Philips dvp3560kx/78 dvd player service manual (47 pages)
Summary of Contents for Philips DVP3560/12
Page 1
Register your product and get support at www.philips.com/welcome DVP3560 EN User manual...
Page 2
DO NOT STARE INTO BEAM. LOCATION: INSIDE, NEAR THE DECK MECHANISM. Italia DICHIARAZIONE DI CONFORMITA’ Si dichiara che l’apparecchio DVP3560, Philips risponde alle prescrizioni dell’art. 2 comma 1 del D.M. 28 Agosto 1995 n.548. Fatto a Eindhoven Philips Consumer Lifestyles...
Connect power Get started Prepare the remote control Find the TV input channel Select menu display language Turn on progressive scan Use Philips EasyLink Play Play a disc Play video Play music Play photo Play from a USB flash drive...
1 Important Safety and important notice Warning • Risk of overheating! Never install the product in a confined space. Always leave a space of at least 4 inches around the product for ventilation. Ensure curtains or other objects never cover the ventilation slots on the product.
2 Your DVD player Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome. Playable media This product can play: • DVD, DVD-Video, DVD+R/+RW, DVD-R/-RW, DVD+R/-R DL (Dual Layer) •...
• HDMI OUT jack on this product. • the HDMI input jack on the TV. Note • If the device supports HDMI CEC, you can control compliant devices with a single remote control (see “Get started” > “Use Philips EasyLink”).
Option 2: Connect to the component video jack COMPONENT VIDEO OUT Connect the component video cables to: • Y Pb Pr jacks on this product. • the COMPONENT VIDEO input jacks on the TV. Connect the audio cables to: • AUDIO OUT L/R jacks on this product.
Connect power Caution • Risk of product damage! Ensure that the power supply voltage corresponds to the voltage printed on the back of the product. • Before connecting the AC power cord, ensure you have completed all other connections. Note •...
In this case, turn off the progressive scan feature on both this product and the TV. Use Philips EasyLink This product supports Philips EasyLink which uses the HDMI CEC (Consumer Electronics Control) protocol. You can use one single remote control to control EasyLink-compliant devices that are connected through HDMI connectors.
Play video Note • Some operations may not work with some discs. See the information accompanying the disc for details. Control video play Play a title. Use the remote control to control the play. Button Action Start, pause or resume disc play. Stop disc play.
Select [Time Disp.], and then press . » The display options vary from disc type. Select an option, and then press OK. View DVD play from different angles During play, press INFO. » The disc status menu is displayed. Select [Angle], and then press . Press the Numeric buttons to change the angle.
If play does not automatically start, select a track to play. • To select another track/folder, press then press OK. Note • For disc recorded in multiple sessions, only the first session is played. • For a WMA file that is protected by Digital Rights Management (DRM), it cannot be played on this product.
Play from a USB flash drive Note • This product plays/views MP3, WMA, DivX (Ultra) or JPEG files that are stored on a USB flash drive. Connect a USB flash drive to the this product. Press the button. » A contents menu is displayed. If play does not start automatically, select a file to play.
Select [Start] in the menu, and then press OK to start to convert. » Once complete, a new folder is created automatically in the USB flash drive to store all the new MP3 files. • To exit the menu, select press OK.
[Analogue Output] Select an analogue setting based on the audio device that is connected through the analogue audio jack. • [LT/RT] - For the surround sound output through two speakers. • [Stereo] - For the stereo output. [Digital Audio] Select a digital setting based on the digital amplifier/ receiver that is connected through the digital jack (coaxial/digital).
Page 16
OK. [My Wallpaper] Select a picture as the wallpaper. • [Default picture] - The default wallpaper preset as the Philips logo. • [Saved picture] - A captured video image or JPEG photo. • [Current picture] - Capture a video image or JPEG photo and save it on the product.
You must turn on the HDMI CEC operations on the TV/ devices before you can enjoy the EasyLink controls. See the TV/devices manual for details. • Philips does not guarantee 100% interoperability with all HDMI CEC compliant devices. Preferences Note •...
Display the software version of this product. Note • This information is required when you want to find out if a newest software version is available at the Philips website that you may download and install on this product. [Default]...
If you contact Philips, you will be asked for the model and serial number of your product. The model number and serial number are on the back of your product.
Page 20
Sound No audio output from the TV. • Ensure that the audio cables are connected to the audio input of the TV. • Assign the audio input of the TV to the corresponding video input. See the TV user manual for details. No audio output from the loudspeakers of the audio device (stereo system/amplifier/receiver).
Page 21
Glossary Aspect ratio Aspect ratio refers to the length to height ratio of TV screens. The ratio of a standard TV is 4:3, while the ratio of a high-definition or wide TV is 16:9. The letter box allows you to enjoy a picture with a wider perspective on a standard 4:3 screen.
