Thiel CS7.2 Owner's Information

Coherent source loudspeaker system
Hide thumbs Also See for CS7.2:
Table of Contents

Advertisement

Quick Links

OWNER INFORMATION

INNOV AT IONS
C O N S U M E R E L E C T R O N I C S S HOW
C O M P O N E N T S
®
THIEL
Model CS7.2
Coherent
Source
loudspeaker
system
Speaker of the Millennium
O F
T H E
Y E A R
®
image hifi

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS7.2 and is the answer not in the manual?

Questions and answers

Related Manuals for Thiel CS7.2

Summary of Contents for Thiel CS7.2

  • Page 1: Owner Information

    OWNER INFORMATION ® INNOV AT IONS C O N S U M E R E L E C T R O N I C S S HOW THIEL Model CS7.2 Coherent Source loudspeaker system C O M P O N E N T S...

  • Page 2: Table Of Contents

    CS7.2’s construction. Properly set up and used with good associated equipment, the CS7.2 will provide a great deal of musical enjoyment for many years. CONTENTS Design philosophy...1 Positioning the speakers ... 2 Connecting the speakers ...

  • Page 3: Design Philosophy

    The CS7.2 is not intended to mask or mitigate shortcomings of the recording or other components in the music playback system.

  • Page 4: Positioning The Speakers

    POSITIONING THE SPEAKERS Because of their unipolar radiation pattern and co-axial design, the CS7.2s will provide good results when placed in a variety of room locations. However, speaker placement will affect the accuracy of timbre, spatial performance, and bass performance. Here are some guidelines to help you achieve the best sound from your speakers. (The pointed metal stabilizer pins should not be installed until the final positioning has been determined.) All aspects of speaker placement are dependent on the particulars of the room.
  • Page 5 Spacing Because of their very wide, even dispersion of energy, the CS7.2s can usually be placed farther apart than most other speakers. Optimum imaging is usually achieved when the speakers are almost as far apart as each speaker is from the listener, although this will depend on the width of the room—narrow rooms require more narrow placement.
  • Page 6 Some rooms, especially narrow ones, can benefit from placing the speakers along the long wall. Although space behind the speaker and behind the listener is reduced, this positioning increases the space between the speakers without side wall interference, and can improve overall performance.

  • Page 7: Connecting The Speakers

    CONNECTING THE SPEAKERS The CS7.2s’ input terminals are located on the bottom of the speaker near the back. Access is from the back with the speaker in its normal upright position. Make sure that both connections are tight. It is best to turn the amplifier off while connecting or disconnecting the speakers.

  • Page 8: Break-In

    BREAK-IN The CS7.2s, like most speakers, require a period of playing before they perform optimally. The time required depends on how loudly the speakers are played; more time is required if played softly, less if played loudly. At least 50 hours at moderately loud levels are required before the speaker is performing near optimum. You should notice even more improvement after 100 hours of playing.

  • Page 9: Service

    GRILLE The CS7.2 grille is designed to not produce diffraction so there is no sonic reason to remove it. If you do need to remove the grille, pull the bottom of the grille frame away from the speaker an inch or so and then lift the grille upward to remove it.
  • Page 10 Light traffic, normal conversation, quiet office Air conditioner at 20 feet, sewing machine Vacuum cleaner, hair dryer, noisy restaurant Average city traffic, garbage disposals, alarm clock at two feet CS7.2 SPECIFICATIONS 23 Hz-20 kHz 25 Hz-17 kHz 1.5 dB minimum 10 86 dB@2.8 V-1m...

  • Page 11: Warranty

    LIMITED WARRANTY THIEL warrants every THIEL model CS7.2 system against defects in materials and workmanship to the original owner for a period of ten years from the date of purchase. THIEL will, at no charge, replace any defective part and make any repairs necessary to ensure its proper performance when the defective unit is returned to us postpaid.
  • Page 12 CONTRIBUTOR HARDWOOD FORESTRY FUND THIEL 1026 Nandino Boulevard Lexington, Kentucky 40511-1207 Telephone: 859-254-9427 • E-mail: mail@thielaudio.com • Web: www.thielaudio.com 3/01...
