IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should
always be followed including the following:
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1.
DANGER- Risk of shock- Disconnect power before installation.
DANGER - RISQUE DE CHOC - COUPER L'ALIMENTATION
AVANT L'INSTALLATION
2.
This luminaire must be installed in accordance with the NEC or your
local electrical code. If you are not familiar with these codes and
requirements, consult a qualified electrician.
Ce produit doit être installé conformément à NEC ou votre code
électrique local. Si vous n'êtes pas familier avec ces codes et ces
exigences, veuillez contacter un électricien qualifié.
3.
To reduce the risk of electric shock, disconnect both standard
and emergency power supplies and converter connector of the
emergency driver before servicing.
Pour réduire le risque de décharge électrique, vous devez
déconnecter à la fois le disjoncteur divisionnaire ou les fusibles et
les alimentations d'urgence avant l'entretien.
4.
Do not use outdoors.
Ne pas utiliser à l'extérieur.
5.
Do not let power supply cords touch hot surfaces.
Ne laissez pas les cordons d'alimentation toucher les surfaces
chaudes.
6.
Do not mount near gas or electric heaters.
Ne montez PAS près des appareils de chauffage de gaz ou
électriques.
7.
Use caution when servicing batteries. Battery acid can cause burns
to skin and eyes. If acid is spilled on skin or eyes, flush acid with
fresh water and contact a physician immediately.
Faites preuve de prudence lors de l'entretien des batteries. L'acide
de batterie peut provoquer des brûlures de la peau et les yeux. Si
l'acide est versé sur la peau ou les yeux, rincer à l'eau acide frais et
contacter un médecin immédiatement.
8.
Equipment should be mounted in locations and heights where it will
not readily be subjected to tampering by unauthorized personnel.
L'équipement doit être monté dans des endroits et à des hauteurs
où il ne sera pas soumis à des altérations par des personnes non
autorisées.
9.
The use of accessory equipment not recommended by the
manufacturer may cause an unsafe condition.
L'utilisation d'accessoires non recommandés par le fabricant peut
causer une situation dangereuse.
10. Max. mounting height: 10 ft.
Hauteur de montage max.: 10.
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE
NOTES:
• The LS Series is for non-insulated ceiling applications using surface
mount, T-Bar ceiling grid, suspended cable, chain and pendant
mount accessory (not included).
• Designed for use in 120-277V 60Hz protected circuit (fuse box, circuit
breaker). Supply wire size as per NEC or governing code(s), 90C
rated.
1 of 4
LED Surface Ambient Luminaire with Emergency Driver
LS
LSQ
Cree Accessories (ordered separately):
SUSPENDED MOUNT
•
AC5-12/3-48-Q14B-JB- 48" Power Feed, #12/3 SJT
Cord with Cable Support for J-Box
•
AC5-18/5-48-Q14B-JB- 48" Power Feed, #18/5 SJT
Cord with Cable Support for J-Box
•
AC5-18/2-48-Q14B-JB- 48" Power Feed, #18/2 SJT
Cord with Cable Support for J-Box
•
AC5-48-Q14B-TB- 48" Cable Support for T-bar mount.
•
B=LS-M- Optional Mounting Bracket
• Available luminaire lengths are 4' and 8'.
• Suitable for Damp Locations.
• Figures below show LS luminaire for illustration purposes only.
LS AND LSQ Series
Includes: LS4 and LS8 luminaires
INSTALLATION INSTRUCTIONS
INSTRUCTIONS D'INSTALLATION
LPN00238X0001A1_E
