Summary of Contents for ACOUSTIC SOLUTIONS CAMP-1B

  • Page 2: Table Of Contents

    CAMP-1B HI-FI STEREO AMPLIFIER INTRODUCTION PAGE No. CONTENTS Congratulations on purchasing the Acoustic Solutions CAMP-1B Hi-Fi Introduction Stereo Amplifier. Safety Instructions Front Panel Controls We trust that this product will give you hours of listening pleasure, and Rear Panel connections provide years of unparalleled performance.

  • Page 3: Safety Instructions

    For your safety please observe the following information. IMPORTANT SAFETY INSTRUCTIONS • The CAMP-1B is designed to operate on AC mains supply between 220 • Read and keep these instructions available for future reference. and 240 volts, 50 Hz.

  • Page 4: Front Panel Controls

    Speaker Right Speaker Left Line Out MP3-in Tape Phono Impedance 4-16Ω Impedance 4-16Ω FRONT PANEL CONTROLS Control DAB/MP3 Headphone Treble Bass Balance Function CD/DVD PHONO/TAPE Power 1. POWER BUTTON. Switches mains power on/off to internal components, 8. CD/DVD SELECTOR. Switch between CD and DVD input modes. however please note that mains power is still applied to this unit even though this switch may be off.

  • Page 5: Rear Panel Connections

    17. CD INPUT SOCKET. For the connection of a CD player 11. RIGHT LOUDSPEAKER OUTPUTS. Please ensure that +/- connections are made properly between rear of the CAMP-1B amplifier and loudspeakers. 18. TAPE INPUT SOCKET. For the connection of a Tape player Ensure wires are not frayed or touching.

  • Page 6: Remote Controls

    ON/Stby DAB/FM A remote control is supplied with the CAMP-1B unit, this remote is shared 26. MUTE. Press to instantly cancel the sound, press again to restore. between the CAMP-1B and the CDAB-1 ( DAB/FM Tuner ) with the amp controls on the bottom half of the remote ( as shown ) 27.

  • Page 7: Installation And Position

    Do not place the CAMP-1B connected to the red terminal on the loudspeaker. The same process should in areas of direct sunlight, nor place it adjacent to a radiator or other heating occur for the black terminals.

  • Page 8: Making The Connections

    MAKING THE CONNECTIONS MP3 PLAYER MP3 PLAYER & DOCK WITH RCA OUTPUT CTT-1 TURNTABLE IE: CDK-2 Speaker Right Speaker Left Line Out MP3-in Tape Phono Impedance 4-16Ω Impedance 4-16Ω CAMP-1 AMPLIFIER CD PLAYER CDVD-1 CD/DVD PLAYER CDAB-1 DAB TUNER CSPK-85 SPEAKERS Control Input Select Headphone...

  • Page 9: Using The Amplifier

    When you unpack the amplifier from the box, all music settings will be at default values. These can be altered according to your listening tastes; This CAMP-1B amplifier is fitted with a digital user interface which allows these new settings will be retained within the memory of the amplifier and complete control of the features of this amplifier.
  • Page 10 USING THE AMPLIFIER VOLUME CONTROL TREBLE CONTROL The VOLUME level will be displayed on line one of the LCD display as a This amplifier is fitted with a treble control which offers +/-14dB attenuation numeric dB value. around the centre frequency of 10Khz, and 6dB across the frequency range of 2Khz to 20Khz.
  • Page 11 USING THE AMPLIFIER BASS CONTROL BALANCE CONTROL This amplifier is fitted with a bass control which offers +/-14dB attenua- This amplifier is fitted with a balance control which allows the volume of the tion around the centre bass frequency of 100Hz, and +/-3dB across the left and right signals of the stereo image to be altered in order to frequency range of 45Hz to 259Hz.

  • Page 12: Using The Amplifier

    USING THE AMPLIFIER LOUDNESS CONTROL SPEAKER ON/OFF CONTROL This amplifier is fitted with a loudness control which provides a boost to This amplifier is fitted with a loudspeaker control which allows the lower frequencies at lower listening volumes. loudspeakers to be turned off when listening through headphones This creates the effect of increasing the perceived amount of bass / mid content in the music when playing the amplifier at a lower level.

  • Page 13: Trouble Shooting

    TROUBLE SHOOTING PROBLEM POSSIBLE SOLUTION PROBLEM POSSIBLE SOLUTION No power when switched • Mains socket not switched on, or faulty. Will not play or make tape • Tape input / output connections reversed. • Plug not fully inserted into wall socket recordings •...

  • Page 14: Specifications

    SPECIFICATIONS CONTACT DETAILS We trust you are completely satisfied with this product from Clarity Vision PHONO INPUT (Group) Limited, however please feel free to contact us if you experience 47kΩ Input impedance any difficulties, or if you would like to express your views regarding our 5mV (to suit magnetic cartridges) Input sensitivity products.
