- Page 1 ZVOX VoiceBud ® Hearing Aid Model VB25 R E C H A R G E A B L E Great Sound. Made Simple. zvox.com...
- Page 2 This indicates the internal battery jack should be supported by an AC power connection. The Charging is fully charged and it can be used in portable operation again. ii VoiceBud VB25 Hearing Aid | Smart Device App and Battery Information...
-
Page 3: Table Of Contents
The Ear Dome and the Sound Tube ..............................9-10 Wearing a VoiceBud ..................................11-12 VoiceBud Operation and Use ................................13 VoiceBud Sound Mode Selection and Explanation ..........................14-15 Care of Your VoiceBud ..................................16-17 Sound Tube Removal ..................................18-19 Sound Tube Installation ...................................20-21 VoiceBud VB25 Hearing Aid | Table of Contents 1... -
Page 4: Parts And Features Vb25 And Charging Case
Its tip can be trimmed slightly (1/8 inch) for a more comfortable fit in a Ear dome small ear lobe. Install and cleaning tool 2 VoiceBud VB25 Hearing Aid | Parts and Features... - Page 5 Power On/Off Press and hold down the Volume Down end of the switch for 3 seconds to power Volume Down cycle the VoiceBud VB25. Watch the light inside the switch. When the switch light: Stays for 3 seconds: VoiceBud On.
- Page 6 Right Ear Dome Bay Left Charging Bay Left Charging Bay Left Charging Right Charging Status Indicator Status Indicator = CHARGING = CHARGING = CHARGED BLUE BLUE = CHARGED Charging On/Off Button 4 VoiceBud VB25 Hearing Aid | Charging Case Parts and Features...
- Page 7 Charging Case Status Light Indications = internal battery charging While the Charging Case is BLUE = internal battery charged connected to a charging cable NO LIGHT = not receiving charging current VoiceBud VB25 Hearing Aid | Charging Case Parts and Features 5...
-
Page 8: Charging Guide, Vb25 And Charging Case
Battery Charging Guide (VoiceBud VB25s and the Charging Case) A VoiceBud VB25 will begin to emit two rapid beeps VB25 Charging: Open the lid of the Charging Case and when its battery charge is low. Recharge the VoiceBuds follow this sequence. - Page 9 VoiceBud is charging. Allow six hours for a complete Voice- Bud charging cycle. Confirm the charging cycle is complete by pushing the Charging Case Charging Button. A blue light next to a VoiceBud indicates a full charge. Charging Button VoiceBud VB25 Hearing Aid | Using the Charging Case 7...
- Page 10 If the Charging Case is receiving power through its charging. The power socket light turns blue when the Charging USB charging jack, it will always recharge a pair of VoiceBuds. Case’s internal battery has reached a full charge. 8 VoiceBud VB25 Hearing Aid | Charging Case Portable Operation...
-
Page 11: The Ear Dome And The Sound Tube
Detach an ear dome by pulling it straight off the sound tube. Large Medium Small A left sound tube shown, Closed Dome Closed Dome Closed Dome a right sound tube is similar. Large Medium Small Open Dome Open Dome Open Dome VoiceBud VB25 Hearing Aid | Choosing An Ear Dome 9... - Page 12 VoiceBud user to use more sound amplification because it isolates the VoiceBud’s speaker from its microphones. Instructions starting on page 20 describe how to use the supplied tool to remove and attach the sound tube. 10 VoiceBud VB25 Hearing Aid | Closed Versus Open Ear Domes...
-
Page 13: Wearing A Voicebud
(1/8 inch). 4. When the dome is placed correctly, you should not be able to see the sound tube sticking out from your ear when facing a mirror. Right Ear Red “2B” VoiceBud VB25 Hearing Aid | Wearing a VoiceBud 11... - Page 14 Hold the sound tube with your thumb and forefinger and pull out on the sound tube. Don’t hesitate to contact the ZVOX Call Center if you have questions about the fit of your VoiceBud. 12 VoiceBud VB25 Hearing Aid | Wearing a VoiceBud...
-
Page 15: Voicebud Operation And Use
This ‘feedback’ is heard as a squealing note. Decreasing the volume setting eliminates feedback. A closed ear dome provides more feedback resistance than an open ear dome, allowing a VoiceBud user to benefit from more amplification. VoiceBud VB25 Hearing Aid | Operation of Your VoiceBud 13... -
Page 16: Voicebud Sound Mode Selection And Explanation
Mode 1: Speech (one beep is heard) The default mode. Use it Mode 2: Noisy Room (two beeps) Use when inside a space for conversation, in any place without much distracting sound. with distracting noises and other people talking. 14 VoiceBud VB25 Hearing Aid | Sound Mode Selection... - Page 17 Telecoil sound support logo. The VoiceBud will advance to Mode 1 after Mode 4. When the VoiceBud is turned on, the VoiceBud will select the mode in use when it was turned off. VoiceBud VB25 Hearing Aid | Sound Mode Selection 15...
-
Page 18: Care Of Your Voicebud
ZVOX Audio also recommends using the cleaning tool at six week intervals to ensure the sound tube is clear. ear dome sound tube 16 VoiceBud VB25 Hearing Aid | Care of Your VoiceBud... - Page 19 5. Use the cleaning tool’s brush to clear any foreign matter around the VoiceBud’s sound tube socket. Note: Store all unused parts of the VoiceBud hearing aid in its zippered case. cleaning tool brush VoiceBud VB25 Hearing Aid | Care of Your VoiceBud 17...
-
Page 20: Sound Tube Removal
2. Here is the tool capturing the sound tube. 1. Position the end of the tool as shown. Slide the tool onto the sound tube. NOTE: Position the brush on the tool straight-up, as shown. 18 VoiceBud VB25 Hearing Aid | Sound Tube Removal... - Page 21 3. Unscrew the sound tube counter- 4. Pull the tool straight off of the 5 Pull the sound tube out of the clockwise four full rotations. sound tube. VoiceBud. 4 rotations VoiceBud VB25 Hearing Aid | Sound Tube Removal 19...
-
Page 22: Sound Tube Installation
VoiceBud. 1b. Press firmly on the sound tube to seat in the VoiceBud socket. The red stripe on the sound tube lines up with the green dot on the VoiceBud. 20 VoiceBud VB25 Hearing Aid | Sound Tube Installation... - Page 23 VoiceBud socket, the sound tube will rotate without engaging the threads in the socket. In this case, apply more pressure on the tool to seat the sound tube before screwing it into place. VoiceBud VB25 Hearing Aid | Sound Tube Installation 21...
- Page 24 Warranty The ZVOX Audio product warranty information and service agent for each international region is available here: https://zvox.com/pages/warranty-repair © 2019 ZVOX Audio LLC. www.zvox.com 100VB25 09/19...
