
1
Unpacking .....................................................................1
2
Storing ...........................................................................1
3
Installation .....................................................................1
3.1
Installation - Mounting ...................................................1
3.2
Installation - Configuring ...............................................5
4
Connecting a Remote 2-Line Display ...........................9
5
Connecting to PC via Supervisor Port ..........................9
6
7
Mounting in an Enclosure, ENCLs/... ..........................10
1

UnpaCkIng

2

SToRIng

3

InSTallaTIon

3.1

Installation - Mounting

Dimensions
1
A
B
C
D
339 mm (13.35")
c
R X
A D D R E S S B A U D
O K
S W 4
1
3
2
5
4
6
7
8
9 1 0
T X
, 2
)
*
+
,
IQ23x Series Controllers Installation Instructions TG200539 Issue 2 , 23-Feb-2012
+50 °C
-10 °C
ADDRESS
BAUD
RX
OK
TX
DP
93 mm
(3.66")
d
0 °C
+45 °C
0 %RH
90 %RH
H O
2
Altitude: 2000m (6562')
Installation Instructions
Series Controllers
8
Replacing the Battery ..................................................11
9
Zero Address/Baud Rate Switch Reset ......................13
10
Replacing an IQ111 with an IQ231 ..............................14
11
Replacing an IQ111+ with an IQ231 ............................19
12
Replacing an IQ131 with an IQ233 .............................24
13
Replacing an IQ131+ with an IQ233 ...........................28
14
15
Disposal .......................................................................40
0
90 %RH
H O
2
It is recommended that the installation should comply
with the local electrical safety installation practices
(e.g. HSE Memorandum of Guidance on Electricity
at Work Regulations 1989, For USA National Electric
Code).
Mounting Requirements
2
a
1 3
! N

!
"
#
$
%
&
'



 !
 "
 #
 $
 %
 &
 '
b
ADDRESS BAUD
SW4
1 2 3 4 5 6 7 8 9 10
A
B
C
D
e
ADDRESS
BAUD
A
B
C
D
IQ23x
IQ23x Installation
Instructions TG200539
1 3
! N
8
8


!
"
#
$
%
&
'




!
"
#
$
%
&
'



 !
 "
 #
 $
 %
 &
 '


!
"
#
$
%
&
'


RX
OK
TX
A D D R E S S B A U D
R X
O K
1
3
2
4
5
6
7
9 1 0
8
S W 4
T X
DP
, 2
)
*
+
,
The unit must
RX
OK
be installed in
TX
an enclosure
DP
A
B
C
conforming to
D
EN61010-1

R X
A D D R E S S B A U D
O K
S W 4
1
3
2
5
4
7
6
8
9 1 0
T X
J 1 6
D P
D e v B
J 1 5
D e v A
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IQ23 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for TREND IQ23 Series

  • Page 1: Table Of Contents

    Installation Instructions IQ23x Series Controllers Important: Retain these instructions These instructions shall be used be used by trained service personnel only If the equipment is used in a manner not specified by these instructions, the protection provided by the equipment may be impaired. ConTenTS Unpacking ..............1 Replacing the Battery ..........11...
  • Page 2 19k2 baud Wires Belden 9182 1000 m 1000 m 700 m Belden 9207 1000 m 1000 m 500 m Trend Tp/1/1/22/HF/500 1000 m 700 m 350 m (Belden 8761) Trend Tp/2/2/22/HF/500 1000 m 500 m 250 m (Belden 8723) Terminal size 0.5 to 2.5 mm...
  • Page 3 Installation Instructions IQ23x Installation - Mounting (continued) Connect Inputs Trend TP/1/1/22/HF/500 (Belden 8761) cable ADDRESS BAUD recommended for all inputs Terminal size 0.5 to 2.5 mm Universal Inputs In1 to In20 earth flange " &  "  & I N 1...
  • Page 4 IQ23x Installation Instructions Installation - Mounting (continued) Connect outputs Trend TP/1/1/22/HF/500 (Belden 8761) cable recommended for voltage outputs Terminal size 0.5 to 2.5 mm2 ADDRESS BAUD analogue Voltage outputs, B1 to B12 " & earth flange * " * &...
  • Page 5: 3.2 Installation - Configuring

    Installation Instructions IQ23x 3.2 Installation - Configuring Switch off Isolate I/o, and aux open panel Supply A D D R E S S B A U D 9 1 0 S W 4 ADDRESS BAUD J 1 6 D e v B J 1 5 D e v A WaRnIng:...
  • Page 6 IQ23x Installation Instructions 3.2 Installation - Configuring (continued) Remove Cover A D D R E S S B A U D A D D R E S S B A U D CaUTIon: This unit contains static sensitive devices. Suitable anti-static precautions should be taken throughout this operation to prevent damage to the units.
  • Page 7 Installation Instructions IQ23x 3.2 Installation - Configuring (continued) Replace Cover Switch on A D D R E S S B A U D replace 5 screws Check Controller ADDRESS BAUD (power) (green) Check supply (fail) (red) IQ Faulty Check network I Q 2 3 x (yellow) I Q 2 3 x...
  • Page 8 IQ23x Installation Instructions 3.2 Installation - Configuring (continued) Configure IQ Configuration Manual 90-1533 IQ23x Data Sheet TA200538 SET Manual TE200147 or PowerTool Manual TE200163 if autodialled X.IQ2 IQ23x PowerTool ADDRESS BAUD X.IQ2 also set time, 9 Way ‘D type’ day, date Female IQ23x Cable/EJ101442...
  • Page 9: Connecting A Remote 2-Line Display

    Installation Instructions IQ23x ConneCTIng a ReMoTe 2-lIne DISplay (if KIT/2xx/RDS has been fitted) ensure /RDS Installed Switch off KIT/2xx/RDS Installation Instructions TG103128 Connect Display Switch on (FPK or HDP) Connector Test adjust Viewing angle (if faint) Display Panel angle adjust screw Manual 90-1505 ConneCTIng To pC VIa SUpeRVISoR poRT Connect RS232...
  • Page 10: Connecting To Ndp Via Supervisor Port

    IQ23x Installation Instructions ConneCTIng To nDp VIa SUpeRVISoR poRT Configure Address See section ‘Connecting to PC via Supervisor Port’, steps 1 & 2 above Configuration Mode, addRess Module sUpervisor port addr = 1,4 to 9, 11 to 119 sUpervisor port addr = 0 Connect nDp to Controller Test ADDRESS...
  • Page 11: Replacing The Battery

    Installation Instructions IQ23x ReplaCIng THe BaTTeRy Upload Strategy Switch SET Manual TE200147 PowerTool Manual TE200163 SET cannot upload over autodial link RJ11 SET or PowerTool ADDRESS BAUD 9 ‘D type’ Female X.IQ2 IQ23x Cable/EJ101442 IQ23x See section 5 ‘Connecting to PC via Supervisor Port’...
  • Page 12 IQ23x Installation Instructions ReplaCIng THe BaTTeRy (continued) Replace Cover A D D R E S S B A U D replace 5 screws Switch on Wait Download Strategy SET Manual TE200147 PowerTool Manual TE200163 SET cannot download over autodial link RJ11 SET or PowerTool...
  • Page 13: Zero Address/Baud Rate Switch Reset

    Installation Instructions IQ23x ZeRo aDDReSS/BaUD RaTe SWITCH ReSeT Backup, Switch off, Isolate, open panel Replace the battery, see section 8 ‘Replacing the Battery’, steps 1 to 4 above note the network address and Set all Switch poles to Zero Baud Rate ADDRESS BAUD ADDRESS...
  • Page 14: Replacing An Iq111 With An Iq231

    IQ23x Installation Instructions ReplaCIng an IQ111 WITH an IQ231 Survey Unit Subject Question action Required additional equipment Fixing Are fixing bars used? If NO must drill new fixing holes Is panel depth greater than 93 mm? If not, can this be modified? Are current outputs used? If YES replace SRMI with SRMV (or SRMV (one for each SRMI,...
  • Page 15 Installation Instructions IQ23x ReplaCIng an IQ111 WITH an IQ231 (continued) Upload IQ111 Strategy WupDn Manual TE200162 PowerTool Manual TE200163 WupDn or 25 Way ‘D type’ 1 3    PowerTool Male X.IQF 9 ‘D type’ Female IQ111 1 3    IQ111 Cable/58-0750 note network address...
  • Page 16 IQ23x Installation Instructions ReplaCIng an IQ111 WITH an IQ231 (continued) Remove all Connections Remove Cover IQ111 IQ111 Check Setup Note Baud Rate Settings 9 K 6 S u p e r v i s o r 1 K 2 1 9 K 2 Note input link settings 9 K 6 N e t w o r k...
  • Page 17 Installation Instructions IQ23x ReplaCIng an IQ111 WITH an IQ231 (continued) Connect network Connect Inputs if used - see step 7 above Signal leads should plug in channel for channel - see section A D D R E S S B A U D ‘Installation - Mounting’, step 6 (page 3) R+R-T+T-...
  • Page 18 IQ23x Installation Instructions ReplaCIng an IQ111 WITH an IQ231 (continued) Make IQ2xx Changes either upload to SET and make changes, or change in configuration mode - see section ‘Installation - Configuring’ step 14 (page 8). loop Reschedule Time: Multiply by 5 and re-enter Sensor Scaling Mode 1: If sensor outputs a voltage signal, and scaling mode 0, linear is being used, multipy T and B by 2 and re-enter.
  • Page 19: Replacing An Iq111+ With An Iq231

    Installation Instructions IQ23x ReplaCIng an IQ111+ WITH an IQ231 Survey Unit Subject Question action Required additional equipment Fixing Is it fixed in a small box (380 x 380 If YES, must drill new fixing holes x 80 mm) using semicircular cutout fixings? Is panel depth greater than 93 mm? If not, can this be modified?
  • Page 20 IQ23x Installation Instructions ReplaCIng an IQ111+ WITH an IQ231 (continued) Switch off Isolate I/o, network " & '   I Q 1 1 1 + WaRnIng: The connecting leads may be connected supplies. Isolate before touching. open panel Check Connections is local supervisor is external 2DP fitted? connected?
  • Page 21 Installation Instructions IQ23x ReplaCIng an IQ111+ WITH an IQ231 (continued) Note address Check Setup Note baud rate settings " & '   A D D R E S S B A U D Note input link settings e.g. Address = 2 + 16 = 18 19k2 baud Check for 9k6 baud...
  • Page 22 IQ23x Installation Instructions ReplaCIng an IQ111+ WITH an IQ231 (continued) Connect auxiliary Supply if used - see step 6 above 0 24 see page 4 step 8 A D D R E S S B A U D 2 wide extension cable provided in KIT/IQ23x/UPGRADE Set network Baud Rate to previous...
  • Page 23 Installation Instructions IQ23x ReplaCIng an IQ111+ WITH an IQ231 (continued) Connect local Supervisor Connect external nDp if noted in step 6 above - see section 5 if noted in step 6 above - see section 6 ‘Connecting to PC via Supervisor Port’ ‘Connecting to NDP via Supervisor Port’...
  • Page 24: Replacing An Iq131 With An Iq233

    IQ23x Installation Instructions ReplaCIng an IQ131 WITH an IQ233 Survey Unit Subject Question action Required additional equipment Fixing Are fixing bars used? If NO must drill new fixing holes Is panel depth greater than 93 If not, can this be modified? Are current outputs used? If YES replace SRMI with SRMV SRMV (one for each SRMI, or...
  • Page 25 Installation Instructions IQ23x ReplaCIng an IQ131 WITH an IQ233 (continued) Upload IQ131 Strategy WupDn Manual TE200162 PowerTool Manual TE200163 WupDn or 25 Way ‘D type’ 1 3  !  PowerTool Male X.IQF 9 ‘D type’ Female IQ131 1 3  !  Cable/58-0750 IQ131 Switch off...
  • Page 26 IQ23x Installation Instructions ReplaCIng an IQ131 WITH an IQ233 (continued) Note supervisor baud 1k2 9k6 Check Setup BAUD rate settings after removing node card step 10 Node Note input link settings Supervisor 3 4 5 6 7 8 D U M B Check network address on integral CNC O F F N O R M...
  • Page 27 Installation Instructions IQ23x ReplaCIng an IQ131 WITH an IQ233 (continued) Connect outputs Connect auxiliary Supply if noted in step 6 above. See section ‘3.1 Installation - Mounting’, step 8 Channels previously linked as current (I) will need: Note: Rewire +24 Vdc from either (a) Replace SRMI by SRMV or (2SRM for pair of 24 Vdc terminal on IQ131 A D D R E S S...
  • Page 28: Replacing An Iq131+ With An Iq233

    IQ23x Installation Instructions ReplaCIng an IQ131+ WITH an IQ233 Survey Unit Subject Question action Required additional equipment Fixing Is it fixed in a small box (380 x 380 x 80 If YES, must drill new fixing holes mm) using semicircular cutout fixings? Is panel depth greater than 93 mm? If not, can this be modified? Power...
  • Page 29 Installation Instructions IQ23x ReplaCIng an IQ131+ WITH an IQ233 (continued) Switch off Isolate I/o, network " & '   I Q 1 3 1 + WaRnIng: The connecting leads may be connected to supplies. Isolate before touching. Check Connections open panel is local supervisor is external 2DP fitted?
  • Page 30 IQ23x Installation Instructions ReplaCIng an IQ131+ WITH an IQ233 (continued) Note address Check Setup Note baud rate settings " & '   A D D R E S S B A U D Note input link settings e.g. Address = 2 + 16 = 18 19k2 baud Check for 9k6 baud...
  • Page 31 Installation Instructions IQ23x ReplaCIng an IQ131+ WITH an IQ233 (continued) Connect auxiliary Supply if noted in step 6 above. See section ‘3.1 Installation - Mounting’, step 8 0 24 Note: Rewire +24 Vdc from 24 Vdc terminal on IQ131 A D D R E S S B A U D into one terminal of 2 way extension connector and rewire 0 V from adjacent 0 V terminal on IQ131 to...
  • Page 32: Installing An Auxiliary Internal Node Board

    IQ23x Installation Instructions InSTallIng an aUxIlIaRy InTeRnal noDe BoaRD FRoM a ReplaCeD ConTRolleR kIT/noDe/IQ23x IQ131 Internal CnC Board All the parts required to install a node into the IQ23x are The IQ131 auxiliary internal CNC node board is replaced included in KIT/NODE/IQ23x. by the IQ233 firmware node, so the CNC board can be discarded.
  • Page 33 Installation Instructions IQ23x InSTallIng an aUxIlIaRy InTeRnal noDe BoaRD FRoM a ReplaCeD ConTRolleR (continued) Remove network links Connect local network Cable Not ANC, AND, MNC, TMN if on internetwork. Not INC2 if used as internetwork repeater pull off links (dumb/normal = normal, address >= 100). A D D R E S S B A U D CABLE/EJ103086...
  • Page 34 IQ23x Installation Instructions InSTallIng an aUxIlIaRy InTeRnal noDe BoaRD FRoM a ReplaCeD ConTRolleR (continued) Connect power Cable to node Connect power Cable to IQ23x Board Pre-TMN type boards CABLE/EJ103087 CABLE/EJ103087 polarized connector POWER P O W E R A D D R E S S B A U D R S 2 3 2 A ensure socket is connected to correct terminal pins...
  • Page 35 Installation Instructions IQ23x InSTallIng an aUxIlIaRy InTeRnal noDe BoaRD FRoM a ReplaCeD ConTRolleR (continued) Connect local network to node Board (8 wide) Rewire cable EJ103086 Connect cable CABLE/EJ103086 Remove R - R + R - R + 4 way plug CABLE/EJ103086 L A N J 1 5...
  • Page 36 IQ23x Installation Instructions InSTallIng an aUxIlIaRy InTeRnal noDe BoaRD FRoM a ReplaCeD ConTRolleR (continued) Connect Internetwork and Internetwork Segment B to node Board Internetwork for INC, INC2 Internetwork Segment B for INC2 if used as internetwork repeater (dumb/normal = normal, address >=100) Place Cable in Gland Close Gland A D D R E S S...
  • Page 37 Installation Instructions IQ23x InSTallIng an aUxIlIaRy InTeRnal noDe BoaRD FRoM a ReplaCeD ConTRolleR (continued) Connect RS232 to node Board for CNC, PNC, ANC, XNC+, XN28, AND, CNC2, PNC2, TMNE a Knock out RS232/modem hole b Fit appropriate cable’s connector to hole for CNC, CNC2, PNC, PNC2, A D D R E S S B A U D...
  • Page 38 IQ23x Installation Instructions InSTallIng an aUxIlIaRy InTeRnal noDe BoaRD FRoM a ReplaCeD ConTRolleR (continued) Connect Device to IQ23x RS232/Modem Connector CnC, CnC2 pnC, pnC2 anC, anD, xn28, TMne Modem/ Terminal Adaptor 25 Way D type Male 25 Way D type Male 9 Way D type Female special cable, pins 3,7,20 CABLE/58-2894...
  • Page 39 Node Controller Data Sheet Check network baud rate. Check network address and bumb/normal switch. Check 2nd network/device baud rate. Check Trend lan and Internetwork sections Do separate check fo each Lan/Internetwork segment PWR ON (green) Check supply W/DOG...
  • Page 40: Disposal
