E200P Operation Manual
(Version: V1.02)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E200P and is the answer not in the manual?

Questions and answers

Related Manuals for Estun E200P

Summary of Contents for Estun E200P

  • Page 1 E200P Operation Manual (Version: V1.02)

  • Page 2: Table Of Contents

    E200P Operation Manual Contents Preface ........................1 Chapter 1 Product Introduction ................3 1.1 Characteristic ....................3 1.2 Operation Panel ....................3 1.3 Display ......................4 Chapter 2 Operation Example .................. 6 2.1 Single-Step ...................... 6 2.1.1 Background ......................6 2.1.2 Analysis .........................

  • Page 3: Preface

    Attention  Copy right is preserved by ESTUN. Do not add or delete part or all of the manual content without ESTUN’s consent. Do not use part or all of manual content for the third party’s design. ...
  • Page 4 E200P Operation Manual Caution Sign The following symbols with an adjoining safety advice or notice are used in this document. You have to read the safety advices carefully and adhere them strictly! Risk of injury! If you do not adhere the safety advise adjoining this symbol, there is...

  • Page 5: Chapter 1 Product Introduction

    Chapter 1 Product Introduction 1.1 Characteristic E200P CNC device is a very suitable for torsional axis bending machine, providing solutions for most of the machine both complete and economy, with high performance, flexible configuration, compact structure, easy to use, high reliability characteristic: ...

  • Page 6: Display

    E200P Operation Manual Function Description Enter key: confirm the input content. If no content is input, the key has the similar function to direction key Start key: automatic start-up, top left corner of the key is operation indicator LED. When operation is started, this indicator LED is on.
  • Page 7 E200P Operation Manual  Current Position: here shows the relative position of the X-axis and Y-axis.  Parameter editing area: here shows the editable parameters.  Interpretation and Unit: here shows interpretation and unit of parameters the cursor...

  • Page 8: Chapter 2 Operation Example

    According to the actual situation to set. 2.1.3 Procedure Step 1 When the E200P device is electrified, wait a few seconds into the SINGLE page (Default page). Step 2 According to the analysis, press the arrow keys and number keys to modify the...

  • Page 9: Mutil-Step

    E200P Operation Manual Single 10.00 Y = 10.00 XP = 80.00 YP = 100.00 XP = 80.00 DX = 5.00 HT = 3.00 DLY= 2.00 PP = CP = OPN= 0.00 : DestPosX Unit: mm Figure 2-1 Single-Step example configuration Step 3 Press to run the machine, the device will enter the running page.

  • Page 10: Procedure

    85.00mm ST 3/3 5.00mm Repeat Times 2.2.3 Procedure Step 1 When the E200P device is electrified, wait a few seconds into the SINGLE page (Default page). Step 2 Press to enter PROGRAMS page. Step 3 Press or arrow key to select 2program, and then press to enter the NO.2...
  • Page 11 E200P Operation Manual PROGRAM2 1 / 3ST 10.00 Y = 10.00 50.00 85.00 5.00 OPEN DIST: 0.00 Repeat Times: TIMES Figure 2-3 Step configuration Step 6 According to Step 5, modify the parameters on the 2/3ST and 3/3ST pages. Step 7 Press back to PROGRAM page.

  • Page 12: Chapter 3 Operation Description

    E200P Operation Manual Chapter 3 Operation Description 3.1 Basic Operation 3.1.1 Start and Stop  After finishing the programming, press to run the machine.  The device starts, the green indicator light.  Only on the SINGLE page, PROAGRAM page or STEP page, the machine can run after pressing .

  • Page 13: Operation Flow

    Because of the SINGLE page has simple and direct parameter, it more suitable for the bending operation just only one-step. When the E200P device is electrified, wait a few seconds into the SINGLE page (Default page), as shown in Figure 3-2.
  • Page 14 E200P Operation Manual SINGLE X = 100.50 Y = 120.05 XP = 55.00 YP = 0.00 XP = 55.00 DX = 20.00 HT = 2.00 DLY= 2.00 PP = CP = OPN= 0.00 : DestPosX Unit: mm Figure 3-2 The SINGLE page The description of the SINGLE parameters is as shown in Table 3-1.

  • Page 15: Multi-Step

    In the actual processing, operator user pedal switch to control the bending process. In PROGRAM page, you can finish the complex operation with carefully programmed. Step 1 When the E200P device is electrified, wait a few seconds into the SINGLE page (Default page). Step 2 Press to enter the PROGRAMS page, as shown in Figure 3-3.
  • Page 16 E200P Operation Manual NO.2 PROGRAM 10.00 Y = 10.00 STEP PIECE PIECE DLY: 4.00 2.00 Figure 3-4 The PROGRAM page The description of the PROGRAM parameters is as shown in Figure 3-2. Table 3-2 The description of the PROGRAM parameters...
  • Page 17 E200P Operation Manual PROGRAM2 1 / 3ST 10.00 Y = 10.00 50.00 85.00 50.00 OPEN DIST: 0.00 Repeat Times: TIMES Figure 3-5 The STEP page The description of STEP parameters is as shown in Table 3-3. Table 3-3 The description of Step parameters...

  • Page 18: Manual

    In general, operator wants to adjust the backgauge or the block, need to enter MANUAL page to do relevant operation. When the E200P device is electrified, wait a few seconds into the SINGLE page (Default page), press enter MANUAL page, as shown in Figure 3-6.

  • Page 19: Alarm And Monitor

    E200P Operation Manual 3.6 Alarm and Monitor  On the CONST page, press to enter IO MONITOR page, as shown in Figure 3-7. IO MONITOR INPUTS 01 02 03 04 05 06 07 08 09 10 01 02 03 04 05 06 07 08 09 10...

  • Page 20: Appendix A Common Fault And Troubleshooting

    E200P Operation Manual Appendix A Common fault and troubleshooting Fault phenomena Trouble shooting  When power on, the device will not The electrode of power supply terminal is connected display. error; please see the information of power nameplate.  Voltage is too low.

  • Page 21: Appendix B Alarm List

    E200P Operation Manual Appendix B Alarm List Alarm NO. Alarm Information Alarm Description Normal message, that the count reaches a preset A.01 Pieces reached value. The current position of X-axis beyond the minimum A.02 XPos < minimum value, need manually adjust to the soft limit range.
  • Page 22 E200P Operation Manual Alarm NO. Alarm Information Alarm Description Check and set the parameter Driven Mode of each A.31 Drive Mode Err. axis, and make them as the same. A.32 Axis Droped When the driven mode is EDS, the drive is offline.

  • Page 23: Appendix C Parameter Description

    E200P Operation Manual Appendix C Parameter Description Parameter Default Range Unit Description CONST  0: mm mm/inch  1: inch 0: 中文  中文/English  1: English The delay time for the slide Release Delay 0.50 releasing the pressure after bending.
  • Page 24 E200P Operation Manual Parameter Default Range Unit Description In case of single step, delay 0~99.99 time for X-axle retracting. The number of processing 0~9999 workpiece in this program.  PP=0: this value is the current work piece. 0~9999  PP>0: this value is the remain work piece.
