Before You
Use This
Machine
Before you can send or receive fax messages,
please take about 30 minutes to set up your machine.
Set up your machine using the following procedures.
Keep going...
Printed Matters
H5358671_COVER_A4.pm6
1
00.12.8, 10:35 AM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fax 2100L and is the answer not in the manual?

Questions and answers

Related Manuals for Ricoh Fax 2100L

Summary of Contents for Ricoh Fax 2100L

  • Page 1 Before You Use This Machine Before you can send or receive fax messages, please take about 30 minutes to set up your machine. Set up your machine using the following procedures. Keep going... Printed Matters H5358671_COVER_A4.pm6 00.12.8, 10:35 AM...

  • Page 2: Installing The Toner Cassette

    Installing the Pull the front cover release lever in the Hold the toner cassette as shown in the Toner direction indicated by the arrow and open illustration and set it in the machine. Make the front cover. sure that the pins (marked with “ ”...

  • Page 3: Installing The Main Paper Cassette

    Installing the Press down on the cassette until it locks Install the cassette. Push it in firmly until it Main Paper into place. locks into place. Note Cassette T If you do not push the cassette in fully, the cover will not close.

  • Page 4: Attaching The Trays And Docu- Ment Table

    Attaching the Attaching the Hold the Document Delivery Tray at the Quick Dial Trays And Docu- points indicated by the circles in the illustration, then attach it to the fax machine. Attach the Document Delivery Sheet ment Table Tray. Unpack the Quick Dial sheet, then remove The machine has three types of trays.

  • Page 5: Connecting To The Telephone Line

    Connecting the Connecting to Power and the Tele- Switching On phone Line Insert the power cable into the socket There are two similar sockets located at the rear located at the rear of the machine. of the machine: TEL1: For the optional handset or external telephone Plug the cable into a wall socket.

  • Page 6: Initial Settings & Adjustments

    Initial Settings & The keys used for making settings are as fol- Press the [OK] key. Adjustments lows. A. (If you select a country or region name in step 3, the following display will appear.) [OK] key Year: Press OK [2001] B.
  • Page 7 Country Code List Use the number keys to enter the correct Enter your office, company, or personal number for the date (1~31) and press the name, or any other appropriate identifica- Code Country / Region Name Code Country / Region Name [OK] key.
  • Page 8 Use the number keys to enter your fax number as it must be dialed from outside of your country. (You cannot enter pauses.) Fax Number +4401234567890 Note T The format of the number is normally as follows: International Dial Prefix, your Country Code, your Area Code, followed by your telephone number.
