1 Service and Maintenance

Disassembly

Tools required

Items
PZ1 driver
T10 Torx driver
T8 Torx driver
1/4" nut socket
1/2" nut socket

Removing/Installing the optional GPIB interface

TURN OFF POWER AND REMOVE ALL CONNECTIONS BEFORE PROCEED
WARNING
Turn off the power and remove all connections, including the power cord,
from the instrument prior installation/removal of the GPIB interface.
RETAIN GPIB COVER PLATE
WARNING
After installing the GPIB interface, retain the cover plate for use in the event
that you ever remove the GPIB interface. The instrument should never be
connected to power or inputs on the output terminals without either the
GPIB interface or the cover plate securely covering the rear-panel opening.
Refer to the E36200 Series User's Guide for more information on how to remove or
install the optional GPIB interface (Chapter 1, "Prod uct Information" >
Installation > Installing the optional GPIB interface).
20
Torque value
9.0 in.lbs
9.0 in.lbs
9.0 in.lbs
9.0 in.lbs
3.5 in.lbs
Keysight E36200 Series Service Guide
