4.2 Disassembly Procedure

This section illustrates how to remove the main components of this product. Unless otherwise specified, the reassembly procedure is the reverse of the disassembly procedure. For
additional assembly illustrations, refer to the exploded diagrams provided by SPI (Service Parts Information).
The following flowchart shows the disassembling procedure step-by-step. When disassembling any unit, refer to the corresponding page number shown in the following figure.
Disassembly of Main Unit
Start
Hinge Disengagement(P.34)
Upper Housing(P.35) Document Cover(P.35)
Panel Board(P.37)
Main Board(P.37) CR Motor(P.39)
Carriage Unit(P.41)
Eject Button(P.55)
Damper/Film Holder(P.53)
Film Holder Lock(P.54)
DISASSEMBLY/ASSEMBLY
Driven Pulley(P.41)
Hinge(P.36)
Cover Lower Assy/AFL
Sensor A(P.51)
Figure 4-1. Perfection V10/V100 Photo/V350 Photo Disassembly/Reassembly Flowchart
Disassembly of TPU
(Perfection V100 Photo/V200 Photo)
Start
TPU Upper Housing(P.43)
Harness TPU/TPU Inverter
Board(P.44)
Lamp Assy(P.49)
AFL Sensor B(P.50)
Disassembly Procedure
Disassembly of AFL
(Perfection V350 Photo)
Separation of AFL Upper
Housing Assy/AFL Lower
Housing Assy(P.46)
Lamp Assy(P.45)
AFL Inverter Board/AFL Harness AFL/AFL Main
Inverter Board Cover(P.48)
Film Ejection Cover(P.51)
Revision B
Start
Board(P.47)
