DURAVIT Starck 3 Mounting Instructions
One-piece water toilet
Hide thumbs
Also See for Starck 3:
- Template and mounting instructions (2 pages) ,
- Mounting instructions (2 pages)
Related Manuals for DURAVIT Starck 3
Summary of Contents for DURAVIT Starck 3
- Page 1 Leben im Bad Living bathrooms Starck 3 Mounting instructions One-piece water toilet Instrucciones de montaje Inodoro monopieza # 2120010001...
-
Page 2: Table Of Contents
Index English Español Technical information Información técnica Content of packaging ....3 Contenido de la caja ...... 3 ........3 Assembly dimensions ....4 Medidas de montaje ...... 4 ........4 Mounting instructions Instrucciones de montaje Installation of the toilet ....5 Instalación del inodoro .... -
Page 3: Content Of Packaging
# 2120010001 # 0063320000 # 0063390000 THIS CARTON CONTAINS: ESTE CARTÓN CONTIENE: 1. One-piece water toilet with tank 1. Un inodoro monopieza con tapa lid and side lever actuator de cisterna y pulsador lateral. 2. Tank supplied with fill valve and 2. -
Page 4: Assembly Dimensions
" " " " " 12" " 4" " " BEFORE YOU START: ANTES DE EMPEZAR: Please take a few minutes to read Tómese algunos minutos para leer the following installation instruc- las siguientes instrucciones de tions. in-stalación. Your new one-piece water toilet Su nuevo inodoro monopieza es un (1.28 gpf /4.8 lpf) is a low consumption water toilet... -
Page 5: Installation Of The Toilet
Shut-off valve Llave de paso " 225 mm " 125 mm 305 mm 12" max. / máx. " / 6,5 mm INSTALLATION OF THE TOILET If the floor flange has not been se- Place the new wax-ring around the Connect the flexible water supply cured to the building structure affix outlet hole of the floor flange. - Page 6 It is recommended that two people Alternately tighten nuts until toilet Connect the water supply line with Turn on the water at the shut-off lift the one-piece water toilet into is firmly seated on floor. the shut-off valve. valve. place over the floor bolts and on the wax-ring.
- Page 7 Open the tank cover carefully. The tank water level is factory set and should rise to the water level mark (1). Flush the tank at least three times If it is not at this level, adjust the fill valve (2) to set the water line to the and check it for leaks.
- Page 8 It is recommended that the fixture be sealed around its base using sili- cone sealant. Es recomendable sellar el inodoro alrededor de su base usando sili- cona. MAL_53758/14.02.2...
-
Page 9: Safety Instructions
Fill valve # 0074114262, flapper 3” # 0074136962, side lever # 0074831000, hinge set for Starck 3 toilet seat and cover elongated # 0061611000, SoftClose hinge set for Starck 3 toilet seat and cover # 0061621000, pair of bolt caps white... -
Page 10: Instrucciones De Seguridad
# 0061611000 de inodoro Starck 3, el kit de SoftClose para fijar la tapa y el asiento del inodoro Starck 3 # 0061621000 y dos tornillos con embellecedores blancos # 0067140000 pueden adquirirse en el establecimiento del agente - La cadena de la válvula de des-... - Page 11 #0074114262, 3” #0074136962, #0074831000, #0061611000, #0061621000 # 0 0 6 7 1 4 0 0 0 0 #0063320000 #0063390000 MAL_53758/14.02.2...
- Page 12 Duravit AG Duravit USA, Inc. Duravit Shanghai Sales Center Werderstr. 36 2205 Northmont Parkway Suite B-d, 10/F Jiu Shi Tower 78132 Hornberg Suite 200 No. 28 Zhongshan Road South Germany Duluth, GA 30096 Shanghai P.C. 200010 Phone +49 78 33 70 0...
