southpaw enterprises Flexion Disc Swing 1909 Instruction Sheet

southpaw enterprises, inc.
Instruction Sheet
Flexion Disc Swing 1909
Take time to familiarize yourself with the use and maintenance of this equipment before using. Please file this
Instruction Sheet in an accessible location: the Instruction Sheet must be read and familiar to anyone who is
using Southpaw Enterprises Equipment.
IMPORTANT: Please check equipment immediately for any damage
that may have resulted during shipping. If any damage has occurred,
please contact Southpaw Enterprises, Inc. immediately.

MATERIALS LIST

1909
1 - Carpeted Base
1 - Padded Body
4 - Washers
4 - Locking Washers
4 - 1" Button Head Bolts
1 - 1 Allen Wrench
1 - Detachable Control Strap
1 - Safety Snap
1 - Instruction Sheet
1 - Maintenance Checklist
1 - Safety Snap Instruction Sheet
A SAFETY ROTATIONAL DEVICE MUST BE USED TO
PREVENT DAMAGE TO YOUR FLEXION DISC SWING
MINIMUM HEIGHT REQUIREMENT: 8 ft.
Use care to assure a clear distance of 6 ft. from walls and other obstacles.
WORKING LOAD: 300 lbs.
TOOLS NEEDED FOR ASSEMBLY: Included allen wrench.

ASSEMBLY PROCEDURES

•
Put the body on a table laying on it's side with the small, wood disc on the end sticking off the table.
•
Remove the washers, lock washers, and bolts from the bag which is tied onto the padded body.
•
With the carpeted side of the base facing the body, line up the holes in the base with the holes on the body (The
center hole on the base is a clearance hole for the welded nut only).
•
Onto each Button head bolt place a lock washer, followed by a flat washer (see illustration). Put each bolt through a
hole the base, into the padded body, and hand tighten.
•
Tighten each nut securely with the included allen wrench.
•
Turn the Flexion Disc Swing over and hang from your Southpaw Safety Rotational Device (item #2000), that is
attached to your suspension system, using a Safety Snap attached to the cable at the top of the swing. (Note: insert
Stimulation Device between the swing and rotational device with 1910 deluxe model).
•
The Detachable Control Strap can be attached to the Flexion Disc Swing either at the top or bottom. Attach the con-
trol strap to the eye nut at the top if desired, or to the attachment ring on the bottom of the base.
Deluxe Flexion Disc Swing 1910
1910
1 - Carpeted Base
1 - Padded Body
4 - Washers
4 - Locking Washers
4 - 1" Button Head Bolts
1 - Allen Wrench
1 - Detachable Control Strap
1 - Safety Snap
1 - Vertical Stimulation Device
1 - Instruction Sheet
1 - Maintenance Checklist
1 - Safety Snap Instruction Sheet
1 - V.S.D. Instruction Sheet
Store these instructions in a safe place or
with the enclosed maintenance checklist
Warning: Failure to properly install a forged
steel eyebolt (1/2" or 5/8") may result in serious
injury or death. If you have any questions about
the installation of the forged steel eyebolt,
please contact Southpaw Enterprises Customer
Service at 1-800-228-1698.
®
